GB/T 14174-2012 English PDF

US$299.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 14174-2012: Large caliber liquid nitrogen container
Status: Valid

GB/T 14174: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 14174-2012	299	Add to Cart	3 days	Large caliber liquid nitrogen container	Valid
GB 14174-1993	319	Add to Cart	3 days	Large calibre liquid nitrogen container	Obsolete

Similar standards

GB/T 14251   GB 13042   GB/T 14188   GB/T 45451.1   GB/T 45451.2   GB/T 45318

Basic data

Standard ID: GB/T 14174-2012 (GB/T14174-2012)
Description (Translated English): Large caliber liquid nitrogen container
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: A82
Classification of International Standard: 55.120
Word Count Estimation: 13,158
Older Standard (superseded by this standard): GB 14174-1993
Quoted Standard: GB 150.3; GB/T 191-2008; GB/T 3198-2010; GB/T 3280-2007; GB/T 4237-2007; GB/T 6388-1986; GB/T 13550-1992; GB/T 16958-2008; GB/T 18443.2; GB/T 18443.3; GB/T 18443.5; GB/T 18443.8; GB 24511; HG/T 2690-1995; SN/T 0273-2002
Regulation (derived from): National Standards Bulletin No. 42 of 2012
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the austenitic stainless steel large diameter liquid nitrogen containers (hereinafter referred to as the container) the terms and definitions, classification, technical requirements, test methods, inspection rules and signs, packag

GB/T 14174-2012: Large caliber liquid nitrogen container

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Large caliber liquid nitrogen container ICS 55.120 A82 National Standards of People's Republic of China Replacing GB 14174-1993 Large caliber liquid nitrogen containers Issued on. 2012-12-31 2013-07-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard is based on GB/T 1.1-2009 given rule drafting. This standard replaces GB 14174-1993, compared with GB 14174-1993, there are the following changes. --- Chapter 1, "Scope" increased scope shall not apply; --- Increased Chapter 3, "Terms and definitions" and the foundation "large caliber liquid nitrogen containers main terminology" in the original Appendix A (Supplement) Carried out on the appropriate additions, deletions and modifications; --- Original Chapter 3, "product models, specifications" to Chapter 4, "category", and large caliber liquid nitrogen containers directly into mouth and two partial mouth category; --- Original 1 "Structure Representation" to be modified, and the words "straight mouth type container structure diagram"; --- Added Figure 2 "Partial opening type container structure diagram"; --- Original Chapter 4, "technical requirements" to Chapter 5, and increases the technical requirements of flatfish type products; --- Increased by 5.1 "General requirements"; --- An increase of 5.2 "material and an outer member," added the insulation material and the welding material requirements; --- Increased 5.3 "design"; --- Canceled a Table 1 for product diameter, height, empty weight requirements; --- Table 1, the original product daily evaporation rate index appropriate changes, and adds static evaporation rate index flatfish type products; --- Original table 2 to Table 4 "neck tube diameter tolerance" and cancel the provisions of the original table 2 in the plug body diameter; --- On 5.4 "manufacturing" requirements, appropriate complementary; Adjusted 6.1 --- "effective volume" methods of measurement; --- An increase of 6.3 "sandwich vacuum degree" methods of measurement; --- Clear 6.4 "sandwich vacuum leak rate" measurement method; --- Canceled a 6.2 "unqualified category"; --- A "type test" instead of the original "periodic inspection"; --- On 8.2 "packaging" made the necessary additional provisions. This standard by the National Standardization Technical Committee of the boiler pressure vessel (SAC/TC262) and focal points. This standard was drafted. Chengdu Golden Phoenix Liquid Nitrogen Container Co., Ltd., Shanghai Gas Industry Association, Shanghai Jiaotong University, Shenyang Xinguang hypothermia Container Co., Ltd., Leshan East Asia Electrical and Mechanical Industry and Trade Company, China Special Equipment Inspection and Research Institute, Shanghai Huayi Equipment Engineering Co., Ltd., the National Low Temperature container Quality Supervision and Inspection Center, Shanghai Institute of Special Equipment Inspection. The main drafters of this standard. Li Zongji, security concept, in Tong, Luxue Sheng, Liu Yuanming, Wei-Ming Zhou, Chen Zhaohui, Weiyong Biao, Ya-Yu, Teng Junhua, Chen Union. This standard replaces the standards previously issued as follows. --- GB 14174-1993. Large caliber liquid nitrogen containers

1 Scope

1.1 standard austenitic stainless steel large caliber liquid nitrogen containers (hereinafter referred to as the container) terms and definitions, classifications, technical requirements, test Test methods, inspection rules and signs, packaging, storage and transportation requirements. 1.2 This standard applies to the storage of liquid nitrogen at atmospheric pressure, the effective volume of not more than 1830L, with a caliber of 315mm high vacuum multi-layer of absolute Thermal containers. 1.3 This standard does not apply to use of containers. --- With pressure storage of liquid nitrogen; --- Other cryogenic liquid storage and liquid oxygen.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB 150.3 pressure vessels - Part 3. Design GB/T 191-2008 Packaging - Pictorial signs GB/T 3198-2010 aluminum and aluminum foil GB/T 3280-2007 cold-rolled stainless steel sheet and strip GB/T 4237-2007 hot-rolled stainless steel sheet and strip GB/T 6388-1986 transport package shipping mark GB/T 13550-1992 5A molecular sieve and test methods GB/T 16958-2008 biaxially oriented polyester film for packaging GB/T 18443.2 vacuum insulation cryogenic device performance test methods - Part 2. Vacuum Measurement GB/T 18443.3 vacuum insulation cryogenic device performance test methods - Part 3. leak rate measurement GB/T 18443.5 vacuum insulation cryogenic device performance test methods - Part 5. Static evaporation rate measurement GB/T 18443.8 vacuum insulation cryogenic device performance test methods - Part 8. volume measurement GB 24511 pressure equipment with stainless steel sheet and strip HG/T 2690-1995 13X molecular sieves SN/T 0273-2002 and export goods transport packaging wooden boxes for the inspection

3 Terms and Definitions

The following terms and definitions apply to this document. 3.1 Mezzanine interspace Confined space formed between the liner and the shell of the container. 3.2 High vacuum multi-layer insulation highvacuummulti-layerinsulation Multilayer insulation layer disposed within the spatial separation of the insulating material heat radiation screen, and high vacuum pumping adiabatically formed. ......
