GB/T 15566.20-2021 English PDF

US$189.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 15566.20-2021: Public information guidance systems - Setting principles and requirements - Part 20: Urban area
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 15566.20-2021	189	Add to Cart	3 days	Public information guidance systems - Setting principles and requirements - Part 20: Urban area	Valid

Similar standards

GB/T 16903   GB/T 15565   GB/T 15566.1   GB/T 15566.2   GB/T 15566.3   GB/T 15566.4

Basic data

Standard ID: GB/T 15566.20-2021 (GB/T15566.20-2021)
Description (Translated English): Public information guidance systems - Setting principles and requirements - Part 20: Urban area
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: A22
Word Count Estimation: 10,181
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 15566.20-2021: Public information guidance systems - Setting principles and requirements - Part 20: Urban area

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Public information guidance systems - Setting principles and requirements - Part 20.Urban area ICS 01.080.01 A22 National Standards of People's Republic of China Principles and Requirements of Public Information Oriented System Setting Part 20.urban areas Part 20.Urbanarea Released on 2021-03-09 2021-10-01 implementation State Administration of Market Supervision and Administration Issued by the National Standardization Management Committee

Table of contents

Foreword Ⅰ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 The composition of the urban guidance system 1 4.1 System composition 1 4.2 Sub-guide system 1 4.3 Guiding Elements 2 5 General principles and requirements 2 6 Setup requirements 3 6.1 City entrance and exit guidance system 3 6.2 Public transportation guidance system 3 6.3 Block guidance system 3 6.4 Public service facilities and cultural and entertainment oriented system 4 6.5 Guide system for public facilities 5 Appendix A (informative appendix) City guidance system guidance example 6 Figure A.1 Example of setting up city-oriented information featuring tourism 6 Figure A.2 Example of setting up a block-oriented map of characteristic blocks 7

Foreword

GB/T 15566 "Principles and Requirements for the Establishment of Public Information Oriented System" is planned to be divided into the following parts. ---Part 1.General Provisions; ---Part 2.Civil Airport; ---Part 3.Railway passenger station; ---Part 4.Public transportation stations; ---Part 5.Shopping places; ---Part 6.Medical places; ---Part 7.Sports venues; ---Part 8.Hotels and restaurants; ---Part 9.Tourist Attractions; ---Part 10.Blocks; ---Part 11.Motor vehicle parking lot; ---Part 20.Urban areas. This part is part 20 of GB/T 15566. This section was drafted in accordance with the rules given in GB/T 1.1-2009. This part is proposed and managed by the National Graphic Symbol Standardization Technical Committee (SAC/TC59). Drafting organizations of this section. China National Institute of Standardization, National Railway Administration, Ministry of Culture and Tourism, Ministry of Transport, Beijing Municipal Commission of Communications, China Aerospace Standardization Institute, Beijing Vision 4D Urban Orientation System Planning and Design Co., Ltd. The main drafters of this section. Zhang Liang, Bai Dianyi, Chen Ziding, Wang Hui, Feng Liguang, An Xiaofen, Zhu Yiwei, Zou Chuanyu, Chen Yongquan, Wang Liming, Gong Fengqi. Principles and Requirements of Public Information Oriented System Setting Part 20.urban areas

1 Scope

This part of GB/T 15566 defines the composition of the urban area public information guidance system (hereinafter referred to as the city guidance system) and stipulates The setting principles and setting requirements of the guidance elements in the urban guidance system are discussed. This section applies to public information in urban areas such as city entrances and exits, public transportation stations, blocks, public services, cultural and entertainment venues, etc. The setting of the guidance system.

2 Normative references

The following documents are indispensable for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For undated reference documents, the latest version (including all amendments) is applicable to this document. GB 5768.2 Road Traffic Signs and Markings Part 2.Road Traffic Signs GB/T 10001 (all parts) Graphical symbols for public information GB/T 15565 Graphical Symbol Terms GB/T 15566 (all parts) Principles and requirements for setting up public information-oriented system GB/T 20501 (all parts) Design principles and requirements for guiding elements of public information guiding systems GB/T 31015 Public Information Orientation System Based on the Design and Setting Principles of Accessibility Requirements GB/T 31382 Principles and requirements for the establishment of urban tourism public information guidance system GB/T 31384 Specification for the Setting of Public Information Guidance System in Tourist Attractions GB/T 38654 Planning and Design Guidelines for Public Information Orientation System

3 Terms and definitions

The terms and definitions defined in GB/T 15565 apply to this document.

4 The composition of the urban guidance system

4.1 System composition The urban guidance system is composed of interrelated sub-guidance systems and guidance elements. 4.2 Sub-guide system The sub-guidance systems of the city guidance system include. ---Urban entrance and exit guidance system. provide information such as civil airports, railway passenger stations, passenger terminals and long-distance passenger stations; ---Public transportation guidance system. provide urban rail transit stations, bus (or trolleybus) stations and public transportation hubs, etc. information; ---Block guidance system. Provide information on urban public transportation facilities, roads and public service facilities; ......
