GB/T 15972.55-2009 English PDF

US$189.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 15972.55-2009: Specifications for optical fibre test methods -- Part 55: Measurement methods and test procedures for environmental characteristics -- Hydrogen aging
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 15972.55-2009	189	Add to Cart	3 days	Specifications for optical fibre test methods -- Part 55: Measurement methods and test procedures for environmental characteristics -- Hydrogen aging	Valid

Similar standards

YD/T 2554.1   GB/T 9771.1   GB/T 20186.1   GB/T 15972.49   GB/T 15972.54   GB/T 15972.47

Basic data

Standard ID: GB/T 15972.55-2009 (GB/T15972.55-2009)
Description (Translated English): Specifications for optical fibre test methods -- Part 55: Measurement methods and test procedures for environmental characteristics -- Hydrogen aging
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: M33
Classification of International Standard: 33.180.10
Word Count Estimation: 8,888
Date of Issue: 2009-09-30
Date of Implementation: 2009-12-01
Older Standard (superseded by this standard): GB/T 15972.5-1998
Quoted Standard: GB/T 9771.3-2008; GB/T 15972.10-2008; GB/T 15972.40-2008
Regulation (derived from): Announcement of Newly Approved National Standards No. 10 of 2009 (No. 150 overall)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard provides a hydrogen-containing fibers in a given environment, the hydrogen aging test methods and test procedures.

GB/T 15972.55-2009: Specifications for optical fibre test methods -- Part 55: Measurement methods and test procedures for environmental characteristics -- Hydrogen aging

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Specifications for optical fibre test methods Part 55. Measurement methods and test procedures for environmental characteristics Hydrogen aging. ICS 33.180.10 M33 National Standards of People's Republic of China Optical fiber test methods - Part 55. Methods of measurement of environmental performance and Hydrogen aging test procedure Posted 2009-09-30 2009-12-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

GB/T 15972 "fiber test methods" consists of several components. --- Part 10 ~ 19. Measurement methods and test procedures - General (corresponding to IEC 60793-1-10 ~ IEC 60793-1-19; Generation For GB/T 15972.1-1998); --- Part 20 - Part 29. dimensional parameters measuring methods and test procedures (corresponding to IEC 60793-1-20 ~ IEC 60793- 1-29; instead of GB/T 15972.2-1998); --- Part 30 - Part 39. Mechanical properties measurement methods and test procedures (corresponding to IEC 60793-1-30 ~ IEC 60793- 1-39; instead of GB/T 15972.3-1998); --- Part 40 - Part 49. transmission characteristics and measurement methods and test procedures for optical characteristics (corresponding to IEC 60793-1-40 ~ IEC 60793-1-49; instead of GB/T 15972.4-1998); --- Part 50 - Part 59. Environmental Performance Measurement methods and test procedures (corresponding to IEC 60793-1-50 ~ IEC 60793- 1-59; instead of GB/T 15972.5-1998). Wherein the GB/T 15972.5 × consists of the following components. --- Part 50. Measurement methods and test procedures for environmental characteristics constant heat; --- Part 51. Measurement methods and test procedures for environmental performance of dry heat; --- Part 52. Measurement methods and test procedures for the environmental performance of temperature cycles; --- Part 53. Measurement methods and test procedures for environmental characteristics of flooding; --- Part 54. Environmental Performance Measurement methods and test procedures gamma irradiation; --- Part 55. Measurement methods and test procedures for environmental characteristics of hydrogen aging. This section GB/T 15972 Part 55. The reference test methods in some of the major reference IEC 60793-2-50.2008 "Fiber Part 2-50. Product specification class B single-mode fiber specification" (in English), combined with the specific circumstances of the domestic test system Given. Appendix A of this section is an informative annex. This part is proposed by the Ministry of Industry and Information Technology of the People's Republic of China. This part of the jurisdiction of the China Communications Standards Association. This section is drafted. Wuhan Research Institute of Posts and Telecommunications, Optical Fiber and Cable Co., Ltd. The main drafters of this section. Chen poetry, Li Haiqing, Li Jing, Liu Cheng, Cheng Shuling. Optical fiber test methods - Part 55. Methods of measurement of environmental performance and Hydrogen aging test procedure

1 Scope

This section GB/T 15972 specifies the optical fiber in a given environment in the hydrogen-containing hydrogen aging test methods and test procedures. This part is suitable for assessing GB/T 15972.10-2008 specified in B1.3 class extended wavelength band dispersion unshifted single-mode optical Hydrogen aging performance fiber can also be used to evaluate the B4 class hydrogen aging performance single-mode fiber.

2 Normative references

The following documents contain provisions which, through reference GB/T 15972 in this section constitute provisions of this section. For dated reference documents Member, all subsequent amendments (not including errata content) or revisions do not apply to this section, however, encouraged to reach under this section Parties to research agreement to use the latest versions of these documents. For undated reference documents, the latest versions apply to this section. Non-dispersion shifted single-mode optical fiber characteristic wavelength band extension. GB/T 9771.3-2008 communication with single-mode fiber - Part 3 GB/T 15972.10-2008 fiber test methods - Part 10. Measurement methods and test procedures - General (IEC 60793-1-1.2002, Opticalfibres-Part 1-1. Measurementmethodsandtestprocedures-General andguidline, MOD) GB/T 15972.40-2008 fiber test methods - Part 40. Measuring methods for transmission and optical characteristics and testing Program attenuation (IEC 60793-1-40.2001, Opticalfibres-Part 1-40. Measurementmethodsandtestproce- dures-Attenuation, MOD)

3 test device

3.1 Test Chamber Test device includes an environmental chamber. The chamber should be able to accommodate the size of the test sample, the sample can not be subject to direct radiant heat, It can maintain the required temperature in the specified tolerance within the available air circulation to maintain uniform conditions of the test chamber. 3.2 Fiber container Size of the container should be able to accommodate optical fiber test samples, it can maintain the desired hydrogen-containing environments. Containers should be placed in environmental test chamber, and the container Materials heat transfer performance to ensure fiber samples and environmental test chamber set temperature in the vessel to reach consensus. 3.3 Other devices Other devices necessary to complete the test and measurement, if fitted (H2 + He) (hydrogen and helium) or (H2 + N2) (hydrogen and nitrogen) mixed Combined gas bottles.

4 Sample and Sample Preparation

In order to achieve the desired attenuation measurement repeatability, single-mode fiber sample length should be at least 2000m. Exposed outside the chamber light Fiber should be as short as possible, if the exposed portion of the total length of more than 10% of the sample, are advised to record instructions. There should be no impact to the environment caused by the optical fiber under measurement harm in the process of preparing a sample of. Unless otherwise specified in the detail specification, It recommended that the loose fiber samples around, rewind and cable attenuation coefficient at the wavelength of 1310nm response had no effect, rewind Zhang Liyi not more than 0.3N. The sample is placed horizontally, in order to avoid the impact of any macro bending, circling diameter should be greater than 150mm. ......
