GB/T 24123-2009 English PDF

US$299.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 24123-2009: Metallized film for capacitors
Status: Valid
Standard IDUSDBUY PDFLead-DaysStandard Title (Description)Status
GB/T 24123-2009299 Add to Cart 3 days Metallized film for capacitors Valid

Similar standards

GB/T 20632.3   GB/T 20632.2   GB/T 31034   GB/T 13542.4   GB/T 24124   GB/T 24122

Basic data

Standard ID: GB/T 24123-2009 (GB/T24123-2009)
Description (Translated English): Metallized film for capacitors
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K15
Classification of International Standard: 29.035.99
Word Count Estimation: 13,120
Date of Issue: 2009-06-10
Date of Implementation: 2009-12-01
Quoted Standard: GB/T 2828.1; GB/T 13542.2-2009
Regulation (derived from): Announcement of Newly Approved National Standards No. 8, 2009 (No. 148 overall)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the metallized film capacitor with the terminology, product classification, performance requirements, test methods, inspection rules, marking, packaging, transport and storage. This standard applies to capacitors with metallized polypropylene film and the beginning of metallized polyester film.

GB/T 24123-2009: Metallized film for capacitors

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Metallized film for capacitors ICS 29.035.99 K15 National Standards of People's Republic of China Metalized film capacitors Posted 2009-06-10 2009-12-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

The standard proposed by China Electrical Equipment Industrial Association. This standard by the National Standardization Technical Committee of the insulating material (SAC/TC51) centralized. This standard was drafted. Junta Jiangmen Industrial Investment Co., Ltd., Zhejiang Nanyang Technology Co., Ltd., Foshan Plastics Group shares have Limited, Guilin Institute of Electrical Science, Guilin Power Capacitor limited liability company. The main drafters of this standard. Ke Qingyi, Ding Bang Jian, Tang Xiaoling, Wang Xianfeng, Li Zhaolin. This standard was first formulated. Metalized film capacitors

1 Scope

This standard specifies the metallized film capacitors terms, product classifications, performance requirements, test methods, inspection rules, marking, packaging, Transport and storage. This standard applies to metallic polypropylene film capacitors and metallized polyester film.

2 Normative references

The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 2828.1 count test procedures - Part 1. batch inspection plans by acceptance quality limit (AQL) retrieval (GB/T 2828.1-2003, ISO 2859-1.1999, IDT) Test Method. GB/T 13542.2-2009 Electrical insulation film 2 part article (IEC 60674-2. 1988, MOD)

3 Terms and Definitions

The following terms and definitions apply to this standard. 3.1 It can be deposited on the surface layer of very thin metal layer of plastic film capacitors. 3.2 The high purity aluminum or zinc under high vacuum melting, evaporation, deposit base film, the surface of the base film layer of very thin metal layer is formed after plastic film. 3.3 After the metal film dielectric breakdown locally instinct immediately restored to the electrical breakdown properties of the phenomenon before. 3.4 The actual production of capacitors required, metallized film or one or both edges to form a blank cover intermediate insulating metal vapor deposition was not Article (band) called Margin, Margin amount is called its width. 3.5 Metal layer metallized film on the resistance value of the unit square area known as sheet resistance with Ω/□ represented, usually sheet resistance To indicate the thickness of the metal coating. Note. □ See Table 5 note. 3.6 Patterned metal layer containing metal film fuse security architecture. Press safety fuse structural features can be divided into grid security film, T-shaped safety The whole film and safety film series.
......
