GB/T 17465.6-2022: Appliance couplers for household and similar general purposes - Part 3: Standard sheets and gauges

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Appliance couplers for household and similar general purposes - Part 3.Standard sheets and gauges ICS 29.120.30 CCSK65 National Standards of People's Republic of China Couplers for household and similar appliances Part 3.Standard loose-leaf and gauges (IEC 60320-3.2018,MOD) Published on 2022-07-11 2023-02-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration directory Foreword V Introduction VII 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 General Requirements 1 5 Standard leaflet for appliance couplers5 6 Gauge 5 Standard loose-leaf C1 36 Standard loose leaf C2 37 Standard loose leaf C5 38 Standard loose leaf C6 39 Standard loose leaf C7 40 Standard loose-leaf C7A 41 Standard loose leaf C8 42 Standard loose-leaf C8A 43 Standard loose leaf C8B 44 Standard loose leaf C8C 45 Standard loose leaf C9 46 Standard loose leaf C10 47 Standard loose leaf C13 48 Standard loose leaf C14 49 Standard loose leaf C15 50 Standard loose-leaf C15A 51 Standard loose leaf C16 52 Standard loose-leaf C16A 53 Standard loose-leaf C17 54 Standard loose leaf C18 55 Standard loose-leaf C19 56 Standard loose-leaf C20 57 Standard loose-leaf C21 58 Standard loose-leaf C22 59 Standard loose leaf C23 60 Standard loose leaf C24 61 Standard loose leaf C25 62 Standard Leaflet A 63 Standard loose-leaf B 64 Standard loose-leaf C 65 Standard loose-leaf D 66 Standard Leaflet E 67 Standard loose-leaf F 68 Standard loose-leaf G 69 Standard loose-leaf H 70 Standard Leaflet I 71 Standard loose-leaf J 72 Standard loose-leaf K 73 Standard loose leaf L 74 Standard loose-leaf IP-A 75 Standard loose-leaf IP-B 76 Standard loose-leaf IP-C 77 Standard loose-leaf IP-D 78 Reference 79 Fig. 1 Position of the switch cam 9 Figure 2 General gauge 9 for checking compliance with standard loose-leaf C1 connectors Figure 3 General gauge 10 for checking compliance with standard loose-leaf C5 connectors Figure 4 General gauge 10 for checking compliance with standard loose-leaf C7 connectors Figure 5 General gauge 11 for checking compliance of side entry type connectors with standard leaflet C7 Figure 6 Stop gauge 12 for checking compliance with standard loose-leaf C1 connectors Figure 7 Stop gauge 12 for checking compliance with standard loose-leaf C1, C5 and C7 connectors Figure 8 Stop gauge 13 for checking compliance with standard loose-leaf C1 and C7 connectors Fig. 9 Test piece 13 for checking the resistance to deformation Figure 10 Stop gauge for checking compliance with standard loose-leaf C8, C8A and C8B appliance inlets 14 Figure 11 General gauge 14 for checking compliance with standard loose-leaf C9 connectors Figure 12 Stop gauge 15 for checking compliance with standard loose-leaf C9 connectors Figure 13 General gauge 15 for checking compliance with standard loose-leaf C10 appliance input sockets Figure 14 General gauge 16 for checking compliance with standard loose-leaf C13 connectors Figure 15 Stop gauge for checking compliance with standard loose-leaf C13 and C17 connectors 16 Figure 16 General gauge 17 for checking compliance with standard loose-leaf C14, C16 and C18 appliance inlets Figure 17 General gauge 17 for checking compliance with standard loose-leaf C15 connectors Figure 18 General gauge 18 for checking compliance with standard loose-leaf C17 connectors Figure 19 General gauge 19 for checking compliance with standard loose-leaf C19 connectors Figure 20 General gauge 20 for checking compliance with standard loose-leaf C20 and C24 appliance inlets Figure 21 General gauge 21 for checking compliance with standard loose-leaf C21 connectors Figure 22 General gauge 22 for checking compliance with standard loose-leaf C22 appliance inlets Figure 23 General gauge 23 for checking compliance with standard loose-leaf C23 connectors Figure 24 Stop gauge for checking compliance with standard loose-leaf C13, C15 and C17 connectors 24 Figure 25 General gauge 25 for checking compliance with standard loose-leaf C15A connectors Figure 26 General gauge for checking compliance with standard loose-leaf C16A appliance input sockets 26 Figure 27 General gauge for checking compliance with standard loose-leaf F appliance outlet sockets 27 Figure 28 General gauge for checking compliance with standard loose-leaf H appliance outlet sockets 28 Figure 29 General gauge for checking compliance with standard loose-leaf J appliance outlet sockets 29 Figure 30 General gauge for checking compliance with standard loose-leaf L appliance outlet sockets 30 Figure 31 Gauge for checking the first contact point 31 Figure 32 General gauge 32 for checking compliance with standard loose-leaf IP-A connectors Figure 33 Primary and secondary general gauges for checking compliance with standard loose-leaf IP-B appliance input socket/plug connectors 33 Figure 34 General gauge for checking compliance with standard loose-leaf IP-C connectors 34 Figure 35 Primary and secondary general gauges for checking compliance with standard loose-leaf IP-D appliance input socket/plug connectors 35 Table 1 Appliance couplers C1 to C24---standard leaflet 2 Table 2 Appliance couplers A to L---standard leaflet 4 Table 3 Appliance couplers IP-A to IP-D---standard leaflet 5 Table 4 Dimensions of contact and non-contact gauges 31

foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules of Standardization Documents" drafted. This document is part 3 of GB/T 17465 "Couplers for Household and Similar Appliances". GB/T 17465 has issued the following part. --- Part 1.General Requirements (GB/T 17465.1); --- Part 2.Appliance couplers with protection levels higher than IPX0 (GB/T 17465.3); --- Part 2-4.Couplers engaged by the weight of appliances (GB/T 17465.4); --- Part 2-1.Sewing machine coupler (GB/T 17465.5); --- Part 3.Standard loose-leaf and gauge (GB/T 17465.6). This document is modified to adopt IEC 60320-3.2018 "Couplers for household and similar appliances - Part 3.Standard loose-leaf and gauges". The technical differences between this document and IEC 60320-3.2018 and their reasons are as follows. --- Added "This document specifies the dimensions and gauges of two-pole and two-pole appliance couplers with grounding contacts.", to comply with Requirements of GB/T 1.1 (see Chapter 1); --- Replaced IEC 60320-1 with the normatively cited GB/T 17465.1-2022, and the degree of consistency between the two documents is revised To adapt to our technical conditions and provide operability (see Chapter 3, 5.1 and standard leaflet C7); ---According to the actual application of our products, the polarized connector (standard leaflet C7A) and the polarized appliance input have been added Socket (standard loose-leaf C8C). Polarized connectors and polarized appliance input sockets improve product safety, according to The actual application of polarized connectors and polarized appliance input sockets in my country, this document adds standard loose-leaf C7A) and standard leaflet C8C). The following editorial changes have been made to this document. ---In the first sentence of 6.32 of IEC 60320-3.2018, the "appliance outlet socket" is omitted in "acting on the connector", this document is added as "Applies to connectors and appliance outlet sockets"; ---In the first sentence of 6.34 of IEC 60320-3.2018, "the connector shall be able to be connected", the "appliance input socket" is omitted, this document is added as "shall be capable of feeding the appliance into a socket/plug connector"; ---In the first sentence of 6.36 of IEC 60320-3.2018, "the connector shall be able to be connected", the "appliance input socket" is omitted, this document is added as "shall be capable of feeding the appliance into a socket/plug connector"; --- Replaced ISO 1101 with GB/T 1182 cited for information (see 5.1); --- Replaced ISO 286-1 (see 5.1) with GB/T 1800.1 cited for information. Please note that some content of this document may be patented. The issuing agency of this document assumes no responsibility for identifying patents. This document is proposed by China Electrical Equipment Industry Association. This document is under the jurisdiction of the National Standardization Technical Committee for Electrical Accessories (SAC/TC67). This document is drafted by. Weikai Testing Technology Co., Ltd., Zhejiang Zhongxun Electronics Co., Ltd., Hangzhou Hongyan Electric Co., Ltd., Jiangsu Tongtong Leading Technology Co., Ltd., Xiamen Yangmai Electric Co., Ltd., Guangdong Liansheng Conduction Technology Co., Ltd., Shenzhen Smart Security Industry Association, Bull Group Co., Ltd., Zhejiang Youmo Technology Co., Ltd., Guangdong Liying Intelligent Technology Co., Ltd., Zhongshan Shixin Electric Co., Ltd., Feihualing Co., Ltd., Zhejiang Yuehua Telecommunications Co., Ltd., China Electric Appliance Research Institute Co., Ltd., Anhui Hengchuangkai Electric Co., Ltd. Technology Co., Ltd., China Quality Certification Center, South China Laboratory of China Quality Certification Center, Shaanxi Teny Electronics Co., Ltd., Guangdong Kangxinxin Materials Co., Ltd., Shandong Yaosi Intelligent Technology Co., Ltd., Yiwu Jianghao Plastic Technology Co., Ltd., Ningbo Ouzhi Electrical Technology Co., Ltd., Guangdong Quanwei Industrial Technology Co., Ltd., Shaanxi Juzhong Zhide Electronic Technology Co., Ltd., Zhejiang Rujing Technology Co., Ltd., Shaanxi Fahida Electric Co., Ltd. Subsidiary Co., Ltd., Guangdong Yanfei Technology Co., Ltd. The main drafters of this document. Li Zhongyao, Qu Hailiang, Wang Fengqin, Cai Sufeng, Sun Ting, Chen Geng, Qiu Hong, Zhang Yi, Cai Yingfeng, Yang Lingling, Ding Chunyan, Zhang Jilan, Wu Zhigang, Wang Sheng, Shu Meijun, Liu Shuiqiang, Liu Yue, Ke Cilong, Zhang Weijun, Cai Jun, Quan Yongde, Xiang Dongmei, Li Ji, Xu Yueping, Wang Zhewei, Li Shouying, Xiao Benchong, Huang Qiongfang, Liu Heping.

