GB/T 16656.45-2013: Industrial automation systems and integration -- Product data representation and exchange -- Part 45: Integrated generic resources: Material and other engineering properties
Status: Valid

GB/T 16656.45: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 16656.45-2013	774	Add to Cart	3 days	Industrial automation systems and integration -- Product data representation and exchange -- Part 45: Integrated generic resources: Material and other engineering properties	Valid
GB/T 16656.45-2001	RFQ	ASK	4 days	Industrial automation systems and integration -- Product data representation and exchange -- Part 45: Integrated generic resources: material	Obsolete

Similar standards

GB/T 38633 GB/T 38666 GB/T 38672 GB/T 16656.52 GB/T 16656.42 GB/T 16656.46

Basic data

Standard ID: GB/T 16656.45-2013 (GB/T16656.45-2013)
Description (Translated English): Industrial automation systems and integration -- Product data representation and exchange -- Part 45: Integrated generic resources: Material and other engineering properties
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: L67
Classification of International Standard: 25.040.40
Word Count Estimation: 39,338
Older Standard (superseded by this standard): GB/T 16656.45-2001
Quoted Standard: ISO/IEC 8824-1; ISO 10303-1; ISO 10303-11; ISO 10303-41; ISO 10303-43; ISO 10303-50; ISO/IEC GUIDE 98-3-2008
Adopted Standard: ISO 10303-45-2008, IDT
Regulation (derived from): National Standards Bulletin No. 25 of 2013
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the resource structure of resource material properties and structural products by characterizing uncertainty and reliability of numerical data. The following content belongs to the scope of this standard: the relationship between c

GB/T 16656.45-2013: Industrial automation systems and integration -- Product data representation and exchange -- Part 45: Integrated generic resources: Material and other engineering properties

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Industrial automation systems and integration Product data representation and exchange Part 45... Integrated generic resources. Material and other engineering properties ICS 25.040.40 L67 National Standards of People's Republic of China Replacing GB/T 16656.45-2001 Industrial automation systems and integration Product data representation and exchange Part 45. Integrated generic resources. And other engineering properties of materials Part 45. Integratedgenericresources. (ISO 10303-45.2008, IDT) Issued on. 2014-06-01 2013-12-17 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Introduction Ⅲ Introduction Ⅵ 1 Scope 1 2 Normative references 1 3 Terms, definitions and abbreviations 2 3.1 ISO 10303-1 defined terms 2 3.2 ISO /IEC Guide98-3.2008 defined the term 2 3.3 Other definitions 2 3.4 Acronyms 3 4 material properties defined mode 3 4.1 Introduction 4 4.2 Basic concepts and assumptions 4 Type 4.3 material_property_definition_schema Model Definition 4 4.3.1 Type characterized_material_property 4 4.3.2 Type characterized_product_composition_value 4 Entity Definition 4.4 material_property_definition_schema Mode 5 4.4.1 Entity material_designation 5 4.4.2 Entity material_designation_characterization 5 4.4.3 Entity material_property 5 4.4.4 Entity product_material_composition_relationship 6 4.4.5 Entity property_definition_relationship 7 4.5 material_property_definition_schema function definition mode 7 4.5.1 Function acyclic_property_definition_relationship 7 5 material properties of the expression pattern of 8 5.1 Introduction 9 5.2 Basic concepts and assumptions 9 Entity definitions 5.3 material_property_representation_schema 9 5.3.1 Entity data_environment 9 5.3.2 Entity data_environment_relationship 10 5.3.3 Entity material_property_representation 10 6 Restricted measurement mode 11 6.1 Introduction 11 6.2 Basic concepts and assumptions 11 6.3 qualified_measure_schema type definitions 12 6.3.1 Type value_qualifier 12 Entity definitions 6.4 qualified_measure_schema 12 6.4.1 Entity descriptive_representation_item 12 6.4.2 Entity expanded_uncertainty 12 6.4.3 Entity maths_value_qualification 13 6.4.4 Entity maths_value_representation_item 13 6.4.5 Entity maths_value_with_unit 14 6.4.6 Entity measure_qualification 14 6.4.7 Entity measure_representation_item 14 6.4.8 Entity precision_qualifier 15 6.4.9 Entity qualified_representation_item 15 6.4.10 entity qualitative_uncertainty 15 6.4.11 entity standard_uncertainty 16 6.4.12 entity type_qualifier 16 6.4.13 entity uncertainty_qualifier 16 Appendix A (normative) Short name of the entity 17 Logo Annex B (normative) information object registration 18 Appendix C (Informative Appendix) EXPRESS list 19 Appendix D (Informative Appendix) EXPRESS-G 20 Appendix E (normative) technical discussions 24 References 30 Figure 1 partially integrated architecture model diagram (1/1) Ⅶ Figure D.1 material_property_definition_schema of EXPRESS-G (1/2) 20 Figure D.2 material_property_definition_schema of EXPRESS-G diagram (2/2) 21 Figure D.3 material_property_representation_schema of EXPRESS-G (1/2) 21 Figure D.4 material_property_representation_schema of EXPRESS-G diagram (2/2) 22 Figure D.5 qualified_measure_schema of EXPRESS-G (1/2) 22 Figure D.6 qualified_measure_schema of EXPRESS-G diagram (2/2) 23 Figure E.1 Examples of products 25 Figure E.2 relationship characteristics and data environment conditions 27 Figure E.3 composite sample products manufactured 29 Table A.1 entity short name 17 Table 19 lists C.1 EXPRESS

