GB/T 24348.4-2009 English PDF

US$169.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 24348.4-2009: Textile machinery and accessories -- Reeds -- Part 4: Dimensions and designation of plastic-bound metal reeds
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 24348.4-2009	169	Add to Cart	3 days	Textile machinery and accessories -- Reeds -- Part 4: Dimensions and designation of plastic-bound metal reeds	Valid

Similar standards

FZ/T 93048.1   FZ/T 93019   GB/T 24348.3   GB/T 24348.5   GB/T 24348.2

Basic data

Standard ID: GB/T 24348.4-2009 (GB/T24348.4-2009)
Description (Translated English): Textile machinery and accessories -- Reeds -- Part 4: Dimensions and designation of plastic-bound metal reeds
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: W90
Classification of International Standard: 59.120.30
Word Count Estimation: 7,754
Date of Issue: 2009-09-30
Date of Implementation: 2010-02-01
Quoted Standard: GB/T 24348.5
Adopted Standard: ISO 366-4-2005, MOD
Regulation (derived from): National Standard Approval Announcement 2009 No.10 (Total No.150)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the textile industry Sizha resin curing metal reeds basic dimensions and markings. This section applies to rapier, water jet loom, projectile loom resin curing metal Sizha reed.

GB/T 24348.4-2009: Textile machinery and accessories -- Reeds -- Part 4: Dimensions and designation of plastic-bound metal reeds

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Textile machinery and accessories.Reeds.Part 4. Dimensions and designation of plastic-bound metal reeds ICS 59.120.30 W90 National Standards of People's Republic of China Textile machinery and accessories reed Part 4. resin - cured metal wire reed Size and mark (ISO 366-4..2005, MOD) 2009-09-30 release 2010-02-01 Implementation General Administration of Quality Supervision, Inspection and Quarantine of the People 's Republic of China China National Standardization Management Committee released

Foreword

GB/T 24348 "Textile machinery and accessories reed" is divided into five parts. - Part 1. Dimensions and marking of adhesive tape reed; - Part 2. Dimensions and marking of flat beam girders; - Part 3. Dimensions and marking of double elastic beam metal wire reed; - Part 4. Dimensions and marking of resin cured metal wire reeds; - Part 5. Dimensions and marking of grooved beams. This part is part 4 of GB/T 24348. Revised use of ISO 366-4..2005 "Textile machinery and accessories reed Part 4. Resin curing metal wire reed size and Mark "(English version). This part is re-drafted in accordance with ISO 366-4..2005, and the technical differences with ISO 366-4..2005 are. The reason for the above technical differences is. Requirements, and no applicable testing equipment, so according to the use of requirements and production changes to 0.5mm. For ease of use, this section also makes the following editorial changes to ISO 366-4..2005. a) "ISO 366" was replaced by the words "GB/T 24348"; b) delete the preface of ISO 366-4..2005; c) the title of the second chapter "reference standard" to "normative reference document", and use GB/T 1.1-2000 specified in the guide; d) In Figure 1 and Figure 2, the dimension between the size code and the corresponding name is changed to a dash "---" and the punctuation is added after the name symbol; e) Table 1, add the table "gray area for the recommended size specifications"; f) Replace "," with the decimal point symbol "." instead of the decimal point symbol; g) The vertical reference symbol in Fig. 2 is changed to an italicized letter with a small circle and is connected to a thick dash line with a thin solid line. This part is made by China Textile Industry Association. This part of the National Textile Machinery and Annex Standardization Technical Committee. This part of the drafting unit. Changzhou Reed Co., Ltd., Shaoxing City Shui Fu Textile Equipment Co., Ltd., Shaoxing County Dingfeng Textile Equipment Co., Ltd., Shaanxi Textile Equipment Research Institute. The main drafters of this part. Zhao Yusheng, Qiu Lifeng, Shi Yuehao, Ni Kegang, Zhu Shuifu, Ding Guosheng, Yu Dingquan, light Peixia. Textile machinery and accessories reed Part 4. resin - cured metal wire reed Size and mark

1 Scope

This part of GB/T 24348 specifies the basic dimensions and marking of resin cured metal wire reed for textile industry. This part applies to rapier looms, water jet looms, sheet loom with resin curing metal wire reed.

2 normative reference documents

The terms of this document are the terms of this part by reference to this part of GB/T 24348. Any reference to the date of the text , All subsequent amendments (excluding corrigenda) or revisions do not apply to this part, however, encouragement under this section The parties to the agreement study whether the latest version of these documents can be used. For undated references, the latest edition of this document applies section. GB/T 24348.5 Textile machinery and accessories - Reed - Part 5. Dimensions and marking of grooved beams (GB/T 24348.5-2009, ISO 366-5..2006, MOD)

3 size

The basic dimensions of the resin cured metal wire reed are shown in Figures 1 and 1, and the vertical tolerance of the dents is as per the requirements of Fig. The height of the upper and lower reed beams shall be in accordance with GB/T 24348.5 or by both parties. ......
