GB/T 22520-2008: Dial thickness gauges
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 22520-2008	279	Add to Cart	3 days	Dial thickness gauges	Valid

Similar standards

GB/T 40742.1 GB/T 22092 GB/T 26093 GB/T 22522 GB/T 22519 GB/T 22518

Basic data

Standard ID: GB/T 22520-2008 (GB/T22520-2008)
Description (Translated English): Dial thickness gauges
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J42
Classification of International Standard: 17.040.30
Word Count Estimation: 12,175
Date of Issue: 2008-11-12
Date of Implementation: 2009-05-01
Regulation (derived from): National Standard Approval Announcement 2008 No.19 (Total No.132)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the terms and definitions of the instruction sheet thickness, Types and basic parameters, requirements, test methods, such as logo and packaging. This standard applies to indexing value/resolution of 0. 1mm, 0. 01mm, 0. 002mm, 0. 001mm, is not greater than the upper limit of the measuring range of 30mm thickness instruction sheet.

GB/T 22520-2008: Dial thickness gauges

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Dial thickness gauges ICS 17.040.30 J42 National Standards of People's Republic of China Thickness indicator Posted 2008-11-12 2009-05-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

The standard proposed by China Machinery Industry Federation. The standard measuring instrument by the National Standardization Technical Committee (SAC/TC132) centralized. This standard is drafted by. Guilin Measuring & Cutting Tool Co., Ltd. Participated in the drafting of this Standard. China Institute of Metrology, Chengdu Tool Research Institute, Chengdu into a tool Limited, Guangxi measuring and testing RESEARCH Study hospital. The main drafters of this standard. Zhao Weirong, Li Qiong, Ming, Jiang Zhigang, Yuan Yongxiu, Lu Rui. Thickness indicator

1 Scope

This standard specifies the terms and definitions instruction sheet thickness, type and basic parameters, requirements, and other test methods, marking and packaging. This standard applies to the value of indexing/resolution of 0.1mm, 0.01mm, 0.002mm, 0.001mm, not more than the upper limit of the measuring range 30mm thickness indicator.

2 Normative references

The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 1219-2008 Indicators GB/T 2423.3-2006 Environmental testing for electric and electronic products Part 2. Test methods - Test Cab. Damp heat test (IEC 60068-2-78.2001, IDT) GB/T 2423.22-2002 Environmental testing for electric and electronic products Part 2. Test methods - Test N. Temperature change (IEC 60068-2-14. 1984, IDT) GB 4208 housing protection (IP Code) (GB 4208-2008, IEC 60529.2001, IDT) GB/T 17163 dimensional measuring instruments - Basic terminology GB/T 17164 dimensional measuring instruments - Product terms GB/T 17626.2-2006 Electromagnetic compatibility - Testing and measurement techniques - Electrostatic discharge immunity test GB/T 17626.3-2006 Electromagnetic compatibility - Testing and measurement techniques RFEMS test GB/T 18761-2007 Electronic Digital Indicator

3 Terms and Definitions

GB/T 17163, GB/T 17164 and established in the following terms and definitions apply to this standard. 3.1 For measuring a frame attached to the bow of the indicator measuring probe surface relative linear displacement amount (thickness) pantograph anvils measuring surface by means Table shows readings of measuring instruments; can be equipped with a fork lifting device (or under pressure unit), so that the spindle measured in surface contact with the workpiece table surface measuring anvils surface. Also known as "the thickness of the table" or "thickness gauge." Note 1. The indicator scale value/resolution of 0.1mm thickness is also known as table; division value/resolution of 0.01mm thickness, also known as dial; Dividing the value/resolution of 0.001mm, 0.002mm, also known as micrometer thickness. Note 2. The table is called with a pointer indicating pointer instruction sheet thickness, equipped with electronic digital indicator called the Digital thickness indicator. 3.2 Digital thickness indicator can be displayed properly when the value of the maximum spindle speed.

4 Types and basic parameters

Figure 4.1 indicates the type shown in Table 1 to a thickness of 4. Illustration illustration purposes only and does not indicate a detailed structure. ......
