GB/T 14598.301-2020: Technical requirements for power system continuous recorder
Status: Valid

GB/T 14598.301: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 14598.301-2020	779	Add to Cart	6 days	Technical requirements for power system continuous recorder	Valid
GB/T 14598.301-2010	RFQ	ASK	6 days	General specification of transformer fault oscillograph equipment for microprocessor-based generator	Obsolete

Similar standards

DL/T 540 GB/T 38953 GB/T 37155.2 GB/T 14598.2 GB/T 14598.300 GB/T 14598.302

Basic data

Standard ID: GB/T 14598.301-2020 (GB/T14598.301-2020)
Description (Translated English): Technical requirements for power system continuous recorder
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K45
Classification of International Standard: 29.240.01
Word Count Estimation: 42,446
Date of Issue: 2020-06-02
Date of Implementation: 2020-12-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 14598.301-2020: Technical requirements for power system continuous recorder

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Technical requirements for continuous recording devices in power systems) ICS 29.240.01 K45 National Standards of People's Republic of China Replace GB/T 14598.301-2010 Technical requirements for continuous recording devices in power systems 2020-06-02 release 2020-12-01 implementation State Administration of Market Supervision and Administration Issued by the National Standardization Management Committee

Foreword Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 2 4 Acronyms 2 5 Technical requirements 2 5.1 Rated parameters 2 5.2 DC working power supply 3 5.3 Environmental conditions 3 5.4 Main functions of the device 4 5.5 Technical performance of the device 7 5.6 Power consumption 13 5.7 Overload capacity 13 5.8 Insulation performance 14 5.9 Humidity and heat resistance 14 5.10 Mechanical properties 14 5.11 EMC requirements 15 5.12 Continuous power supply 16 5.13 Structure and appearance requirements 16 5.14 Safety requirements 17 6 Test method 17 6.1 Test conditions 17 6.2 Environmental test 17 6.3 Main function and technical performance test 17 6.4 Power consumption test 22 6.5 Overload capability test 22 6.6 Insulation performance test 22 6.7 Damp heat test 23 6.8 Mechanical performance test 23 6.9 Electromagnetic compatibility performance test 24 6.10 Continuous power-on test 26 6.11 Structural and visual inspection 26 6.12 Safety requirements test 26 7 Inspection rules 26 7.1 Inspection classification 26 7.2 Type test 26 7.3 Factory test 27 8 Identification, packaging, transportation and storage 27 8.1 Logo 27 8.2 Packaging 28 8.3 Transportation 28 8.4 Storage 28 9 Completeness of delivery 28 9.1 Documents supplied with the device 28 9.2 Accessories supplied with the device 28 10 Quality guarantee period 29 Appendix A (informative appendix) Basic requirements for device models 30 Appendix B (informative appendix) Definition and criteria for abnormal alarms on networks and messages 34

