GB/T 17116.1-2018 English PDFUS$498.00 · In stock
Delivery: <= 1 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 17116.1-2018: Pipe supports and hangers -- Part 1: Technical specification Status: Valid GB/T 17116.1: Historical versions
Basic dataStandard ID: GB/T 17116.1-2018 (GB/T17116.1-2018)Description (Translated English): Pipe supports and hangers -- Part 1: Technical specification Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: J15 Classification of International Standard: 23.040.99 Word Count Estimation: 78,790 Date of Issue: 2018-03-15 Date of Implementation: 2018-10-01 Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration GB/T 17116.1-2018: Pipe supports and hangers -- Part 1: Technical specification---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.Pipe supports and hangers--Part 1. Technical specification ICS 23.040.99 J15 National Standards of People's Republic of China Replace GB/T 17116.1-1997 Pipe hanger Part 1. Technical specifications Published on.2018-03-15 2018-10-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Administration issued ContentForeword V 1 Scope 1 2 Normative references 1 3 Terms and Definitions 4 4 General 5 5 Material 6 5.1 General 6 5.2 Forgings 6 5.3 Castings 6 5.4 bolts, nuts, washers and pins 7 6 Design 7 6.1 General 7 6.2 Load criteria 15 6.3 Allowable stress 16 6.4 Variable force and constant force support hangers 18 6.5 rigid support device 20 6.6 Damping and damping device 20 6.7 Spring Design 21 6.8 Pipe structure 21 6.9 Booms and Accessories 23 6.10 Auxiliary steel structure 23 6.11 Threaded connection 24 6.12 Weld connection 24 6.13 Multi-tube shared bracket 25 6.14 Support hanger spacing 25 6.15 Support and hanger assembly design 27 7 Manufacturing 29 7.1 General 29 7.2 Manufacturing tolerances 29 7.3 Material cutting 30 7.4 Hot and cold forming 30 7.5 Welding 31 7.6 Threaded connection 33 7.7 Assembly and alignment 34 7.8 Protective coating 34 7.9 Product Mark 35 7.10 Packaging 35 7.11 Packaging and Delivery Marks 36 7.12 Shipping 36 7.13 Receiving 36 8 Installation 36 8.1 General 36 8.2 Preparation 37 8.3 Positioning 37 8.4 Installation Requirements 37 8.5 Adjustment 39 8.6 Check 41 9 Test 42 9.1 General 42 9.2 Testing of steel parts and their raw materials 43 9.3 Machine performance test 44 10 inspection 45 10.1 General 45 10.2 Inspection timing and conditions 45 10.3 Appearance, Coating and Dimensional Inspection 45 10.4 Hardness and Metallographic Examination 46 10.5 Nondestructive testing 46 10.6 Raw Material Inspection 46 10.7 Spring Inspection 46 10.8 Threaded connection inspection 47 10.9 Welding joint inspection 47 10.10 Finished Product Inspection 49 10.11 Settlement inspection 50 10.12 Type Inspection 50 10.13 Supplementary Inspection 50 10.14 Sampling Rules 50 10.15 Discrimination Rule 50 10.16 Installation Quality Inspection 51 11 Maintenance 53 11.1 General 53 11.2 Support and hanger maintenance outline 54 11.3 Operation and Maintenance Related Work 55 11.4 Maintenance Procedures 56 11.5 Maintenance Precautions 56 11.6 Maintenance Quality Inspection and Inspection 57 11.7 Maintenance Recommendations 57 Appendix A (Normative Appendix) Permissible stress tables for commonly used domestic steels 58 A.1 steel plate 58 A.2 Steel pipe 61 A.3 Forgings 63 A.4 bolt 64 Appendix B (informative appendix) Hengli support hanger performance test method 66 B.1 Test equipment and instruments 66 B.2 Installation Requirements 66 B.3 Test procedure 66 B.4 Test record 67 Appendix C (informative) Test method for performance of variable force spring hangers and hangers 68 C.1 Test equipment and instruments 68 C.2 Test procedure 68 C.3 Test record 68 Appendix D (informative) Test method for spring damper performance 69 D.1 Test equipment and instruments 69 D.2 Test procedure 69 D.3 Test record 69 Appendix E (informative) Hydraulic Damper Performance Test Method 70 E.1 Test equipment, instruments and test environment 70 E.2 Test procedure 70 E.3 Test record 70ForewordGB/T 17116 "Pipe Supporting and Hanging" is divided into the following three parts. --- Part 1. Technical specifications; --- Part 2. Pipe connection parts; --- Part 3. Intermediate connectors and building structure connectors. This part is the first part of GB/T 17116. