GB/T 15022.10-2023: Resin based reactive compounds used for electrical insulation - Part 10: Polyesterimide resin composite
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 15022.10-2023	129	Add to Cart	3 days	Resin based reactive compounds used for electrical insulation - Part 10: Polyesterimide resin composite	Valid

Similar standards

GB/T 20632.2 GB/T 20632.3 GB/T 11026.1 GB/T 15022.9 GB/T 15022.7 GB/T 15022.8

Basic data

Standard ID: GB/T 15022.10-2023 (GB/T15022.10-2023)
Description (Translated English): Resin based reactive compounds used for electrical insulation - Part 10: Polyesterimide resin composite
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K15
Classification of International Standard: 29.035.99
Word Count Estimation: 6,689
Date of Issue: 2023-12-28
Date of Implementation: 2024-07-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 15022.10-2023: Resin based reactive compounds used for electrical insulation - Part 10: Polyesterimide resin composite

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 29:035:99 CCSK15 National Standards of People's Republic of China Resin-based reactive compounds for electrical insulation Part 10: Polyesterimide resin composites Published on 2023-12-28 2024-07-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration Committee

PrefaceⅠ Introduction II 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Technical requirements 1 5 Test method 2 6 Inspection Rules 3 7 Marking, packaging, transportation and storage 3

Foreword

This document complies with the provisions of GB/T 1:1-2020 "Standardization Work Guidelines Part 1: Structure and Drafting Rules of Standardization Documents" Drafting: This document is Part 10 of GB/T 15022 "Resin-based reactive compounds for electrical insulation": GB/T 15022 has been released with Lower part: ---Part 1: Definitions and general requirements; ---Part 2: Test methods; ---Part 3: Filler-free epoxy resin compounds; ---Part 4: Unsaturated polyester-based impregnating resin; ---Part 5: Quartz filler epoxy resin composites; ---Part 6: Epoxy casting resin for insulation of Class 1E distribution transformers in nuclear power plants; ---Part 7: Epoxy anhydride vacuum pressure impregnation (VPI) resin; ---Part 8: Epoxy modified unsaturated polyester vacuum pressure impregnation (VPI) resin; ---Part 9: Resins for cable accessories; ---Part 10: Polyesterimide resin composites: Please note that some content in this document may be subject to patents: The publisher of this document assumes no responsibility for identifying patents: This document is proposed by the China Electrical Equipment Industry Association: This document is under the jurisdiction of the National Insulation Materials Standardization Technical Committee (SAC/TC51): This document was drafted by: Suzhou Jufeng Electrical Insulation System Co:, Ltd:, Wuxi Xinhongtai Electrical Technology Co:, Ltd:, China China Southern Power Grid Co:, Ltd: Ultra-High Voltage Transmission Company, Zhejiang Rongtai Technology Enterprise Co:, Ltd:, Xiamen Xiaoxun New Energy Technology Co:, Ltd:, Guilin Saimeng Testing Technology Co:, Ltd:, Zhejiang Bofei Electric Co:, Ltd:, Suzhou Taihu Electrical New Materials Co:, Ltd:, Guangdong Shun Deda Geoyuan New Materials Co:, Ltd:, Guilin Electrical Science Research Institute Co:, Ltd:, Xi'an Xidian Electrical Materials Co:, Ltd:, Sichuan Dongcai New Materials Co:, Ltd:, Guangdong Jiewei Electronics Co:, Ltd:, Xujue Electric Co:, Ltd:, Shanghai Wenyou Industrial Co:, Ltd:, CRRC Corporation Zhou Electric Locomotive Research Institute Co:, Ltd:, Guangdong Green Sheng Qingyuan Technology Co:, Ltd:, Shandong Zhaoyu Petroleum Technology Co:, Ltd:, Dongfang Electric Group Dongfang Electric Co:, Ltd:, Harbin Electric Power Equipment Co:, Ltd:, CRRC Zhuzhou Electric Co:, Ltd:, Guangdong Power Grid Co:, Ltd: Power Science Research Institute, CRRC Yongji Motor Co:, Ltd:, Shanghai Electric Group Shanghai Electric Machinery Factory Co:, Ltd:, Shandong Qilu Motor Manufacturing Co:, Ltd: Company, Hebei Jinneng Electric Power Technology Co:, Ltd: The main drafters of this document: Xia Yu, Zhou Cheng, Liu Haitao, Ge Fan, Chen Jisheng, Wang Mingjun, Liao Zhifei, Yang Liyi, Wei Chen, Ran Tao, Zhao Jie, Wu Hongmin, Li Cuicui, Hu Yunqing, Xia Hongwei, Cao Wanrong, Zhang Chunqi, Zhang Mengqiang, Du Chaoyun, Li Jiexia, Li Qiangjun, Ding Mingjun, Yuan Xiaoping, Zhao Zhili, Chen Peixian, Cheng Yanyuan, Zeng Xinghong, Xu Na, Chen Hongsheng, Fu Qiang, Liu Guanfang, Liu Xiangfei, Deng Xueyong, Wu Bing, He Mingpeng, Zhang Yun, Wei Jingsheng, Li Xuguang, Luo Chuanyong, Li Jian, Tao Yan:

