GB/T 15972.41-2021 English PDF

Q: How long will the true-PDF of English version of GB/T 15972.41-2021 be delivered?

Upon your order, we will start to translate GB/T 15972.41-2021_English as soon as possible, and keep you informed of the progress. The lead time is typically 3 ~ 5 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of GB/T 15972.41-2021_English with my colleagues?

Yes. The purchased PDF of GB/T 15972.41-2021_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

Q: Should I purchase the latest version GB/T 15972.41-2021?

Yes. Unless special scenarios such as technical constraints or academic study, you should always prioritize to purchase the latest version GB/T 15972.41-2021 even if the enforcement date is in future. Complying with the latest version means that, by default, it also complies with all the earlier versions, technically.

US$499.00 · In stock
Delivery: <= 5 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 15972.41-2021: Specifications for optical fibre test methods - Part 41: Measurement methods and test procedures for transmission characteristics - Bandwidth
Status: Valid

GB/T 15972.41: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 15972.41-2021	499	Add to Cart	5 days	Specifications for optical fibre test methods - Part 41: Measurement methods and test procedures for transmission characteristics - Bandwidth	Valid
GB/T 15972.41-2008	439	Add to Cart	3 days	Specifications for optical fibre test methods -- Part 41: Measurement methods and test procedures for transmission and optical characteristics -- Bandwidth	Obsolete

Similar standards

YD/T 2554.1 GB/T 9771.1 GB/T 20186.1 GB/T 15972.40 GB/T 15972.33 GB/T 15972.34

Basic data

Standard ID: GB/T 15972.41-2021 (GB/T15972.41-2021)
Description (Translated English): Specifications for optical fibre test methods - Part 41: Measurement methods and test procedures for transmission characteristics - Bandwidth
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: M33
Word Count Estimation: 27,282
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 15972.41-2021: Specifications for optical fibre test methods - Part 41: Measurement methods and test procedures for transmission characteristics - Bandwidth

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Specifications for optical fibre test methods-Part 41.Measurement methods and test procedures for transmission characteristics-Bandwidth ICS 33.180.10 M33 National Standards of People's Republic of China Replace GB/T 15972.41-2008 Optical fiber test method specification. Part 41.Transmission characteristics Measurement method and test procedure bandwidth (IEC 60793-1-41.2010, Opticalfibres- Released on 2021-04-30 and implemented on 2021-11-01 State Administration of Market Supervision and Administration Issued by the National Standardization Management Committee

Foreword Ⅰ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 Abbreviations 2 5 Method overview 2 6 Test device 3 7 Samples and sample preparation 6 8 Procedure 7 9 Calculation 10 10 Length normalized 10 11 Results 10 Appendix A (informative appendix) Structure changes of this part compared with IEC 60793-1-41.2010 12 Appendix B (Normative Appendix) Intra-mode dispersion factor and normalized inter-mode dispersion limit 13 Appendix C (Normative Appendix) Optical fiber transfer function transfer function H(f), power spectrum |H(f)| and f3dB 16 Appendix D (Normative Appendix) Calculation of other expression functions 18 Appendix E (Normative Appendix) Mode Stirring Requirements for Full Injection of Multimode Fiber 19 Reference 23

