GB/T 20441.7-2025: Electroacoustics - Measurement microphones - Part 7: Values for the difference between free-field and pressure sensitivity levels of laboratory standard microphones
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 20441.7-2025	274	Add to Cart	3 days	Electroacoustics - Measurement microphones - Part 7: Values for the difference between free-field and pressure sensitivity levels of laboratory standard microphones	Valid

Similar standards

GB/T 20247   GB/T 19889.1   GB/T 19890   GB/T 20441.8   GB/T 20441.2   GB/T 20441.6

Basic data

Standard ID: GB/T 20441.7-2025 (GB/T20441.7-2025)
Description (Translated English): Electroacoustics - Measurement microphones - Part 7: Values for the difference between free-field and pressure sensitivity levels of laboratory standard microphones
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: A59
Classification of International Standard: 17.140.50
Word Count Estimation: 13,156
Date of Issue: 2025-05-30
Date of Implementation: 2025-05-30
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 20441.7-2025: Electroacoustics - Measurement microphones - Part 7: Values for the difference between free-field and pressure sensitivity levels of laboratory standard microphones

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 17.140.50 CCSA59 National Standard of the People's Republic of China Electroacoustic Measurement Microphones Part 7.Free-field laboratory standard microphones Difference between sensitivity level and sound pressure sensitivity level Published on 2025-05-30 Implemented on 2025-05-30 State Administration for Market Regulation The National Standardization Administration issued

Table of contents

Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Reference environmental conditions 2 5 Background Information 2 6 Difference between free field sensitivity level and sound pressure sensitivity level 2 6.1 Overview 2 6.2 Data Source 2 6.3 Expression for the difference between the free-field sensitivity level and the sound pressure sensitivity level 2 6.4 Calculation of uncertainty in free-field sensitivity level 3 Appendix A (Informative) Source Data 5 Appendix B (Informative) Acknowledgements 6 Appendix C (Informative) Historical Data 7 References 8

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting. This document is Part 7 of GB/T 20441.GB/T 20441 has been published in the following parts. --- Microphones for electroacoustic measurements Part 1.Specifications for laboratory standard microphones; --- Microphones for electroacoustic measurements Part 2.Primary method for sound pressure calibration of laboratory standard microphones using the reciprocity technique; --- Microphones for electroacoustic measurements Part 3.Primary levels for free-field calibration of laboratory standard microphones using the reciprocity technique method; --- Measurement microphones Part 4.Specifications for working standard microphones; --- Microphones for electroacoustic measurements. Part 5.Comparison method for sound pressure calibration of working standard microphones; --- Microphones for electroacoustic measurements Part 6.Electrostatic actuators for determining frequency response; --- Microphones for electroacoustic measurements Part 7.Free-field sensitivity levels and sound pressure sensitivity levels of laboratory standard microphones The difference of --- Microphones for electroacoustic measurements Part 8.Comparison method for determining the free-field sensitivity of working standard microphones. This document is equivalent to IEC TS61094-7.2006 "Measurement microphones Part 7.Free-field sensitivity of laboratory standard microphones" The file type was adjusted from IEC technical specifications to my country's national standards. The following minimal editorial changes were made to this document. --- To be consistent with the existing series of standards, the standard name is changed to "Electroacoustic Measurement Microphones Part 7.Laboratory Standard Microphones". The difference between the free field sensitivity level and the sound pressure sensitivity level of the speaker"; ---Added references. Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document is proposed and coordinated by the National Electroacoustics Standardization Technical Committee (SAC/TC23). This document was drafted by. Institute of Acoustics, Chinese Academy of Sciences, Hunan Acoustic Instrument Measurement and Control Technology Co., Ltd., China Institute of Metrology, The Third Research Institute of China Electronics Technology Group Corporation, Hangzhou Aihua Instrument Co., Ltd., Shanghai Institute of Metrology and Testing Technology, State-owned Hongsheng Instrument Jiaxing Branch of Material Factory, Shenzhen Institute of Metrology and Quality Inspection, and Zhejiang Institute of Metrology Science. The main drafters of this document are. Li Xiaodong, Liu Xiangheng, Sang Jinqiu, Niu Feng, Wu Xin, Zhang Shaodong, Deng Zheng, Shu Guohua, Zhang Guoqing and Qiu Jianmin.

