GB/T 22521-2008 English PDFUS$259.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 22521-2008: Angle block gauge Status: Valid
Basic dataStandard ID: GB/T 22521-2008 (GB/T22521-2008)Description (Translated English): Angle block gauge Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: J42 Classification of International Standard: 17.040.30 Word Count Estimation: 11,199 Date of Issue: 2008-11-12 Date of Implementation: 2009-05-01 Quoted Standard: GB/T 17163; GB/T 17164 Regulation (derived from): National Standard Approval Announcement 2008 No.19 (Total No.132) Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China Summary: This standard specifies the terms and definitions angle gauge block, Types and basic parameters, requirements, test methods, such as logo and packaging. This standard applies to a certain angle between the measuring surface of the block -shaped angle gauge block. GB/T 22521-2008: Angle block gauge---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.Angle block gauge ICS 17.040.30 J42 National Standards of People's Republic of China Angle gauge block Posted 2008-11-12 2009-05-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released ForewordThe Standard Appendix A, Appendix B is an informative annex. The standard proposed by China Machinery Industry Federation. The standard measuring instrument by the National Standardization Technical Committee (SAC/TC132) centralized. This standard is drafted by. Chengdu into a tool Limited Group. Participated in the drafting of this standard. Chengdu Tool Research Institute, Harbin Measuring & Cutting Tool Group Co., Ltd. The main drafters of this standard. Bian Zhou, Ding Hua, Jiang Zhigang, Wang Qi, Song Zhangbin. Angle gauge block1 ScopeThis standard specifies the terms and definitions angle gauge block, type and basic parameters, requirements, and other test methods, marking and packaging. This standard applies to the measurement surface with a certain angle between the block-shaped angle gauge blocks.2 Normative referencesThe following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 17163 dimensional measuring instruments - Basic terminology GB/T 17164 dimensional measuring instruments - Product terms3 Terms and DefinitionsGB/T 17163, GB/T 17164 and established in the following terms and definitions apply to this standard. 3.1 The shape of a triangle or a square, adjacent to the angle between the measuring surface is ideal working angle, and the angle is accurate angle measurement tool. 3.2 Two lines by measuring the angle personally gauge block point and perpendicular to the intersection line and parallel to the two exit surfaces of each measurement reference plane The angle formed by the line. 3.3 Angle gauge block measuring surface positioned as a reference.4 Types and basic parameters4.1 Angle Block type shown in Figure 1, Fig. Illustration illustration purposes only and does not indicate a detailed structure. Millimeters Note 1. Do not use a combination of angle gauge block, or without 2.2 through holes. Note 2. Non lettering surface as the reference surface. Type a schematic diagram 1 Ⅰ type angle gauge block ......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of GB/T 22521-2008_English be delivered?Answer: Upon your order, we will start to translate GB/T 22521-2008_English as soon as possible, and keep you informed of the progress. The lead time is typically 1 ~ 3 working days. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of GB/T 22521-2008_English with my colleagues?Answer: Yes. The purchased PDF of GB/T 22521-2008_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay. |