Foreword

GB/T 16656 (ISO 10303) "Industrial automation systems and integration - Product data representation and exchange" is a multi-part Standard, each part published separately. GB/T 16656 and the relevant portions of the composition of a plurality of sub-series, namely. --- First to the provisions of section 19 has been described methods; Part --- 20 to 29 provides for implementation; --- 30 ~ Part 39 specifies conformance testing methodology and framework; Part --- 40 to 59 provides for integrated generic resources; --- Part 100 to 199 provides integrated application resources; --- Section 200 to section 299 specifies the application protocol; --- Section 300 to section 399 specifies the abstract test suite; --- The first 400 to 499 part specifies the application module; --- The first part provides 500 to 599 Application interpreted construct; 1000 to 1999 --- The first part defines the application modules. GB/T 16656 "Industrial automation systems and integration - Product data representation and exchange" has been released and the upcoming release include the following section. --- Part 1. Overview and fundamental principles; --- Part 11. Description methods. EXPRESS language reference manual; --- Part 21. Implementation methods. Clear text encoding of the exchange file structure; --- Part 28. Implementation. XML data model and expression EXPRESS (using XML mode); --- Part 31. Conformance testing methodology and framework. General concepts; --- Part 32. Conformance testing methodology and framework. Requirements on testing laboratories and customer requirements; --- Part 34. Conformance testing methodology and framework. Abstract test methods for application protocol implementations; --- Part 41. Integrated generic resources. Product description and support; --- Part 42. Integrated generic resources. Geometric and topological representation; --- Part 43. Integrated generic resources. Representation structures; --- Part 44. Integrated generic resources. Product structure configuration; --- Part 45. Integrated generic resource. Materials engineering and other characteristics; --- Part 46. Integrated generic resources. visual display; --- Part 47. Integrated generic resources. Shape variation; --- Part 49. Integrated generic resources. Process structure and properties; --- Part 51. Integrated generic resource. Mathematical expression; --- Part 54. Integrated generic resource. Classification and set theory; --- Part 55. Integrated generic resources. Process and mixed expression; --- Part 56. Integrated generic resource. State; --- Part 101. Integrated application resource. Drawing; --- Part 105. Integrated application resource. Kinematics; --- Part 201. Application protocol. Explicit draughting; --- Part 202. Application protocol. Associative draughting; --- Part 203. Application protocol. Configuration controlled design; --- Part 238. Application protocol. computer numerical controller application interpreted model; --- Part 501. Application interpreted construct. Based on the frame side; --- Part 502. Application interpreted construct. Shell-based wireframe; --- Part 503. Application interpreted construct. Geometrically bounded 2D wireframe; --- Part 504. Application interpreted construct. Drawing annotation; --- Part 505. Application interpreted construct. pattern structure and management; --- Part 506. Application interpreted construct. Drawing elements; --- Part 507. Application interpreted construct. Geometrically bounded surface; --- Part 508. Application interpreted construct. Non-manifold surface; --- Part 509. Application interpreted construct. Manifold surface; --- Part 513. Application interpreted construct. Basic boundary representation; --- Part 520. Application interpreted construct. Associative draughting elements; --- Part 1001. Application module. Appearance assignment; --- Part 1002. Application module. color; --- Part 1003. Application module. Curve appearance; --- Part 1004. Application module. Basic geometry; --- Part 1005. Application module. Basic topology; --- Part 1006. Application module. basal expression; --- Part 1007. Application module. General surface appearance; --- 1008. Application module. Layer assignment; --- Part 1009. Application module. Shape appearance and layers. This section is GB/T Part of 4,516,656. This section drafted in accordance with GB/T 1.1-2009 given rules. This Part replaces GB/T 16656.45-2001 Part 45 "Industrial automation systems and integration - Product data representation and exchange. Integrated generic resource. Materials. " Compared with GB/T 16656.45-2001 main changes are as follows. 1) adds the following EXPRESS Description. --- Characterized_product_composition_value; --- Maths_value_with_unit; --- Maths_value_representation_item; --- Maths_value_qualification. 2) Modify the following EXPRESS Description. --- Product_material_composition_relationship.constituent_amount the EXPRESS description read. product_material_composition_relationship.constituent_amount. SET [1.?] OFcharac- terized_product_composition_value; --- Example 3.3.3 Terms material material_designation mark moved 4.4.1 Example 1. 3) to limit the meaning of certain attributes of an entity, the following entities added rule. --- Measure_qualification; --- Maths_value_qualification. 4) made the following editorial changes. --- EXPRESS change the order of description in alphabetical order for each mode; --- Note the format has been changed to comply with the latest version of GB/T 1.1-2009; --- An example of the format has been changed to comply with the latest version of GB/T 1.1-2009; Title --- Chapter 3 was changed to comply with the latest version of GB/T 1.1-2009; --- This section relates to the pattern has been described in the introduction. 5) extends the following. --- Expands the text in Appendix E, including adding the EXPRESS entity description and chart updates; --- Other features include the extended title of this section is applied to the material properties of the structure outside; --- Extended by reference. 6) Remove the ISO foreword. 7) Remove the ISO introduction. 8) the name was changed to the standard engineering materials and other features. This section uses the translation method identical with the international standard ISO 10303-45.2008 Industrial automation systems and integration - Product data representation " And exchange Part 45. Integrated generic resource. Materials and other engineering properties. " Consistency correspondence between this part of international documents and normative references of our files are as follows. --- GB/T 16262.1-2006 Information technology - Abstract Syntax Notation One (ASN.1) - Part 1. Specification of basic notation (ISO /IEC 8824-1.2002, IDT) --- GB/T 16656.1-2008 Industrial automation systems and integration - Product data representation and exchange - Part 1. Overview and groups The principles (ISO 10303-1.1994, MOD) --- GB/T 16656.11-2010 Industrial automation systems and integration - Product data representation and exchange - Part 11. Description Party Method. EXPRESS language reference manual (ISO 10303-11.2004, IDT) --- GB/T 16656.41-2010 Industrial automation systems and integration - Product data representation and exchange Part 41. Integrated Tong Resources used. Product description and support (ISO 10303-41.2005, IDT) Part 43 --- GB/T 16656.43-2008 Industrial automation systems and integration - Product data representation and exchange. Integration through Use of resources. Representation structures (ISO 10303-43.2000, IDT) For ease of use, made the following editorial changes. 1) by deleting the ISO and ISO Foreword Introduction; 2) For each underlined in bold for EXPRESS English language to describe the entity names, attribute names and function names, etc., in order to maintain Its English original intent, in this section, uses its English name, only when it is used as the title, we have to increase their name in front of the English Type attribution described. This section is proposed and managed by the China National Institute of Standardization. This section drafted by. China National Institute of Standardization. The main drafters of this section. Wang Zhiqiang, book Yin Rui, Yang Qinghai, Zhan Junfeng, Liu Shouhua, Hongyan. This part replaces the previous version of the published case. --- GB/T 16656.45-2001.