Introduction

Resin-based active compound standards for electrical insulation are widely used in the research and development, production, quality inspection, sales, acceptance and technical delivery of this series of products: Flow etc: This document can guide the industry in testing and quality assessment of resin-based active compounds for electrical insulation, and can improve the quality of such products: Quality and application reliability: GB/T 15022 "Resin-based reactive compounds for electrical insulation" stipulates the definition and general requirements for resin-based reactive compounds for electrical insulation: The requirements, test methods, and individual material product standards are intended to be composed of the following parts: ---Part 1: Definitions and general requirements: The purpose is to determine the nomenclature, definition, classification and General requirements: ---Part 2: Test methods: The purpose is to determine test methods for resin-based reactive compounds for electrical insulation: ---Part 3: Filler-free epoxy resin compounds: The purpose was to determine the post-cured requirements for filler-free epoxy resin compounds: ---Part 4: Unsaturated polyester-based impregnating resin: The purpose is to determine the general requirements for unsaturated polyester-based impregnating resins: ---Part 5: Quartz filler epoxy resin compounds: The objective was to determine the requirements for quartz filler epoxy resin composites after curing: ---Part 6: Epoxy casting resin for insulation of Class 1E distribution transformers in nuclear power plants: The purpose is to determine the level 1E distribution transformer of the nuclear power plant Requirements, test methods, inspection rules, packaging, marking, storage and transportation of epoxy casting resin for device insulation: ---Part 7: Epoxy anhydride vacuum pressure impregnation (VPI) resin: The purpose is to identify epoxy anhydride vacuum pressure impregnation (VPI) resins requirements, test methods, inspection rules and packaging, marking, storage and transportation: ---Part 8: Epoxy modified unsaturated polyester vacuum pressure impregnation (VPI) resin: The purpose is to determine the epoxy modified unsaturated polyester Classification, requirements, test methods, inspection rules and packaging, marking, storage and transportation of vacuum pressure impregnation (VPI) resin: ---Part 9: Resins for cable accessories: The purpose is to determine the terms and definitions, nomenclature, type testing, and supply of resins for cable accessories: applications, packaging, logos and labels: ---Part 10: Polyesterimide resin composites: The purpose is to determine the use of electrically heated-UV curable polyesterimide impregnation for electrical insulation: Technical requirements, test methods, inspection rules and marking, packaging, storage and transportation of resin composites: Resin-based reactive compounds for electrical insulation Part 10: Polyesterimide resin composites

1 Scope

This document specifies the technical requirements, inspection rules, markings, and packaging of electrically heated-UV curable polyesterimide resin composites for electrical insulation: packaging, transportation and storage, and the corresponding test methods are described: This document is applicable to electric heating-UV curing polyesterimide resin composites for motors with heat resistance levels of 180 (H) and:200 (C): compound: Note: This type of product is composed of heat-resistant unsaturated polyesterimide resin, environmentally friendly reactive cross-linking monomer and composite initiator: Electric heating-UV curing process one It generally refers to an insulation treatment process in which after being impregnated with insulating resin, the motor stator winding conductors are energized to generate heat and ultraviolet (UV)-assisted curing is used:

2 Normative reference documents

The contents of the following documents constitute essential provisions of this document through normative references in the text: Among them, the dated quotations For undated referenced documents, only the version corresponding to that date applies to this document; for undated referenced documents, the latest version (including all amendments) applies to this document: GB/T 15022:2-2017 Resin-based reactive compounds for electrical insulation Part 2: Test methods GB/T 31838:2 Dielectric and resistive properties of solid insulating materials Part 2: Resistive properties (DC method) Volume resistance and volume Sheet resistivity

3 Terms and definitions

There are no terms or definitions to be defined in this document:

4 Technical requirements

The technical requirements of this product should comply with the provisions of Table 1: Table 1 Technical requirements Serial number performance unit requirements 1 Appearance - light brown transparent liquid, no mechanical impurities 2 Viscosity, (23±1)℃ mPa·s 1600~2500 3 Gel time, (100±2)℃ min 10~20 4 Curing volatile matter, (150±2)℃, 2h % ≤2 5 Water absorption, (23±2)℃ water immersion, 24h % ≤0:5 ......
