GB/T 22524-2008 English PDF

US$169.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 22524-2008: Small-sized micro indicators
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 22524-2008	169	Add to Cart	3 days	Small-sized micro indicators	Valid

Similar standards

GB/T 40742.1   GB/T 22092   GB/T 26093   GB/T 22522   GB/T 22519   GB/T 22518

Basic data

Standard ID: GB/T 22524-2008 (GB/T22524-2008)
Description (Translated English): Small-sized micro indicators
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J42
Classification of International Standard: 17.040.30
Word Count Estimation: 7,752
Date of Issue: 2008-11-12
Date of Implementation: 2009-05-01
Quoted Standard: GB/T 17163
Regulation (derived from): National Standard Approval Announcement 2008 No.19 (Total No.132)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the small torsion comparator terms and definitions, Types and basic parameters, requirements, such as test methods and marking and packaging. This standard applies to a diameter of 8 mm clamping sleeve small torsion spring comparator (hereinafter referred to as the " comparator ").

GB/T 22524-2008: Small-sized micro indicators

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Small-sized micro indicators ICS 17.040.30 J42 National Standards of People's Republic of China Small torsion spring comparator Posted 2008-11-12 2009-05-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

The standard proposed by China Machinery Industry Federation. The standard measuring instrument by the National Standardization Technical Committee (SAC/TC132) centralized. This standard is drafted by. Harbin Measuring & Cutting Tool Group Co., Ltd. Participated in the drafting of this standard. Chengdu Tool Research Institute. The main drafters of this standard. Li Yi, Zhang Wei, Wu Ying, Jiang Zhigang. Small torsion spring comparator

1 Scope

This standard specifies the small torsion spring comparator terms and definitions, types and basic parameters, requirements, and other test methods and marking and packaging. This standard applies to the barrel diameter of 8mm small torsion spring comparator (hereinafter referred to as "comparator").

2 Normative references

The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 17163 dimensional measuring instruments - Basic terminology

3 Terms and Definitions

GB/T 17163 and established in the following terms and definitions apply to this standard. 3.1 As a torsion spring element size conversion and amplification mechanism, the linear displacement measuring rod for change pointer on the dial arc angle Displacement by dial readings of the measuring instruments. 4 Types, basic parameters 4.1 comparator scale value and range of values \u200b\u200bshown in Table 1. Table 1 compares the meter scale value and range shown in microns Dividing the value range of indication 0.2 ± 10 0.5 ± 25 1 ± 50 2 ± 100 4.2 Comparison of the type shown in Figure 1 meter illustrated illustration purposes only. ......
