GB/T 21684-2008 English PDF

US$294.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 21684-2008: Woodworking machines -- Two-, three- and four-side moulding machines -- Nomenclature and acceptance conditions
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 21684-2008	294	Add to Cart	3 days	Woodworking machines -- Two-, three- and four-side moulding machines -- Nomenclature and acceptance conditions	Valid

Similar standards

GB/T 40337   JB/T 13910.3   GB/T 8118   GB/T 21683   GB/T 21685   GB/T 21680

Basic data

Standard ID: GB/T 21684-2008 (GB/T21684-2008)
Description (Translated English): Woodworking machines -- Two-, three- and four-side moulding machines -- Nomenclature and acceptance conditions
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J65
Classification of International Standard: 79.120.10
Word Count Estimation: 15,148
Date of Issue: 2008-04-22
Date of Implementation: 2008-10-01
Quoted Standard: GB/T 17421.1-1998
Adopted Standard: ISO 7947-1985, IDT
Regulation (derived from): National Standard Approval Announcement 2008 No.6 (Total No.119)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the two, three, surrounded by milling the term of each part. While referring to GB/T 17421. 1-1998, provides for inspection of geometric precision machine tools and precision inspection work, and given the appropriate allowance for general purposes, ordinary precision machine tools. This standard only requires that the machine accuracy test, the test does not apply to the operation of the machine. Does not apply to the characteristics of the machine test, these tests are generally advised to test for accuracy in front of the machine.

GB/T 21684-2008: Woodworking machines -- Two-, three- and four-side moulding machines -- Nomenclature and acceptance conditions

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Woodworking machines. Two-, three- and four-side moulding machines. Nomenclature and acceptance conditions ICS 79.120.10 J65 National Standards of People's Republic of China GB/T 21684-2008/ISO 7947. 1985 Woodworking machines two, three, four milling machine Nomenclature and (ISO 7947. 1985, IDT) Posted 2008-04-22 2008-10-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard is identical with ISO 7947. 1985 "Woodworking machines two, three, four milling Nomenclature and acceptance conditions" (in English). For ease of use, this standard made the following editorial changes. --- "This International Standard" be replaced by "this standard"; "." --- With a decimal point instead of a comma as the decimal point, ""; --- Remove the French terminology and Appendix A; --- Deleted international standards foreword; --- Increasing the normative references of Lead; --- Other international standard ISO 7947 referenced with the international standard has been adopted as the standard instead of the corresponding country. The standard proposed by China Machinery Industry Federation. This standard is under the jurisdiction of the National Woodworking Machine and Tool Standardization Technical Committee. This standard drafting unit. Woodworking Machine Tool Research Institute, Fuzhou, Fujian Shaowu Zhen Machinery Manufacturing Co., Ltd., Shunde District of Foshan City, Guangdong Province, Rui Asia Machinery Co., Ltd. Drafters of this standard. Xiaoxiao Hui, Yang Hua, Zhou Hua standard. GB/T 21684-2008/ISO 7947. 1985 Woodworking machines two, three, four milling machine Nomenclature and

1 Scope

This standard specifies two, three, four milling machine (hereinafter referred to as the machine) The term of each part, while referring to GB/T 17421.1-1998, Regulation Geometric accuracy of machines set up and test the accuracy of inspection work, and given the appropriate tolerances for general use, general precision machine tools. This standard only requires that the machine accuracy test, does not apply to running test machine (such as vibration, unusual noise, reptiles and other parts of the seized Experience), does not apply to machine features test (such as speed, feed rate, etc.), these tests are generally advised to test for accuracy in front of the machine.

2 Normative references

The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 17421.1-1998 Test code for machine tools - Part 1. under no-load or finishing conditions Geometric accuracy of machines (Eqv ISO 230-1.1996)

3 Short Description

3.1 standard in all dimensions and tolerances are in millimeters. 3.2 This standard should be used with reference to GB/T 17421.1-1998, especially the test installation, spindles and other moving parts of the machine before Temperature, and test methods. Gage error should not exceed 1/3 of the tolerance of the subject project. 3.3 standard geometric accuracy test order is given by the machine tool assembly sequence, which is not limited by the order of the actual inspection time. In order to facilitate Installation and testing of the seizure, inspection in any order. The standard test given project must be itemized or not always be able to test 3.4 test machine. 3.5 Test Project selection is determined by the user, and in agreement with the manufacturer, clearly defined at the time of ordering the machine. Selected test Projects are often of interest about the performance of your machine. 3.6 movement in the direction of the workpiece called longitudinal movement. 3.7 When determining the minimum conversion time measuring range is different tolerances specified in this standard on measuring range should be considered a value of 0.01mm tolerance (See GB/T 17421.1-19982.3.1.1).

4 Terms

Tools - Terminology Figure 1, Figure 2 and Table 1. GB/T 21684-2008/ISO 7947. 1985 ......