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This part replaces GB/T 17116.1-1997 "Pipe hangers and hangers Part 1. Technical specifications", and GB/T 17116.1-1997 In addition to the editorial changes, the main technical changes are as follows. --- Modified the temperature classification of the pipeline system; --- Increased the lower temperature limit for use of gray cast iron, malleable cast iron and ductile iron; --- According to the degree of versatility, the typical standard components of the hangers are sorted and adjusted; ---Adjusted the safety factor of the allowable stress of the support and hanger components; --- Modified the maximum load of the threaded boom according to the adjusted material allowable stress; ---The threaded boom with a nominal diameter greater than or equal to 56mm is modified to use a fine thread with a pitch of 4mm; ---Modified pipe clamp tolerance for forming; ---Specific requirements are given on the test methods and results of the support of hanger parts and their raw materials; ---Specific requirements for the performance test of the support and hanger; --- Classification refines the inspection requirements for hangers and components; ---Enriched the relevant content and requirements for maintenance of hangers and hangers; --- In the appendix, the performance test method of constant force support hanger, variable force support hanger, spring damper and hydraulic damper is added. This part was proposed by the China Machinery Industry Federation. This part is under the jurisdiction of the National Pipeline Attachment Standardization Technical Committee (SAC/TC237). This section is responsible for drafting. China Power Engineering Consulting Group East China Electric Power Design Institute Co., Ltd. Participated in the drafting of this section. Zhongji Guoneng Power Engineering Co., Ltd., China Machine Productivity Promotion Center, China Power Engineering Consulting Group Northwest Electric Power Design Institute Co., Ltd., Jiangsu Electric Power Equipment Co., Ltd., Huadian Electric Power Research Institute, China Petroleum Engineering Construction Corporation East China Design branch, China Tianchen Engineering Co., Ltd. The main drafters of this section. Lin Lei, Lin Qiluo, Li Junying, Ma Xinqiang, Pu Wansheng, Guo Yanjun, Liu Jian, Liu Jun, Orchid, Xiong Jianwen, Feng Feng, Shen Songlin, Huang Jiayun, Xu Jinghua. The previous versions of the standards replaced by this section are. ---GB/T 17116.1-1997. Pipe hanger Part 1. Technical specifications1 ScopeThis part of GB/T 17116 specifies the basics of materials, design, manufacture, installation, testing, inspection and operation and maintenance of pipeline supports and hangers. Claim. This section applies to the support and hanger devices of round-section metal pipes.2 Normative referencesThe following documents are indispensable for the application of this document. For dated references, only dated versions apply to this article. Pieces. For undated references, the latest edition (including all amendments) applies to this document. GB/T 90.1 fastener acceptance inspection GB/T 91 cotter pin GB/T 117 taper pin GB/T 119.1 cylindrical pin not hardened steel and austenitic stainless steel GB/T 119.2 cylindrical pin hardened steel and martensitic stainless steel GB/T 150.2-2011 Pressure Vessels Part 2. Materials GB/T 150.3-2011 Pressure Vessels Part 3. Design GB/T 157 Geometrical Product Specifications (GPS) Cone taper and cone angle series GB/T 191 packaging storage and transportation icon GB/T 193 Ordinary Thread Diameter and Pitch Series GB/T 196 basic thread basic size GB/T 197 ordinary thread tolerance GB/T 228.1 tensile testing of metallic materials - Part 1 GB/T 229 metal material Charpy pendulum impact test method GB/T 231.1 Brinell hardness test for metallic materials - Part 1. Test methods GB/T 232 metal material bending test method GB/T 321 priority number and priority number GB/T 324 weld symbol notation GB/T 699 high quality carbon structural steel