GB/T 17037.5-2020 English PDF

US$189.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 17037.5-2020: Plastics. Injection moulding of test specimens of thermoplastic materials - Part 5: Preparation of standard specimens for investigating anisotropy
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 17037.5-2020	189	Add to Cart	3 days	Plastics. Injection moulding of test specimens of thermoplastic materials - Part 5: Preparation of standard specimens for investigating anisotropy	Valid

Similar standards

GB/T 16422.4   GB/T 16422.3   GB/T 16578.2   GB/T 12008.7   GB/T 18964.1   GB/T 17037.2

Basic data

Standard ID: GB/T 17037.5-2020 (GB/T17037.5-2020)
Description (Translated English): Plastics. Injection moulding of test specimens of thermoplastic materials - Part 5: Preparation of standard specimens for investigating anisotropy
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: G31
Classification of International Standard: 83.080.20
Word Count Estimation: 10,133
Date of Issue: 2020-12-14
Date of Implementation: 2021-07-01
Quoted Standard: GB/T 17037.1-2019; GB/T 37426-2019
Adopted Standard: ISO 294-5-2017, MOD
Regulation (derived from): National Standard Announcement No. 28 of 2020
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration
Summary: This standard specifies the mold (F-type GB/ISO mold) used to inject rectangular plate-shaped specimens to obtain single-point and multi-point data. The minimum specimen size is ��90 mm X 80 mm, and the preferred size is 120 mm X 80 mm, the preferred thickness is 2 mm. It has been found that samples of this size can provide the greatest anisotropic properties and are only slightly sensitive to injection rate. The use of a two-cavity mold is preferred. For the design of plastic parts, this will provide upper and lower limits for tensile properties. Due to the influence of mold filling rate and part geometry on anisotropy, it is not appropriate to match the thickness of the injection molded sample plate with the thickness of a given part. The study of material anisotropy is used to guide mold design rather than quality control

GB/T 17037.5-2020: Plastics. Injection moulding of test specimens of thermoplastic materials - Part 5: Preparation of standard specimens for investigating anisotropy

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Plastics:Preparation of injection molded specimens of thermoplastic materials:Part 5: Preparation of standard specimens for anisotropy evaluation) ICS 83:080:20 G31 National Standards of People's Republic of China Preparation of Injection Molding Specimen of Plastic Thermoplastic Materials Part 5: For anisotropy assessment Preparation of standard samples (ISO 294-5:2017, MOD) 2020-12-14 release 2021-07-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Table of contents

Foreword Ⅰ Introduction Ⅱ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 Device 1 5 Step 3 6 Sample preparation report 3 Appendix A (Normative Appendix) Sample Preparation 5 Reference 6

Foreword

GB/T 17037 "Preparation of Injection Molding Specimens of Plastic Thermoplastic Materials" is divided into 5 parts: ---Part 1: General principles and preparation of multi-purpose specimens and long strip specimens; ---Part 2: Small tensile specimen; ---Part 3: Small square test piece; ---Part 4: Determination of mold shrinkage; ---Part 5: Preparation of standard samples for anisotropy evaluation: This part is Part 5 of GB/T 17037: This section was drafted in accordance with the rules given in GB/T 1:1-2009: This part uses the redrafting method to amend and adopt ISO 294-5:2017 ``Preparation of Plastic Thermoplastic Material Injection Specimen No: 5 Part: Preparation of Standard Samples for Anisotropy Evaluation: The technical differences between this part and ISO 294-5:2017 and the reasons are as follows: ---Regarding normative reference documents, this section has made adjustments with technical differences to adapt to my country's technical conditions and adjustments: The situation is collectively reflected in Chapter 2 "Normative Reference Documents", and the specific adjustments are as follows: ● Replace ISO 294-1:2017 with GB/T 17037:1-2019 which is modified to adopt international standards; ● Replace ISO 20753:2018 with GB/T 37426-2019, which is modified to adopt international standards: This part was proposed by the China Petroleum and Chemical Industry Federation: This part is under the jurisdiction of the National Plastics Standardization Technical Committee (SAC/TC15): Drafting organizations of this section: Beijing Huasu Chenguang Technology Co:, Ltd:, Kingfa Technology Co:, Ltd:, Anhui Huaxing Cable Group Co:, Ltd:, Zhonglan Chenguang Chemical Co:, Ltd:, Tongrail Technology Chengdu Co:, Ltd:, Shandong Dawn Polymer Materials Co:, Ltd:, People of China The Republic of Qingdao Dagang Customs, Jiangmen Xinhui Henglong Household Innovation Co:, Ltd: The main drafters of this section: Chen Hongyuan, Zhang Changyi, Chen Pingxu, Deng Yongjun, Zheng Ning, Liu Huansheng, Tian Hongchi, Gao Jianguo, Shi Xin, Nie Huayao:

