GB/T 22193-2008 English PDF

US$94.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 22193-2008: Electrical installations in ships -- Equipment -- Semiconductor convertors
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 22193-2008	94	Add to Cart	3 days	Electrical installations in ships -- Equipment -- Semiconductor convertors	Valid

Similar standards

GB/T 22190   GB/T 22191   GB/T 22189

Basic data

Standard ID: GB/T 22193-2008 (GB/T22193-2008)
Description (Translated English): Electrical installations in ships -- Equipment -- Semiconductor convertors
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: U60
Classification of International Standard: 47.020.60
Word Count Estimation: 5,581
Date of Issue: 2008-07-16
Date of Implementation: 2009-04-01
Quoted Standard: IEC 60146; IEC 60146A; IEC 60146-2; IEC 60146-3; IEC 60119
Adopted Standard: IEC 60092-304-1995, IDT
Regulation (derived from): National Standard Approval Announcement 2008 No.12 (Total No.125)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard applies to the use of such diodes, reverse blocking three-terminal thyristor semiconductor rectifier element museum ship static inverter. Inverter can be AC ??to DC, DC to AC, DC to DC and AC to AC.

GB/T 22193-2008: Electrical installations in ships -- Equipment -- Semiconductor convertors

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Electrical installations in ships. Equipment. Semiconductor convertors ICS 47.020.60 U60 National Standards of People's Republic of China GB/T 22193-2008/IEC 60092-304.1995 Marine Electrical Equipment Equipment Semiconductor convertors (IEC 60092-304.1995, Electricalinstalationsinships- Part 304. Equipment-Semiconductorconvertors, IDT) Posted 2008-07-16 2009-04-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard is identical with IEC 60092-304.1995 "Electrical installations in ships - Part 304. Equipment - Semiconductor convertors" (in English). This standard is equivalent translation IEC 60092-304.1995. For ease of use, this standard made the following editorial changes. --- "This International Standard" be replaced by "this standard"; "." --- With a decimal point instead of a comma as the decimal point, ""; --- Delete international standards preface, introduction; --- Of expression in accordance with the provisions of GB/T 1.1-2000 made changes. The standard proposed by China State Shipbuilding Corporation. This standard by the National Standardization Technical Committee boat ocean. This standard was drafted. Technical and Economic Research Institute of China Shipbuilding Industry. The main drafters of this standard. Li Dayi, Yan Ping. GB/T 22193-2008/IEC 60092-304.1995 Marine Electrical Equipment Equipment Semiconductor convertors

1 Scope

This standard applies to the use of such diodes, and reverse blocking three-terminal thyristor semiconductor rectifier element marine static converter. Converter can So the AC to DC and DC-AC, DC-DC and AC-AC.

2 General requirements

Semiconductor convertors shall comply with the relevant provisions of the following publications, and should be in accordance with this standard and IEC 60092 Parts of other additional Provisions. IEC 60146 Semiconductor converters (attached 1st Amendment) Semiconductor convertors IEC 60146A 1st Addition. Chapter 7. converter equipment and components mark Semiconductor convertors IEC 60146-2 Part 2. Semiconductor self-commutated converter Semiconductor convertors IEC 60146-3 Part 3. Semiconductor direct DC converter (chopper direct converter) IEC 60119 polycrystalline semiconductor rectifier stack and rectifier equipment Recommendations

3 cooling arrangement

3.1 Semiconductor convertors is preferably a dry air-cooled. 3.2 immersion semiconductor converters should be sealed. If ventilation measures, it should be equipped with appropriate desiccant. 3.3 pairs immersion semiconductor converters should consider configuring a liquid over-temperature alarm and pneumatic protection device. NOTE. Installation Notes See IEC 60092-401 "Installation and test of completed" in Chapter 16.

4 selenium rectifying elements

Even small amounts of mercury can damage the anti-fogging agent type selenium rectifying elements, and therefore does not allow the use of mercury selenium rectifying element type anti-fogging agent.

5 accessibility

Semiconductor convertors group or member should enable mounting a semiconductor device is removed without having to break up the entire converter.

6 Conditions

6.1 Semiconductor convertors conditions of use shall apply IEC 60092-101 "Definitions and general requirements" provisions (such as ambient temperature). 6.2 If the converter equipment needs to be dried to facilitate maintenance and inspection, then heating should be particularly careful to prevent it from exceeding the maximum allowable temperature Temperature rise limit.

7 Applications

7.1 Forced cooling Such as the use of forced cooling circuits should be designed to maintain effective only when cooled, variable flow reactor to power up or remain charged. 7.2 interaction with the power supply or the load system 7.2.1 Precautions should be taken to prevent over-current or load due to a power system disturbance caused by or overvoltage (if the load operation can be regenerated, further It should include regenerative power) harmful effects on the converter equipment. GB/T 22193-2008/IEC 60092-304.1995 ......