GB/T 713 steel plate for boiler and pressure vessel GB/T 880 headless pin GB/T 882 pin GB/T 912 carbon structural steel and low alloy structural steel hot rolled steel sheet and strip GB/T 985.1 Recommended groove for gas welding, electrode arc welding, gas shielded welding and high energy beam welding GB/T 985.2 recommended groove for submerged arc welding GB/T 1184-1996 Shape and position tolerances without tolerance values GB/T 1220 stainless steel rod GB/T 1221 heat resistant steel rod GB/T 1222 spring steel GB/T 1231 High-strength large hexagon bolts, large hex nuts and washers for steel structures GB/T 1239.2 Technical requirements for cold coiled cylindrical springs - Part 2 GB/T 1348 ductile iron castings GB/T 1413 Series 1 container classification, size and rated quality GB/T 1804-2000 General tolerances and tolerances for linear and angular dimensions without tolerances GB/T 2516 common thread limit deviation GB/T 2518 continuous hot-dip galvanized steel sheet and strip GB/T 2650 welded joint impact test method GB/T 2651 welded joint tensile test method GB/T 2652 Weld and deposited metal tensile test method GB/T 2653 welded joint bending test method GB/T 2822 standard size GB/T 2828.1. Sampling and sampling procedures - Part 1 . Batch-to-batch sampling plan searched by the acceptance quality limit (AQL) GB/T 2934 Intermodal Universal Flat Pallet Main Dimensions and Tolerances GB/T 2975 steel and steel products mechanical properties test sampling position and sample preparation GB/T 3077 alloy structural steel GB/T 3087 seamless steel pipe for low and medium pressure boilers GB/T 3091 welded steel pipe for low pressure fluid transportation GB/T 3098.1 Fastener mechanical properties bolts, screws and studs GB/T 3098.2 fastener mechanical properties nut coarse thread GB/T 3098.4 Fastener mechanical properties nut fine thread GB/T 3098.6 Mechanical properties of fasteners Stainless steel bolts, screws and studs GB/T 3098.8 Mechanical properties of fasteners - Bolted joint parts for use from.200 ° C to 700 ° C GB/T 3098.9 Fastener mechanical properties Effective torque steel lock nut GB/T 3098.15 fastener mechanical properties stainless steel nut GB/T 3103.1 Fastener Tolerance Bolts, Screws, Studs and Nuts GB/T 3103.4 Fastener Tolerance - Bolt-Nut Connection Pair for Use at.200 ° C ~ 700 ° C GB/T 3274 carbon structural steel and low alloy structural steel hot rolled thick steel plate and steel strip GB/T 3531 steel plate for low temperature pressure vessel GB/T 4096 Geometrical Product Specifications (GPS) Angle and Slope Series GB/T 4857.1 Packaging and transportation package marking method for each part of the test GB/T 4879 anti-rust packaging GB/T 4892 hard rectangular transport packaging size series GB/T 4995 intermodal universal flat pallet performance requirements and test options GB/T 5210 paint and varnish pull-off adhesion test GB/T 5267.1-2002 fastener plating GB/T 5310 seamless steel pipe for high pressure boiler GB/T 5398 Large transport package test method GB/T 5752 conveyor belt logo GB/T 6388 transport packaging receipt and delivery mark GB/T 6414 casting dimensional tolerance and machining allowance GB/T 8163 seamless steel pipe for conveying fluid GB/T 8165 stainless steel clad steel plate and steel strip GB/T 8492 general purpose heat resistant steel and alloy castings GB/T 8923.1.Determination of surface cleanliness of steels - Part 1 . Uncoated steel Corrosion grade and treatment grade of the surface of the steel after surface and overall removal of the original coating GB/T 9286 color and varnish paint film cross-cut test GB/T 9437 heat resistant cast iron parts GB/T 9439 gray iron castings GB/T 9440 malleable iron castings GB/T 9799 treated zinc coating on metal and other inorganic coatings GB/T 9948 seamless steel pipe for petroleum cracking GB/T 11334-2005 Product Geometrical Specifications (GPS) Cone Tolerance GB/T 11352 cast carbon steel for general engineering GB/T 11373 thermal spraying metal parts surface pretreatment general rules GB/T 12212 Technical drawing weld symbol size, proportion and simplified representation General technical