Foreword

GB/T 15972 "Specifications for Optical Fiber Test Methods" consists of several parts, and its expected structure and corresponding international standards are. ---Part 10.General principles of measurement methods and test procedures (corresponding to IEC 60793-1-1); ---Part 20~Part 29.Measurement methods and test procedures of dimensional parameters (corresponding to IEC 60793-1-20 to IEC 60793- 1-29); ---Part 30~Part 39.Measurement methods and test procedures of mechanical properties (corresponding to IEC 60793-1-30 to IEC 60793- 1-39); ---Part 40~Part 49.Measurement methods and test procedures of transmission characteristics (corresponding to IEC 60793-1-40 to IEC 60793- 1-49); ---Part 50~Part 59.Environmental performance measurement methods and test procedures (corresponding to IEC 60793-1-50 to IEC 60793- 1-59). Among them, GB/T 15972.40~49 consists of the following parts. ---Part 40.Measurement methods and test procedures for transmission characteristics attenuation; ---Part 41.Measurement methods of transmission characteristics and test procedure bandwidth; ---Part 42.Measurement methods and test procedures for transmission characteristics. Wavelength dispersion; ---Part 43.Measurement methods of transmission characteristics and test procedures numerical aperture; ---Part 44.Measurement methods of transmission characteristics and test procedures cut-off wavelength; ---Part 45.Measurement methods and test procedures for transmission characteristics; Mode field diameter; ---Part 46.Transmission characteristics measurement methods and test procedures light transmittance changes; ---Part 47.Measurement methods and test procedures for transmission characteristics, macrobending loss; ---Part 48.Measurement methods and test procedures for transmission characteristics Polarization mode dispersion; ---Part 49.Differential modulus delay for measurement methods and test procedures of transmission characteristics. This part is part 41 of GB/T 15972. This section was drafted in accordance with the rules given in GB/T 1.1-2009. This part replaces GB/T 15972.41-2008 "Specification for optical fiber test methods Part 41.Measurement of transmission characteristics and optical characteristics Method and test method bandwidth". Based on the testing needs of new categories and new sub-categories of multimode optical fibers, this part is consistent with GB/T 15972.41-2008 In comparison, the main technical differences are as follows. ---Added the definition of transfer function and power spectrum (see Chapter 3); ---Added abbreviations (see Chapter 4); ---Added method C---Full injection mode bandwidth method calculated by DMD (see Chapter 5); ---Added the test requirements for A3 and A4 multimode fibers (see Chapter 1, 6.2, Appendix E); ---Added the requirements for the placement state of the tested fiber (see 7.4); ---Added length normalization requirements (see Chapter 10); ---Added the provisions of the intra-mode dispersion factor and the normalized inter-mode dispersion limit (see Appendix B); ---Added the requirements of fiber transfer function H(f), power spectrum |H(f)| and f3dB (see Appendix C); ---Added the calculation of other expression functions (see Appendix D); ---Added the mode-stirring requirement for the full injection condition of multimode fiber (see Appendix E). This part uses the redrafting method to modify and adopt IEC 60793-1-41.2010 "Optical Fiber Part 1-41.Measurement Method and Test Procedure Sequence bandwidth". Compared with international standards, the main structural changes of this part are as follows. ---According to the layout format and presentation requirements of my country's standards, some content arrangements have been adjusted, and the scope of IEC documents has been adjusted. The content is adjusted to the method overview chapter of this part, abbreviations have been added, and Appendix A has been added to explain the relationship between this part and the IEC chapter. Correspondence. Compared with IEC 60793-1-41.2010, the main technical differences and the reasons for this part are. ---In the normative reference documents, in order to adapt to the technical conditions of our country, the following technical differences have been adjusted. ● Replace IEC 60793-1-20 with GB/T 15972.20; ● Replace IEC 60793-1-42 with GB/T 15972.42; ● Replace IEC 60793-1-43 with GB/T 15972.43. ---This section adds the definition of terms for frequency response; ---In order to meet the requirements of broadband multimode fiber testing of the new sub-categories A1a.3 and A1a.4, this section adds A1a.3 and A1a.4 optical fiber Fiber measurement method. This section has made the following editorial changes. --- Modify the standard name to "Specifications for Optical Fiber Test Methods Part 41.Measurement Methods and Test Procedures for Transmission Characteristics width"; ---Corrected the formula reference error in the IEC file, and changed the formula B1 cited in 6.3 in the IEC file to the formula (13) of this part; ---Corrected the presentation error in IEC Appendix A, and changed the name of Table A.1 in Appendix A to "the highest expected color of commercial A1 optical fiber "Discrete" is amended to "Minimum expected IDF for commercial category A1 multimode fiber". Please note that some of the contents of this document may involve patents. The issuing agency of this document is not responsible for identifying these patents. This part was proposed by the Ministry of Industry and Information Technology of the People's Republic of China. This part is under the jurisdiction of the National Communication Standardization Technical Committee (SAC/TC485). Drafting unit of this section. Fiberhome Technology Group Co., Ltd. The main drafters of this section. Liu Cheng, Wang Dongxiang, He Shuping, Hu Guohua, Qi Qingqing, Yu Huang, He Maoyou, Zhou Huizhi, Chen Liming, Yao Di. The previous releases of the standards replaced by this part are as follows. ---GB/T 15972.41-2008. Optical fiber test method specification. Part 41.Transmission characteristics Measurement method and test procedure bandwidth

1 Scope

This part of GB/T 15972 specifies the test method for the bandwidth of multimode optical fiber, and establishes the test equipment, injection conditions, procedures, and calculations. Technical requirements for methods and results. This section applies to the measurement of the bandwidth of A1, A3, and A4 multimode optical fibers.

2 Normative references

The following documents are indispensable for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For undated reference documents, the latest version (including all amendments) is applicable to this document. GB/T 15972.20 Specification for optical fiber test methods Part 20.Dimensional parameter measurement methods and test procedures Optical fiber geometrical parameters (GB/T 15972.20-2021, IEC 60793-1-20.2014, MOD) GB/T 15972.42 Specification for optical fiber test methods Part 42.Transmission characteristics and optical characteristics measurement methods and test procedures Long dispersion (GB/T 15972.42-2021, IEC 60793-1-42.2010, MOD) GB/T 15972.43 Specification for optical fiber test methods Part 43.Transmission characteristics and optical characteristics measurement methods and test procedures Value aperture (GB/T 15972.43-2021, IEC 60793-1-43.2015, MOD) IEC 60793-1-49.2018 Optical fiber Part 1-49.Measurement method and test procedure Differential mode delay (Opticalfibres- Part 1-49.Measurementmethodsandtestprocedures-Differentialmodedelay)

3 Terms and definitions

The following terms and definitions apply to this document. 3.1 Bandwidth(-3dB) bandwidth(-3dB) The bandwidth value is equal to the minimum modulation frequency when the amplitude of the baseband transfer function of the fiber drops to a specific value. The value is usually half of the amplitude corresponding to zero frequency. Note. The bandwidth value is expressed by f3dB. 3.2 Transfer function The frequency-dependent complex discrete function is used to characterize the frequency domain response of the fiber under test. Note. Method A is to process the time domain data through Fourier transform to determine the frequency response. If you use a type that can measure both phase and amplitude Device, method B can be used to measure the transfer function. When using Fourier transform, method C is similar to method A. The transfer function is represented by H(f). Here Method A, Method B, and Method C are explained in Chapter 5. 3.3 Power spectrum A real discrete function related to frequency, which characterizes the amplitude of the frequency domain response of the fiber under test. Note. Method A and Method C use the transfer function to determine the power spectrum. Method B is obtained by the ratio of the measured amplitude of the tested fiber to the amplitude of the reference fiber. ......
