GB/T 20063.9-2006: Graphical symbols for diagrams -- Part 9: Pumps, compressors and fans
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 20063.9-2006	234	Add to Cart	3 days	Graphical symbols for diagrams -- Part 9: Pumps, compressors and fans	Valid

Similar standards

GB/T 19799.1   GB/T 19802   GB/T 19943   GB/T 19799.3   GB/T 20063.15   GB/T 20063.13

Basic data

Standard ID: GB/T 20063.9-2006 (GB/T20063.9-2006)
Description (Translated English): Graphical symbols for diagrams -- Part 9: Pumps, compressors and fans
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J04
Classification of International Standard: 01.080
Word Count Estimation: 12,166
Date of Issue: 2006-02-05
Date of Implementation: 2006-09-01
Quoted Standard: GB/T 16901.1-1997; GB/T 17446; GB/T 20063.1; GB/T 20063.2; GB/T 20063.10
Adopted Standard: ISO 14617-9-2002, IDT
Regulation (derived from): Announcement of Newly Approved National Standards 2006 No. 2 (No. 89 overall)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the main road in the transfer tube for pumps, compressors and blowers graphic symbols in the sketch. Here mainly refers to pumps and compressors for the energy transfer. For example, in hydraulic power systems, see GB/T 20063. 10. Sketch creation and use of graphic symbols basic rules, see GB/T 16901. 1-1997. On the identification of patterns used in the creation of graphical symbols registration number and use of information, and these symbols represent, application rules, see GB/T 20063. 1.