conditions for GB/T 12361 steel die forgings GB/T 12362 steel die forgings tolerance and machining allowance GB/T 12363 forgings functional classification GB/T 12467.1 Welding quality requirements for metallic materials - Part 1 GB/T 12467.2 Welding quality requirements for metallic materials - Part 2. Complete quality requirements GB/T 12467.3 Welding quality requirements for metallic materials - Part 3. General quality requirements GB/T 12467.4 Welding quality requirements for metallic materials - Part 4. Basic quality requirements GB/T 12467.5 Metallic materials - Welding quality requirements - Part 5. Standard documents to be used to meet quality requirements GB/T 13148 stainless steel clad steel plate welding technical requirements GB/T 13298 metal microstructure inspection method GB/T 13346 treated cadmium plating on metal and other inorganic coatings GB/T 13452.2-2008 Determination of film thickness of paints and varnishes Technical requirements and test methods for hot dip galvanized layer of GB/T 13912 metal-clad steel parts GB/T 14436 General Rules for Industrial Product Assurance Documents GB/T 14976 stainless steel seamless pipe for fluid transportation GB/T 15169 steel fusion welding welder skill assessment GB/T 17116.2 Pipe hangers - Part 2. Pipe connection components GB/T 17116.3 Pipe hangers and hangers - Part 3. Intermediate joints and building structural joints GB/T 17394.1 Test methods for hardness of metallic materials - Part 1 . Test methods GB/T 21470 hammered steel free forgings machining allowance and tolerance plate, column, ring, cylinder GB/T 21471 hammered steel free forgings machining allowance and tolerance shaft GB/T 23934 hot coil cylindrical spiral compression spring technical conditions GB/T 23935 cylindrical coil spring design calculation GB/T 24511 stainless steel plate and steel strip for pressure equipment General technical conditions for steel free forgings on GB/T 26639 hydraulic press GB 50009 Building Structure Load Specification GB 50017 steel structure design specification GB 50018 Cold-formed thin-walled steel structure technical specification GB 50205 Steel Structure Engineering Construction Quality Acceptance Specification DL/T 931 Qualification Examination Rules for Physical and Chemical Inspectors in the Power Industry JB/T 4385.1 General technical requirements for free forgings on hammers NB/T 47008 Carbon steel and alloy steel forgings for pressure equipment NB/T 47013.2 Non-destructive testing of pressure equipment - Part 2. Radiographic testing NB/T 47013.3 Non-destructive testing of pressure equipment - Part 3. Ultrasonic testing NB/T 47013.4 Non-destructive testing of pressure equipment - Part 4. Magnetic particle testing NB/T 47013.5 Non-destructive testing of pressure equipment - Part 5. Penetration testing NB/T 47013.10 Non-destructive testing of pressure equipment - Part 10 NB/T 47014 Pressure welding equipment welding process evaluation TSGZ8001 special equipment non-destructive testing personnel assessment rules3 Terms and definitionsThe following terms and definitions apply to this document. 3.1 Pipe support hanger pipesupportsandhangers Various components or devices used to withstand pipeline loads, limit pipeline displacement, control pipeline vibration, and transfer loads to the load-bearing structure (Can be referred to as "supporting hanger"). 3.2 Constant support hanger constantsupportandhanger It is used to bear the vertical load of the pipeline, and its bearing capacity does not change with the change of the vertical displacement of the pipeline at the supporting point, that is, the load remains basically constant. Fixed hangers. 3.3 Variable force spring support hanger variablespringsupportandhanger The elastic support hanger used to withstand the vertical load of the pipeline and its bearing capacity changes with the vertical displacement of the pipeline at the branch point. 3.4 Rigid hanger rigidhanger A hanger used to withstand the vertical load of the pipe and constrain the vertical displacement of the pipe at the point of attachment. 