US$369.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 19920-2020: Container buttress fitting for ships
Status: Valid

GB/T 19920: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 19920-2020	369	Add to Cart	4 days	Container buttress fitting for ships	Valid
GB/T 19920-2005	639	Add to Cart	3 days	Container buttress fitting for ships	Obsolete

Similar standards

GB/T 11578 GB/T 42053

Basic data

Standard ID: GB/T 19920-2020 (GB/T19920-2020)
Description (Translated English): Container buttress fitting for ships
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: U24
Classification of International Standard: 47.020.50
Word Count Estimation: 20,228
Date of Issue: 2020-12-14
Date of Implementation: 2021-07-01
Older Standard (superseded by this standard): GB/T 19920-2005
Quoted Standard: GB/T 699; GB/T 709; GB/T 712; GB/T 1591; GB/T 3077; GB/T 6414; GB/T 8923.1; GB/T 12362; GB/T 13912; ISO 17905-2015
Regulation (derived from): National Standard Announcement No. 28 of 2020
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration
Summary: This standard specifies the classification, parameters, main dimensions and marking examples, requirements, test methods, inspection rules, marking, packaging, transportation and storage of marine container supports (hereinafter referred to as supports). This standard applies to the design, manufacture and acceptance of container supports in the cabins of multi-purpose container ships.

GB/T 19920-2020: Container buttress fitting for ships

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Ship container support) ICS 47:020:50 U24 National Standards of People's Republic of China Replace GB/T 19920-2005 Ship container support 2020-12-14 release 2021-07-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Preface Ⅲ 1 Scope 1 2 Normative references 1 3 Classification, parameters and main dimensions and marking examples 1 4 Material 13 5 Requirements 14 6 Test method 14 7 Inspection rules 16 8 Sign 17 9 Packaging, storage and transportation 17

Foreword

This standard was drafted in accordance with the rules given in GB/T 1:1-2009: This standard replaces GB/T 19920-2005 "Marine Container Support": This standard is compared with GB/T 19920-2005, except for editing In addition to the changes, the main technical changes are as follows: ---Modified normative reference documents, CB/Z343 was revised to GB/T 13912, and GB/T 3077, GB/T 709, GB/T 8923:1, deleted CB/Z343, GB/T 13306, GB 9969:1 (see Chapter 2, Chapter 2 of the:2005 edition); --- Modified the classification, name, type and code of the support (see 3:1, 3:1 in the:2005 edition); ---Added suspension intermediate pressure support, DM-83:5; added long support seat, ZI series (see 3:2:1); --- Added CT-32:5 compression support (see 3:2:1) and FT-32:5 tension and compression support (see 3:2:1); --- Deleted AT, AM wooden wedge support (see 3:2:1 of the:2005 edition); --- Deleted the FT-50, FT-65 rack top tension and compression support (see the:2005 edition of 3:3:1); --- Deleted ET, EM disc tension and compression support and HM eye plate intermediate tension and compression support (see 3:3:1 of the:2005 edition); --- Deleted the ZH-105 eye plate middle tension and compression support seat (see 3:4:1 in the:2005 edition); ---Modified the product dimensions (see Table 2, Figure 1~Figure 21, Table 2~Table 26, Figure 1~Figure 22 of the:2005 edition); ---Increase the size and tolerance requirements (see 5:2); modify the materials of the main parts of the support (table 3, table 4, table 5,:2005 edition Table 27), modify the hot-dip galvanizing process requirements (see 5:3:1, 4:6 in the:2005 edition), and increase the rust removal level before surface painting Requirements and paint thickness requirements (see 5:3:2); ---Modified the "test methods" and "inspection rules": added strength test methods (see 6:4); modified the number of type tests (see 7:2:3, In the:2005 edition of 6:2:3), etc:, the distinction between group A and group B of the factory inspection was deleted and the subsequent related content was modified (see:2005 Version 6:3); ---Modified the content of the support mark (see Chapter 8, 7:1 of the:2005 edition); ---Deleted the requirements of the support instruction manual (see 7:2 of the:2005 edition): This standard was proposed and managed by the National Marine Outfitting Standardization Technical Committee (SAC/TC129): This standard was drafted by: Jiangnan Shipbuilding (Group) Co:, Ltd:, Kunshan Jihai Industrial Co:, Ltd: The main drafters of this standard: Song Kailei, Sun Jiaxiu, Shen Jiabin: The previous versions of the standard replaced by this standard are as follows: ---GB/T 19920-2005: Ship container support

1 Scope

This standard specifies the classification, parameters, main dimensions and marking examples, requirements, and testing of marine container supports (hereinafter referred to as supports) Inspection methods, inspection rules, signs, packaging, transportation and storage: This standard applies to the design, manufacture and acceptance of container supports in the cabins of multi-purpose container ships:

2 Normative references

The following documents are indispensable for the application of this document: For dated reference documents, only the dated version applies to this article Pieces: For undated references, the latest version (including all amendments) applies to this document: GB/T 699 High-quality carbon structural steel GB/T 709 Hot-rolled steel plate and strip size, shape, weight and allowable deviation GB/T 712 Structural steel for ships and marine engineering GB/T 1591 Low-alloy high-strength structural steel GB/T 3077 Alloy structural steel GB/T 6414 Casting dimensional tolerance, geometric tolerance and machining allowance GB/T 8923:1 Visual assessment of surface cleanliness of steel surface treatment before coating-Part 1: Uncoated steel The corrosion grade and treatment grade of the surface and the steel surface after the original coating has been completely removed GB/T 12362 steel die forging tolerance and machining allowance GB/T 13912 Technical requirements and test methods for hot-dip galvanizing of steel parts with metal covering ISO 17905:2015 Ships and marine technology container securing device installation, inspection and maintenance (Shipsandmarine technology-Instalation, inspectionandmaintenanceofcontainersecuringdevicesforships) 3 Classification, parameters and main dimensions and marking examples 3:1 Classification The classification of supports is shown in Table 1: Table 1 Classification of supports Category name code type Moving parts support BT disc top pressure type BM disc intermediate pressure type CT tooth adjustment top pressure type CM gear adjustment intermediate pressure type DM suspension intermediate pressure type FT tooth adjustment top tension and compression FM gear adjustment intermediate tension and compression type GT screw adjustment top tension and compression type GM spiral adjustment middle tension and compression type ......
