GB/T 24298-2009 English PDF

US$209.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 24298-2009: Standard test method for cross curvature of thermostat metals
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 24298-2009	209	Add to Cart	3 days	Standard test method for cross curvature of thermostat metals	Valid

Similar standards

GB/T 23365   GB/T 24488   GB/T 34190   GB/T 45324   GB/T 24299   GB/T 24297

Basic data

Standard ID: GB/T 24298-2009 (GB/T24298-2009)
Description (Translated English): Standard test method for cross curvature of thermostat metals
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: H21
Classification of International Standard: 29.120.20
Word Count Estimation: 9,939
Date of Issue: 2009-09-30
Date of Implementation: 2010-02-01
Quoted Standard: GB/T 2900.4
Adopted Standard: ASTM B478-1985 (R2003), MOD
Regulation (derived from): National Standard Approval Announcement 2009 No.10 (Total No.150)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the thermal bimetal, strip lateral bending measurement method, measuring device, sampling, sample preparation and calculation formulas and so on. This standard applies to boast curved lateral thermal bimetal measurements also apply to other materials lateral bending of precise measurements. This standard does not address all of the safety elements of the contents before using this standard, the user has the responsibility to develop appropriate safety regime.

GB/T 24298-2009: Standard test method for cross curvature of thermostat metals

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Standard test method for cross curvature of thermostat metals ICS 29.120.20 H21 National Standards of People's Republic of China Thermal bimetallic lateral bending test method Posted 2009-09-30 2010-02-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard ASTMB478. 1985 "Thermal bimetallic transverse bending test method" (2003 review confirm) to modify the degree of consistency use. This standard is based on ASTMB478. 1985 (R2003) redrafted. The standard lists the reg number in Appendix A and ASTMB478. 1985 reg control list numbered. This standard ASTMB478. 1985 (R2003) compared to the main technical differences are detailed in Appendix C. --- To facilitate the use of standards, increased lateral bending radius of curvature of the formula; --- To meet the environmental conditions of the laboratory, the test temperature from 24 ℃ ± 0.5 ℃ adjusted to 24 ℃ ± 2 ℃. For ease of use, for ASTMB478. 1985 standard also made the following editorial changes. --- Provided in Chapter 2, "Normative references"; --- The ASTMB478. 1985 (R2003) for "term" is no longer listed, direct reference to GB/T 2900.4 "Electrotechnical Terminology Electrical Alloy "; --- Remove the standard use of little significance, "the meaning and application", "sampling" and "keywords" content such as chapters; --- Removed ASTMB478. 1985 (R2003) Chapter 11, an increase of Appendix B. This standard Annex A, Annex B, Annex C is informative appendix. The standard proposed by China Electrical Equipment Industrial Association. This standard by the National Standardization Technical Committee for Electrotechnical alloy (SAC/TC228) centralized. This standard was drafted. Foshan Electrical Precision Alloy Co., Ltd., Baoshan Iron & Steel Co., Ltd. Special Steel Branch, Shanghai Electric Power Bureau Engineering Materials Co., Ltd., Shanghai Electric Co., Ltd. and transport, Guilin Institute of Electrical Science. The main drafters of this standard. Huo Zhiwen, Zhang Zhongmin, Lu Yao, Feng Yunfu, Shen Yi, Xie Yongzhong. Thermal bimetallic lateral bending test method

1 Scope

This standard specifies thermal bimetal strip lateral bending of the measuring method, measuring apparatus, sampling, sample preparation and calculation formulas and the like. This standard applies to the measurement of thermal bimetal curved transversely, also applicable to other materials lateral bending of accurate measurement. This standard does not address all of the safety elements contents before using this standard, the user has the responsibility to develop appropriate security regime.

2 Normative references

The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 2900.4 Electrotechnical terminology - Electrical Alloy

3 Terms and Definitions

Terms and definitions GB/T 2900.4 established apply to this standard.

4 measuring principle

Lateral bending measurements is shown in Figure 1. measurement of thermal bimetal sample the entire width (L) from the plane deviation (chord C). The sample was put On the pad dedicated measurement apparatus, convex upward, with a depth micrometer to measure the highest point of the sample to the pad plane distance meter by formula Operators obtain lateral bending and lateral bending radius of curvature of the specimen. Note. Under normal circumstances, the highest point in the center of the specimen at (or near). FIG. 1 a schematic cross-curvature measurement method

5 measurement device

5.1 Fixtures Typical measurement of lateral bending fixture structure diagram shown in Figure 2, the device consists of a base reference plane, brackets, rails, depth micrometer, flat And electrical contact pad row pointer constituted on the end face of the base as the reference plane, it is above the moving rail, the rail and the reference plane parallel to the track A movable track assembly bracket. Depth of 5.2 micrometer Minimum scale value should be less than 0.002mm, the measurement should be made spherical rod end or tip, is fixed to the mobile holder can guide Looking to move on the highest point of the specimen along the specimen width direction. ......