Introduction

GB/T 17465 aims to standardize the technical requirements for household and similar appliance couplers, and to unify household and similar appliance couplers The type and size of the product to ensure the safety and interchangeability of the product, it is intended to be composed of the following parts. --- Part 1.General requirements (GB/T 17465.1). The purpose is to specify the protection against electric shock of couplers for household and similar appliances protection, structure, mechanical properties, electrical properties and other technical requirements. --- Part 2.Appliance couplers with a degree of protection higher than IPX0 (GB/T 17465.3). The purpose is to specify a degree of protection higher than The technical requirements for protection against electric shock, structure, mechanical properties, electrical properties, etc., as well as dimensions and gauges of IPX0 appliance couplers. --- Part 2-4.Couplers engaged by the weight of the appliance (GB/T 17465.4). The purpose is to specify the coupling that engages by the weight of the appliance. The technical requirements for electric shock protection, structure, mechanical properties and electrical properties of the coupler. --- Part 2-1.Sewing machine coupler (GB/T 17465.5). The purpose is to specify the protection against electric shock, Technical requirements for structure, mechanical properties, electrical properties, etc. --- Part 3.Standard loose-leaf and gauge (GB/T 17465.6). The purpose is to specify the coupling of two poles and two poles with earthing contacts The size and gauge of the coupler. This document can provide guidance for the production of household and similar appliance coupler products, improve the technical performance and safety and reliability of the products, Guarantee the interchangeability of products and ensure the safety of people's electricity consumption. Couplers for household and similar appliances Part 3.Standard loose-leaf and gauges

1 Scope

This document specifies the dimensions and gauges of two-pole and two-pole appliance couplers with earthing contacts. This document applies to two-pole and two-pole appliance couplers with earthing contacts, which are used for. --- connect household or similar electrical equipment to mains power; and --- interconnect the power supply to the appliance or equipment; --- and the size of the gauge.

2 Normative references

The contents of the following documents constitute essential provisions of this document through normative references in the text. Among them, dated citations documents, only the version corresponding to that date applies to this document; for undated references, the latest edition (including all amendments) applies to this document. GB/T 17465.1-2022 Couplers for household and similar appliances - Part 1.General requirements (IEC 60320-1.2021, MOD) IEC 60320-2-3.2018 Couplers for household and similar appliances - Part 2-3.Coupling of appliances with a degree of protection higher than IPX0 Note. GB/T 17465.3-2008 Household and similar appliance couplers - Part 2.Appliance couplers with a degree of protection higher than IPX0 (IEC 60320- 2-3.2005, IDT)

3 Terms and Definitions

Terms and definitions defined in GB/T 17465.1-2022 apply to this document.

4 General requirements

The general requirements for connecting the appliance coupler to the mains supply are detailed in Table 1. ......