3.5 Sliding bracket slidingsupport A bracket that supports the pipe on a sliding floor to withstand the vertical load of the pipe and constrain the vertical displacement of the pipe at the point of attachment. 3.6 Rolling support hanger rolesupportandhanger A support for supporting the pipe on the rolling member to withstand the vertical load of the pipe and constrain the vertical displacement of the pipe at the point of attachment. 3.7 Guide guide A device for guiding the displacement of a pipe in a predetermined direction to limit displacement in other directions. Horizontal pipe guides can also withstand pipes Vertical load. 3.8 Limit device restraint A device used to constrain or partially limit the displacement of a pipe system in one or more directions at a point of attachment. It usually does not bear the vertical of the pipe Load. 3.9 Fixed bracket anchor A rigid device used to completely restrain the pipe at the point of attachment without any line and angular displacement. 3.10 Damping device swaybrace It is used to control the low-frequency high-frequency sloshing or high-frequency low-amplitude vibration of the pipeline, and has certain constraints on the thermal expansion or contraction of the piping system. 3.11 Damping device snubber It is used to withstand the seismic load or impact load of the pipeline, and to control the high-speed vibration displacement of the pipeline, while allowing the pipeline to be freely expanded and contracted. Device. 3.12 Integral pipe joints integralpipeattachments Including hangers, guide plates, ear plates, branch pipes (trunken shafts), brackets, saddle supports and skirt supports, etc. Forging is made as a whole. 3.13 Non-integral pipe joint non-integralpipeattachments Supporting hanger components such as pipe clamps, pipe clamps, pipe rings, pipe supports and U-shaped pipe clamps are connected to the pipe or its insulation layer by means of clamping or support. connection.4 General4.1 The materials, design, manufacture, installation, testing, inspection and operation and maintenance of pipeline supports shall be in accordance with the provisions of this standard. The requirements of the current national regulations related to the pipeline. 4.2 Pipe hangers and hanger types such as constant force hangers, variable force spring hangers, rigid hangers, sliding brackets and rolling supports and hangers can be used to withstand pipes The occasion of the road load. 4.3 Pipe hangers and hanger types such as guides, limit devices and fixed brackets can be used to limit pipe displacement. 4.4 Damping devices and damping devices can be used to control the vibration of the pipeline. 4.5 When designing and selecting pipe supports, the pipe system can be classified according to Table 1 according to the working temperature range of the pipeline. Table 1 Pipeline system classification Piping system piping system grading operating temperature range Heat pipe A-1 >50°C~300°C A-2 >300°C~425°C A-3 >425°C~550°C A-4 >550°C Normal temperature pipe B >20°C~50°C Cold pipe C-1 >0°C~20°C C-2 >-20°C~0°C C-3 >-40°C~-20°C C-4 ≤ -40 ° C (low temperature range)5 materials5.1 General 5.1.1 The technical requirements of the materials shall comply with the corresponding national standards, industry standards or relevant technical requirements. 5.1.2 The materi......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of GB/T 17116.1-2018_English be delivered?Answer: Upon your order, we will start to translate GB/T 17116.1-2018_English as soon as possible, and keep you informed of the progress. The lead time is typically in 24 hours. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of GB/T 17116.1-2018_English with my colleagues?Answer: Yes. The purchased PDF of GB/T 17116.1-2018_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.Question 5: Should I purchase the latest version GB/T 17116.1-2018?Answer: Yes. Unless special scenarios such as technical constraints or academic study, you should always prioritize to purchase the latest version GB/T 17116.1-2018 even if the enforcement date is in future. Complying with the latest version means that, by default, it also complies with all the earlier versions, technically. |