Introduction

GB/T 16656 standard product data representation and exchange a computer can recognize. Particular object is to provide a system with no Off neutral mechanism to describe the entire product life cycle of product data. This description is characteristic not only for neutral file exchange, but also Is the basis and sharing product databases and archiving. This is an integrated part of a series of resources. This section includes. --- Material_property_definition_schema; --- Material_property_representation_schema; --- Qualified_measure_schema. These patterns contain background information to understand the mode content. GB/T 16656.45-2001 contents remain valid. Appendix E Providing technical discussion mode configuration might apply. Products made of a material, the material properties of the product life cycle is very important in many ways, these are. ---product design; --- Manufacturing; --- Product processing; --- Products regeneration; ---material selection; ---product testing; --- Product performance analysis; --- Process planning; --- Process control; --- Product maintenance; --- Failure analysis; --- Parts replaced. This section applies for an Integrated generic resource description, application modules and application protocol product characteristics. The nature of these products can be a solid , Liquid, gas, or other physical form. Modify this part is compatible with previous versions. If the following cases, modifying the EXPRESS description is compatible with. --- Encoding instances, conforming to GB/T 16656.21 (ISO 10303-21) and in accordance with this section based on previous versions of application protocols, also Based on this section in line with the revised version of the application protocol. --- An interface that conforms to GB/T 16656.22 (ISO 10303-22) and in accordance with this section based on the previous version of the application protocol, also in line with This part of the revised version of the application protocol. --- Based on previous versions of this part of the application protocol mapping table remain valid in the revised agreement's application. The main changes in this section of the release is the ability to define the composition of the mathematical functions and values \u200b\u200bcharacteristic values, and these values \u200b\u200bcan be achieved which defines Accuracy and reliability. This part of the model relationship with the ISO 10303 Integrated resource definition model in EXPRESS-G form in Figure 1 has been described, The definition given in ISO 10303-11 EXPRESS-G's. Pattern shown in Figure 1 is built into the integrated resource. ......
