GB/T 23565.3-2009: Sliding guide steel-plate die sets of stamping dies -- Part 3: Center-pillar die sets
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 23565.3-2009	189	Add to Cart	3 days	Sliding guide steel-plate die sets of stamping dies -- Part 3: Center-pillar die sets	Valid

Similar standards

GB/T 45677   GB/T 6110   JB/T 3943   GB/T 23565.4   GB/T 23562.1   GB/T 23565.2

Basic data

Standard ID: GB/T 23565.3-2009 (GB/T23565.3-2009)
Description (Translated English): Sliding guide steel-plate die sets of stamping dies -- Part 3: Center-pillar die sets
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J46
Classification of International Standard: 25.120.30
Word Count Estimation: 8,881
Date of Issue: 2009-04-02
Date of Implementation: 2010-01-01
Quoted Standard: GB/T 2861.1; GB/T 2861.3; GB/T 23562.3; GB/T 23566.3; JB/T 8050
Regulation (derived from): National Standard Approval Announcement 2009 No.5 (Total No.145)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the sliding guide die mold steel mold of the middle pillar dimensions and markings. This section applies to sliding guide plate mold die middle pillar mold.

GB/T 23565.3-2009: Sliding guide steel-plate die sets of stamping dies -- Part 3: Center-pillar die sets

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Sliding guide steel-plate die sets of stamping dies Part 3. Center-pillar die sets ICS 25.120.30 J46 National Standards of People's Republic of China Sliding guide die steel mold Part 3. intermediate pillar sets Posted 2009-04-02 2010-01-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

GB/T 23565 "die slide guide plate mold" is divided into four parts. --- Part 1. the rear pillar sets; --- Part 2. diagonal pillar sets; --- Part 3. intermediate pillar sets; --- Part 4. 4 post mold. This section GB/T 23565 Part 3. This part of the National Standardization Technical Committee mold (SAC/TC33) and focal points. This section is drafted. Guilin Institute of Electrical Science, Guilin University of Electronic Technology, Hangzhou Xiaoshan precision mold standard factory, Zhenjiang Chuanshan Mold factory Nanhai District of Foshan City, Guangdong-metal plastic mold Limited. The main drafters of this section. WENG Shi Zhen, Liao Wang Yi, Zhang Yuqin, Qi Wei root, Liang Da Zhi, Feng double. Sliding guide die steel mold Part 3. intermediate pillar sets

1 Scope

This section GB/T 23565 specifies the sliding guide plate mold die middle pillar sets of dimensions and markings. This section applies to the sliding guide die steel mold intermediate pillar sets.

2 Normative references

The following documents contain provisions which, through reference GB/T 23565 in this section constitute provisions of this section. For dated references, All subsequent amendments (excluding corrections) or revisions do not apply to this section, however, encourage an agreement under this section Parties to study the latest versions of these documents. For undated reference documents, the latest versions apply to this section. GB/T 2861.1 Part 1 die guide. slide guide pillar GB/T 2861.3 Part 3 die guides. Slide guide bushings GB/T 23562.3 lower die plate mold base part 3. middle pillar lower die GB/T 23566.3 die mold base plate on the sliding guide - Part 3. intermediate guide post mold base JB/T 8050 Die mold technical conditions

3 Dimensions

Intermediate slide guide pillar mold structure and dimensions shown in Figure 1, Table 1. 1 --- punch holder; 3 --- pillar; 2 --- lower die; 4 --- guide sleeve. Note. Allow the use of removable guide post. Figure 1 intermediate slide guide pillar sets ......
