GB/T 13277.4-2015 English PDF

US$339.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 13277.4-2015: Compressed air -- Part 4: Test methods for solid particle content
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 13277.4-2015	339	Add to Cart	3 days	Compressed air -- Part 4: Test methods for solid particle content	Valid

Similar standards

GB/T 13277.1   GB/T 4976   GB/T 2888   GB/T 13277.8   GB/T 13277.9   GB/T 13277.7

Basic data

Standard ID: GB/T 13277.4-2015 (GB/T13277.4-2015)
Description (Translated English): Compressed air -- Part 4: Test methods for solid particle content
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J72
Classification of International Standard: 23.14
Word Count Estimation: 16,161
Date of Issue: 2015-12-31
Date of Implementation: 2016-06-30
Quoted Standard: GB/T 3853; GB/T 4975; GB/T 17446; ISO 8573-7
Adopted Standard: ISO 8573-4-2001, MOD
Regulation (derived from): State Standard Announcement 2015 No.43
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the methods for measuring the concentration of particles of different sizes in compressed air, including selection of methods, sampling techniques, measurement methods, results evaluation, uncertainty analysis and test reports. This standard applies to the counting of solid particles in compressed air.

GB/T 13277.4-2015: Compressed air -- Part 4: Test methods for solid particle content

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Compressed air.Part 4. Test methods for solid particle content ICS 23.140 J72 National Standards of People's Republic of China Compressed air Part 4. Solid particle measurement methods (ISO 8573-4..2001, MOD) 2015-12-31 released 2016-06-30 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People 's Republic of China China National Standardization Management Committee released Directory Preface III 1 Scope 1 2 normative reference document 1 3 Terms and definitions 1 4 units 1 5 particles 2 6 Method of Selection Guide 2 7 sampling technology 2 Test Method 6 Evaluation of test results 7 Uncertainty 7 11 Report 8 Appendix A (informative) Introduction to measurement methods 9 Appendix B (Informative Annex) Sampling Test Report on Solid Particulate Content in Compressed Air 11 Appendix C (informative) The technical differences between this section and ISO 8573-4..2001 and their causes 12

Foreword

GB/T 13277 "Compressed air" is divided into 9 parts. - Part 1. Pollutant Purification Level; - Part 2. Suspended oil content measurement method; - Part 3. Humidity measurement method; - Part 4. Solid particle measurement methods; - Part 5. Methods for the measurement of oil vapor and organic solvents; - Part 6. Measurement of gaseous pollutant content; - Part 7. Measurement of active microbial content; - Part 8. Solid particle mass concentration measurement method; Part 9. Methods for the measurement of liquid water content. This part is part 4 of GB/T 13277. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This part uses the re-drafting method to modify ISO 8573-4..2001 "Compressed air Part 4. Solid particle measurement method" (English Version). Taking into account our national conditions, this part of the use of ISO 8573-4..2001, made some changes. The technical differences have been incorporated into the text And in the margins of the terms to which they relate. These technical differences and their originals are given in Appendix C For a list of references. For ease of use, this section also makes the following editorial changes. a) the word "international standard" is replaced by the words "this part"; b) Replace the comma as a decimal point with a decimal point "." c) Replace "bar" with "MPa" for pressure units; d) Deleting ISO 8573-4..2001 Preface. This part is made by the China Machinery Industry Federation. This part is headed by the National Standardization Technical Committee of Compressors (SAC/TC145). This part of the drafting unit. Hefei General Machinery Research Institute, Hangzhou Risheng purification equipment Co., Ltd., Guangzhou, Guangdong and Guangdong purification Technology Co., Ltd. Division, Wuxi City, Ling Ling Filter Equipment Co., Ltd., Hefei General Environmental Control Technology Co., Ltd., Shanghai ultrafiltration compressor purification equipment Limited company, Xi'an joint ultrafiltration purification Equipment Co., Ltd., Hangzhou Bi than Filter Technology Co., Ltd., Shenzhen Hong-day purification equipment technology Limited company. This part of the main drafters. Ren Fang, Tan Yuejin, Li Jinlu, Bao Jun, Zhang Jian, Wang Heguang, Yang Yaofeng, Zhang Jianmin, Li Daming, Feng Jinhu, Liu Baifan. Compressed air Part 4. Solid particle measurement methods

1 Scope

This part of GB/T 13277 specifies the method of measuring the concentration of particles of different sizes in compressed air, including the selection of methods, Technology, measurement methods, results assessment, uncertainty analysis and test reports. This part applies to the counting of solid particles in compressed air. Note 1. The method described in this section is suitable for determining the grade 0 to 5 particles defined in GB/T 13277.1 "Compressed Air Part 1. Pollutant Purification Class" concentration. Note 2. ISO 8573-8 "Compressed air Part 8. Solid particle mass concentration measurement method" The method described is suitable for determining GB/T 13277.1 "compression Air Part 1. Pollutant Purification Level "defined by the 6 to 7 particle concentration.

2 normative reference documents

The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. GB/T 3853 Volumetric Compressor Acceptance Test (GB/T 3853-1998, eqvISO 1217..1996) GB/T 4975 Volumetric Compressor Terminology (GB/T 4975-1995, eqvISO 3857-1. 1977, ISO 3857-2. 1977) GB/T 17446 fluid transmission system and component vocabulary (GB/T 17446-2012, ISO 5598..2008, IDT) ISO 8573-7 Compressed air - Part 7. Measurement of active microbial content (Compressedair-Part 7. Test methodsforviablemicrobiologicalparticlecontent)

3 terms and definitions

GB/T 17446, GB/T 4975 and GB/T 3853 and the following terms and definitions apply to this document. 3.1 Solid particles Tiny individual solid matter. 3.2 Microbial particles microbiological factors Solid particles formed by living microbes. 3.3 Aerodynamic particle diameter In air without air, at normal temperature, pressure and relative water vapor pressure, with the same specific speed (in the absence of air in the weight Force acceleration), the density of 1g/cm3 of the ball is equivalent to the particle diameter.

4 units

The units used in this section are units commonly used by the International System of Units (SI). ......