Foreword

GB/T 14598 is divided into the following parts. ---GB/T 14598.1 Electrical Relay Part 23.Contact Performance; ---GB/T 14598.2 Measuring relays and protection devices Part 1.General requirements; ---GB/T 14598.3 Electrical relays Part 5.Insulation coordination requirements and tests for measuring relays and protection devices; ---GB/T 14598.6 Electrical relays Part 18.Dimensions with or without general relays; ---GB/T 14598.8 Electrical Relay Part 20.Protection System; ---GB/T 14598.23 Electrical relays Part 21.Measurement of vibration, shock, collision and earthquake of relays and protection devices Test Part 3.Earthquake test; ---GB/T 14598.24 Measuring relays and protection devices. Part 24.Power system transient data exchange (COMTRADE) common format; ---GB/T 14598.26 Measuring relays and protection devices Part 26.Electromagnetic compatibility requirements; ---GB/T 14598.27 Measuring relays and protection devices Part 27.Product safety requirements; ---GB/T 14598.121 Measuring relays and protection devices Part 121.Distance protection function requirements; ---GB/T 14598.127 Measuring relays and protection devices Part 127.Over/under voltage protection function requirements; ---GB/T 14598.149 Measuring relays and protection devices Part 149.Functional requirements for electrothermal relays; ---GB/T 14598.151 Measuring relays and protection devices Part 151.Over/under current protection function requirements; ---GB/T 14598.300 General technical requirements for transformer protection devices; ---GB/T 14598.301 Power system continuous recording device technical requirements; ---GB/T 14598.302 Technical requirements for arc protection device; ---GB/T 14598.303 General technical requirements for digital motor comprehensive protection device. This part is part 301 of GB/T 14598. This section was drafted in accordance with the rules given in GB/T 1.1-2009. This part replaces GB/T 14598.301-2010 "Technical Requirements for Micro-type Generator Transformer Fault Recorder". Compared with GB/T 14598.301-2010, the main technical changes are as follows. --- Added definitions for continuous recording, trigger recording, conventional electrical data recording, phasor data recording, and traveling wave data recording (see section Chapter 3); --- Added abbreviations (see Chapter 4); --- Added several functions of SV/GOOSE access and related exception handling, clock management, traveling wave data recording and phasor data recording Can be required (see Chapter 5, 4.6 of the.2010 edition); --- Added performance requirements for clock management, traveling wave data recording and phasor data recording (see Chapter 5, 4.7 of the.2010 edition); --- Added several test methods for SV/GOOSE access and related exception handling, traveling wave data recording and phasor data recording (see Chapter 6,.2010 version 5.5); ---Revised the relevant contents of signs, labels, instruction manuals, packaging, transportation, storage, and merged (see Chapter 8,.2010 edition) Chapter 7, Chapter 8); ---Modified the complete package and quality assurance related to the supply (see Chapter 9, Chapter 10,.2010 edition of Chapter 9, Chapter Chapter 10); --- Deleted Appendix A (Micro-transformer transformer fault recorder communication protocol), added the basic requirements of the device model, network And the definition and criterion of abnormal message warning (see Appendix A and Appendix B). Please note that some content of this document may involve patents. The issuer of this document does not assume responsibility for identifying these patents. This part is proposed by China Electrical Equipment Industry Association. This part is under the jurisdiction of the National Standardization Technical Committee for Measuring Relays and Protection Equipment (SAC/TC154). This section was drafted by. State Grid Hebei Electric Power Co., Ltd., Xuchang Cape Electric Research Institute Co., Ltd., State Grid Co., Ltd. Electric Power Dispatching and Control Center, State Grid Hebei Electric Power Research Institute, Wuhan Zhongyuan Huadian Technology Co., Ltd. Dian Nanjing Automation Co., Ltd., Nanjing NARI Jibao Electric Co., Ltd., Guodian NARI Technology Co., Ltd., Changyuan Shenrui Jibao Automation Co., Ltd., Beijing Sifang Jibao Engineering Technology Co., Ltd., Jicheng Electronics Co., Ltd., Ziguang Measurement and Control Co., Ltd., Xu Jidian Gas Co., Ltd., Shandong Shanda Electric Power Technology Co., Ltd., Aerospace Yinshan Electric Co., Ltd., Dongguan Institute of Technology, State Grid Corporation of China Division North China Branch, State Grid Corporation East China Branch, State Grid Jibei Electric Power Co., Ltd., State Grid Jiangsu Electric Power Co., Ltd., Yunnan Power Grid Co., Ltd. Responsible company Kunming Power Supply Bureau, State Grid Gansu Electric Power Research Institute, State Grid Hunan Electric Power Co., Ltd. Power Science Research Institute, State Grid Zhejiang Electric Power Co., Ltd. Jiaxing Power Supply Company, State Grid Shandong Electric Power Company Liaocheng Power Supply Company, Xuchang Kaipu Inspection and Research Institute Co., Ltd., China Electric Power Research Institute Co., Ltd., State Grid Electric Power Research Institute Co., Ltd., China Energy Construction Group East China Electric Power Research Institute Co., Ltd. The main drafters of this section. Zhao Zigang, Li Zhiyong, Liu Dan, Wang Xianzhi, Zheng Junlin, Jiang Xiaoliang, Hou Xueyong, Pang Zhijun, Zhu Huiwen, Wu Fangying, Lei Rongchao, Hu Jiawei, Huang Jidong, Xu Tengfei, Wang Liang, Zhang Zhaoyun, Liu Yimin, Han Jun, Wu Tongxin, Chen Hao, Wei Yingli, Li Yong, Zheng Wei, Zhu Weijun, Yin Weibin, Liu Qi, Zhuang Liangwen, Tang Yi, Xu Zhijing, Lou Guocai. The previous versions of the standard replaced by this part are as follows. ---GB/T 14598.301-2010. Technical requirements for continuous recording devices in power systems

1 Scope

This part of GB/T 14598 specifies the technical requirements, test methods, and inspections of continuous recording devices for power systems (hereinafter referred to as devices) Rules, marking, packaging, transportation, storage, completeness of supply, quality assurance period requirements. This section applies to continuous recording devices of power systems used in substations (converter stations) and power plants, as the design, manufacture and inspection of such devices The basis for verification and operation.