Introduction

The measuring microphone is a microphone with electroacoustic performance and mechanical structure that meets the specified requirements and is used in sound pressure measurement standards, sound measurement instruments and automatic sound-based In the control system, an electroacoustic transducer converts acoustic oscillations into electrical signals. The laboratory standard microphone is mainly used to establish the sound pressure level. Measurement standard; working standard microphone is mainly used as an important part of practical measuring instruments and is widely used in various acoustic measurement fields. It is widely used in the measurement of environmental noise, machine noise and workplace noise, as well as sound detection under some special conditions. It is also used for electroacoustic equipment and electrical Testing of acoustic device performance characteristics; transfer standard microphones are used to achieve the sound pressure difference between laboratory standard microphones and working standard microphones. Value passing. GB/T 20441 "Electroacoustic Measurement Microphones" is intended to define laboratory standard microphones, transfer standard microphones and working standard microphones. The performance specifications and structural requirements of the microphones are given, and the calibration methods for the sound pressure sensitivity and free field sensitivity of these measuring microphones are given. Due to different purposes, GB/T 20441 is intended to consist of 10 parts. --- Part 1.Laboratory standard microphone specification. The purpose is to determine the electroacoustic performance and mechanical dimensions of laboratory standard microphones. to standardize the calibration method and achieve comparison between laboratories. --- Part 2.Primary method for sound pressure calibration of laboratory standard microphones using the reciprocity technique. The purpose is to establish a reproducible and The basis for accurate sound pressure measurements. --- Part 3.Primary method for free-field calibration of laboratory standard microphones using the reciprocity technique. This provides the basis for reproducible and accurate sound pressure measurements under these conditions. --- Part 4.Specification for working standard microphones. The purpose is to determine the electroacoustic performance and mechanical dimensions of working standard microphones so that Used as transfer standards in acoustic measurements or as electroacoustic transducers in practical sound measurement systems. --- Part 5.Comparison method for sound pressure calibration of working standard microphones. The purpose is to compare with calibrated standard microphones Determine the sound pressure sensitivity of the working standard microphone. --- Part 6.Electrostatic actuators for determining frequency response. The purpose is to determine the performance and structure of electrostatic actuators to provide A convenient method for determining the sensitivity and frequency response of measurement microphones. --- Part 7.The difference between the free-field sensitivity level and the sound pressure sensitivity level of the laboratory standard microphone. These differences are used to determine the free-field sensitivity level of the laboratory standard microphone from the known sound pressure sensitivity level. --- Part 8.Comparison method for determining the free-field sensitivity of a working standard microphone. The purpose is to compare the free-field sensitivity of a working standard microphone with a calibrated standard microphone. The free-field sensitivity of the working standard microphone is determined by comparison with the --- Part 9.Specification for transfer standard microphones. The purpose is to determine the electroacoustic characteristics and mechanical dimensions of transfer standard microphones so that Used as transfer standards in acoustic measurements and for performance evaluation and calibration of acoustic calibrators and comparison couplers. --- Part 10.Low-frequency absolute sound pressure calibration of microphones using computable pistonphones. The purpose is to provide The quantity provides a reproducible and accurate measurement standard. Since the sensitivity of the microphone varies under different sound field conditions, this difference will affect the accuracy of the measurement results. This difference must be accurately measured and standardized. This document provides key data for accurately measuring the sensitivity of microphones under different environmental conditions. and calculation methods. Electroacoustic Measurement Microphones Part 7.Free-field laboratory standard microphones Difference between sensitivity level and sound pressure sensitivity level

1 Scope

This document. --- A polynomial function is given by least square method based on the data of several laboratories to obtain the IEC 61094-1 standard. The difference between the free-field sensitivity level and the sound pressure sensitivity level of a given laboratory standard microphone; --- By adding these differences to the sound pressure sensitivity level, it is possible to determine the laboratory standard sound transmission level at zero incidence in air. The free-field sensitivity level of the device; --- Tabular values of polynomial functions are given for a range of frequencies and temperatures; --- This allows the use of these data when a suitable free-field calibration is not possible.

2 Normative references

The contents of the following documents constitute essential clauses of this document through normative references in this document. For referenced documents without a date, only the version corresponding to that date applies to this document; for referenced documents without a date, the latest version (including all amendments) applies to This document. GB/T 20441.2-2018 Electroacoustic measurement microphones Part 2.Acoustic measurement of laboratory standard microphones using the reciprocity technique Primary method for pressure calibration (IEC 61094-2.2009, IDT) Note. There is no technical difference between the referenced content of GB/T 20441.2-2018 and the referenced content of IEC 61094-2.1992. GB/T 20441.3-2010 Electroacoustic measurement microphones Part 3.Self-diagnosis of laboratory standard microphones using the reciprocity technique Primary method by field calibration (IEC 61094-3.1995, IDT) Note. GB/T 20441.1-2010 Electroacoustic Measurement Microphones Part 1.Specifications for Laboratory Standard Microphones (IEC 61094-1.2000, IDT)

3 Terms and definitions

The following terms and definitions defined in IEC 61094-1, GB/T 20441.2-2018 and GB/T 20441.3-2010 apply to This document. 3.1 zero-degreesincidence For normally incident sound waves, the direction is perpendicular to the diaphragm of the microphone. ......
