US$399.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 22436-2008: Series of mounting dimensions for wheel hub of motorcycles and mopeds
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 22436-2008	399	Add to Cart	3 days	Series of mounting dimensions for wheel hub of motorcycles and mopeds	Valid

Similar standards

GB 24155 GB/T 24158 GB/T 24156 GB 19482 GB 15365 GB/T 22435

Basic data

Standard ID: GB/T 22436-2008 (GB/T22436-2008)
Description (Translated English): Series of mounting dimensions for wheel hub of motorcycles and mopeds
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: T80
Classification of International Standard: 43.140
Word Count Estimation: 17,154
Date of Issue: 2008-10-22
Date of Implementation: 2009-04-01
Quoted Standard: GB/T 1801; GB/T 3478.1; GB/T 3478.3; GB/T 3478.4
Regulation (derived from): National Standard Approval Announcement 2008 No.17 (Total No.130)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the motorcycles and brake drum brake drum size series, disc brake threaded hole series, wheel hub bearing bore Series, spline spline drive parameters and hub mounting dimensions series. This standard applies to all types of motorcycles and mopeds wheels (such as light -alloy wheels, -spoke wheels, spoke disc wheel) with wheels.

GB/T 22436-2008: Series of mounting dimensions for wheel hub of motorcycles and mopeds

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Series of mounting dimensions for wheel hub of motorcycles and mopeds ICS 43.140 T80 National Standards of People's Republic of China Motorcycles and mopeds hub mounting dimensions Series Posted 2008-10-22 2009-04-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard Annex A, Annex B normative appendix. This standard was proposed by the National Development and Reform Commission. This standard by the National Automotive Standardization Technical Committee. This standard is drafted by. Nanchang Motorcycle Quality Supervision, Inspection, Zhejiang Wanfeng motorcycle wheel, Ltd., Zhejiang Machinery Group has Jinfei Ltd., Chongqing Jieli Wheel Manufacturing Co., Ltd., Jiangsu Zhonglian Aluminum Co., Ltd. Participated in the drafting of this standard. Henan Tianyang alloy wheels Co., Ltd Hongdou light-alloy wheels, Wang Yongkang Industrial Co., Ltd.. The main drafters of this standard. Jiangkang Yi, Huguo You, Lu Shiping, Ge Bing stove, Zeng Ping, Xie Jianlin. Motorcycles and mopeds hub mounting dimensions Series

1 Scope

This standard specifies the motorcycles and brake drum brake drum size series, disc brake threaded hole series, wheel bearings Hole Series, spline drive spline parameters and hub dimensions series. This standard applies to all types of motorcycles and mopeds Wheels (such as light-alloy wheels, spoked wheels, disc wheel spoke) with wheels.

2 Normative references

The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 1801 limits and tolerances and mating with the choice (GB/T 1801-1999eqv ISO 1829. 1975) GB/T 3478.1 Straight cylindrical involute splines - Modules, basic rack profiles and tolerances (GB/T 3478.1-1995 eqv ISO 4156. 1981) GB/T 3478.3 Straight cylindrical involute splines - 37.5 ° pressure angle dimensions tables (GB/T 3478.3-1995 eqv ISO 4156. 1981) GB/T 3478.4 Straight cylindrical involute splines - 45 ° pressure angle dimensions tables (GB/T 3478.4-1995eqv ISO 4156. 1981)

3 Terms and Definitions

The following terms and definitions apply to this standard. 3.1 The intermediate portion of the wheel. Install axle parts, brakes, transmission and other on wheels. 3.2 Hub during assembly, there is coordination with other parts of the portion size.

4 Classification and form the hub

4.1 hub classification. Motorcycle wheel brake according to type, into the hub drum brake, disc brake two types. 4.2 drum brake hub, divided into four kinds of forms. a) drum brake front wheel dimensions series; b) drum brake rear wheel hub (sprocket drive mounted buffer block) dimensions series; c) drum brake rear wheel hub (loading buffer sets sprocket drives) Installation dimensions Series; d) drum brake rear wheel hub (splined drive) Mounting dimensions series. 4.3 disc brake drum, is divided into two forms. a) front wheel disc brake mounting dimensions Series; b) disc brake rear wheel hub mounting dimensions Series. ......