Introduction

Reinforced and self-reinforced thermoplastic injection molding materials have a very wide range of uses, including safety-related uses: In the material injection During the process, the reinforcing fibers are preferentially arranged according to the flow direction of the melt, not perpendicular to the flow direction of the melt: This preferential arrangement makes the molded thermoplastic Plastics are unbalanced in performance, so the strength and stiffness in the melt flow direction where a large number of reinforcing fibers are arranged will be higher than that of a small number of reinforcing fibers: The dimensional arrangement perpendicular to the direction of melt flow has high strength and rigidity: This difference in performance is the anisotropy of thermoplastic materials Sex: For this reason, the actual strength of the injection molding material may be lower than the expected or designed strength: To help designers understand The potential strength of plastic materials, knowing the anisotropy of injection molding material performance is very valuable: Research during the formulation of this standard shows that the same fiber arrangement is not shown in the cross section of the thickness of the injection molded sample, and the fiber is preferentially arranged: The skin layer is listed in the molding filling direction, while the core layer has almost no oriented fibers (for example, no preferential arrangement): The amount of ordered fibers (thickness of the skin) The ratio of degree) to the amount of unoriented fibers (core layer thickness) in the cross section is affected by the thickness of the sample and the filling speed such as the average injection rate: The proportion of ordered fibers in thicker samples is less than that in thinner samples: Lower mold filling speed results in a thicker skin of ordered fibers Floor: Therefore, in order to obtain meaningful data about the molding design, the researcher should prepare the sample with the largest anisotropic characteristic, because this These data best represent the upper and lower limits of the composite structure: Since the thickness of the sample and the injection rate have a significant effect on the final anisotropy, This section is only used to obtain useful information in the molding design, not for quality control tests of plastic materials: From:2010 to:2013, the working group of the ISO 294-5 standard adopted in this section conducted adjustments to more than 10 raw material suppliers around the world: The investigation clearly shows that in order to prepare a plate with a suitable degree of anisotropy, a non-square plate shape is required to ensure that the fibers flow in the melt: Orientation in the direction: Under the conditions of this study, a rectangular plate specimen with a size of 120mm×80mm×2mm was used to obtain the highest The anisotropy: It can be considered that the rectangular plate-shaped sample over 120mm will at least show good results: Square plate specimen (e:g: 80mm×80mm×2mm, or even 150mm×150mm×2mm) sometimes produce some problems that have nothing to do with size: this research In any case, the 90mm×80mm×2mm rectangular plate shape specified in the previous edition of the ISO 294-5 standard adopted in this part None of the samples showed good effects: Preparation of Injection Molding Specimen of Plastic Thermoplastic Materials Part 5: For anisotropy assessment Preparation of standard samples

1 Scope

This part of GB/T 17037 specifies the mold (Type F GB /ISO ) used to inject rectangular plate-shaped specimens to obtain single-point and multi-point data: Mold), the minimum sample size is ≥90mm×80mm, the preferred size is 120mm×80mm, and the preferred thickness is 2mm: Found This size sample can provide the largest anisotropic properties, and only has a slight sensitivity to the injection rate: The use of a two-cavity mold is preferred: For the design of plastic parts, this will provide upper and lower limits for tensile properties: Due to the anisotropy of mold filling rate and part geometry Due to the impact of performance, it is not appropriate to match the thickness of the injection molded sample to the thickness of the given part: The study of material anisotropy is used to guide mold design rather than a method of quality control: In the thermoplastic injection molding process, the flow of molten polymer can affect the orientation or polymerization of similar fillers such as glass fibers: The orientation of the material chain, which will lead to the anisotropy of the material: In this section, the flow direction is defined as the direction from the gate to the distal end of the mold cavity, and the transverse direction refers to the direction perpendicular to the flow direction: The F-type GB /ISO mold is not used to replace the D-type mold prepared by measuring the shrinkage rate of thermoplastic plastics: This section applies to the preparation of reproducible rectangular plate-shaped specimens by injection molding of thermoplastic materials:

2 Normative references

The following documents are indispensable for the application of this document: For dated reference documents, only the dated version applies to this article Pieces: For undated references, the latest version (including all amendments) applies to this document: GB/T 17037:1-2019 Preparation of injection molded specimens of plastic thermoplastic materials Part 1: General principles and multi-purpose tests Preparation of samples and long strip samples (ISO 294-1:2017, MOD) GB/T 37426-2019 plastic sample (ISO 20753:2018, MOD)

3 Terms and definitions

The terms and definitions defined in GB/T 17037:1-2019 apply to this document: Note: ISO and IEC use the following website to maintain terminology databases: ---IEC World Online Electronic Technology Vocabulary: http://www:electropedia:org ---ISO online browsing platform: http://www:iso:org/obp

4 equipment

4:1 F-type GB /ISO mold A two-cavity F-type GB /ISO mold (see Figure 1 and Figure 2) should be used to prepare rectangular plate-shaped specimens: The mold should be able to prepare the smallest size ≥ For the sample size of 90mm×80mm, the first sample size is 120mm×80mm: Note: Because of the difference in shrinkage of different materials, the actual length and width of the mold cavity vary slightly: ......
