GB/T 11356.2-2023 English PDF

Q: How long will the true-PDF of English version of GB/T 11356.2-2023 be delivered?

Upon your order, we will start to translate GB/T 11356.2-2023_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of GB/T 11356.2-2023_English with my colleagues?

Yes. The purchased PDF of GB/T 11356.2-2023_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

Q: Should I purchase the latest version GB/T 11356.2-2023?

Yes. Unless special scenarios such as technical constraints or academic study, you should always prioritize to purchase the latest version GB/T 11356.2-2023 even if the enforcement date is in future. Complying with the latest version means that, by default, it also complies with all the earlier versions, technically.

US$449.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 11356.2-2023: Belt drives - Geometrical inspection of grooves for classical and narrow V-Pulleys - Part 2: System based on effective width
Status: Valid

GB/T 11356.2: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 11356.2-2023	449	Add to Cart	4 days	Belt drives - Geometrical inspection of grooves for classical and narrow V-Pulleys - Part 2: System based on effective width	Valid
GB/T 11356.2-1997	319	Add to Cart	3 days	Belt drives. Pulley for classical and narrow V-belts drives (system based on effective width). Geometrical inspection of groove	Obsolete

Similar standards

GB/T 11357 GB/T 10414 GB/T 13487 GB/T 11362 GB/T 11356.1

Basic data

Standard ID: GB/T 11356.2-2023 (GB/T11356.2-2023)
Description (Translated English): Belt drives - Geometrical inspection of grooves for classical and narrow V-Pulleys - Part 2: System based on effective width
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J18
Classification of International Standard: 21.220.10
Word Count Estimation: 22,221
Date of Issue: 2023-11-27
Date of Implementation: 2024-06-01
Older Standard (superseded by this standard): GB/T 11356.2-1997
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 11356.2-2023: Belt drives - Geometrical inspection of grooves for classical and narrow V-Pulleys - Part 2: System based on effective width

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 21:220:10 CCSJ18 National Standards of People's Republic of China Replace GB/T 11356:2-1997 Belt drive ordinary and narrow V pulley groove inspection Part 2: Effective width system [ISO 9980:2012,Beltdrives-GroovedpuleysforV-belts(systembasedon Published on 2023-11-27 2024-06-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration Committee

Foreword

This document complies with the provisions of GB/T 1:1-2020 "Standardization Work Guidelines Part 1: Structure and Drafting Rules of Standardization Documents" Drafting: This document is Part 2 of GB/T 11356: GB/T 11356 has published the following parts: ---Belt drive V pulley (standard width system) groove inspection (GB/T 11356:1); --- Belt drive ordinary and narrow V pulley groove inspection Part 2: Effective width system (GB/T 11356:2): This document replaces GB/T 11356:2-1997 "Belt drive pulleys for ordinary and narrow V-belt drives (effective width system) Groove inspection "Experience", compared with GB/T 11356:2-1997, in addition to structural adjustments and editorial changes, the main technical changes are as follows: a) Changed the effective width, groove angle, groove depth, maximum increment of groove top, and maximum depth of groove top arc symbols (see Figure 1 and Table 1,:1997 version) Figure 1 and Table 1); b) Changed the limit gauge width and angle symbols (see Figures 2 and 7, Figures 2 and 7 of the:1997 edition); c) The limit gauge has been changed to mark the requirements for the minimum end αmin and the maximum end αmax (see 5:2:1, 3:2:1 of the:1997 edition); d) Added dimensional requirements for wheel groove section inspection limit gauges for non-united V-belts (see 5:2:2, 3:2:2 of the:1997 edition); e) Added dimensional requirements for wheel groove section inspection limit gauges for combined V-belts (see 5:2:3, 3:2:3 of the:1997 edition); f) The symbol of the correction item has been changed (see Figure 13, Figure 13 of the:1997 version); g) Changed the schematic diagram of circular runout inspection (see Figure 14, Figure 14 of the:1997 edition); h) Increased end face circular runout (see Figure 14, Figure 14 of the:1997 edition); i) Additional tests added (see Chapter 9): This document is modified to adopt ISO 9980:2012 "Belt Drive V Pulley (Effective Width System) Groove Inspection": This document adds two chapters: "Normative Reference Documents" and "Terms and Definitions": Compared with ISO 9980:2012, this document has made the following structural adjustments: ---Changed the arrangement of the diagrams (see Chapter 5): The technical differences between this document and ISO 9980:2012 and their reasons are as follows: --- Added normative references to GB/T 6931:1 and GB/T 6931:2 (see Chapter 3) to increase operability and facilitate the use of this document application; --- Added normative references to GB/T 10413 (see 5:1, 6:1:1, 7:1:1, 7:1:2, Chapter 8) to increase operability and facilitate Application of this document; ---Added the requirement that the limit gauge mark the minimum end αmin and the maximum end αmax (see 5:2:1) to increase operability and facilitate this article Application of software; ---Added the dimensional requirements for the wheel groove section inspection limit gauge for non-united V-belts and the wheel groove section inspection limit gauge for united V-belts: requirements (see 5:2:2, 5:2:3) to increase operability and facilitate the application of this document; ---Added Formula 1 (see 6:2) to increase operability and facilitate the application of this document; ---The symbol for measuring ball or measuring rod diameter has been changed (see 6:2, Chapter 7) to coordinate with existing national standards; ---Deleted the reference B in circular runout inspection (see Chapter 6 of ISO 9980:2012) to increase operability and facilitate the preparation of this document application; ---Added end face circular runout inspection (see Chapter 8) to more standardize product quality; ---Added other inspection methods (see Chapter 9) to guide specific applications: The following editorial changes have been made to this document: ---Added Appendix A (informative) "Special limit gauge inspection of effective width, groove depth and groove spacing of wheel groove section for non-united V-belts": Please note that some content in this document may be subject to patents: The publisher of this document assumes no responsibility for identifying patents: This document is proposed by China Machinery Industry Federation: This document is under the jurisdiction of the National Technical Committee on Standardization of Pulleys and Belts (SAC/TC428): This document was drafted by: Sichuan Deen Precision Technology Co:, Ltd:, China Machinery Productivity Promotion Center Co:, Ltd:, Nanjing Special Equipment Equipment Safety Supervision and Inspection Institute, Shenzhen Hefa Gear Machinery Co:, Ltd:, Ruiniu Co:, Ltd:, Huzhou Ruige Logistics Technology Co:, Ltd: Division, Wuhu Precision Transmission System Research Institute, Weishi County Jiulong Rubber and Plastic Co:, Ltd:, Jin Jiulong Industrial Co:, Ltd:, Zhejiang Dongxing Auto Parts Co:, Ltd: Co:, Ltd:, Jiangxi Kangqi Industrial Co:, Ltd:, Sichuan Ruidi Jiayuan Machinery Co:, Ltd:, Qingdao Product Quality Inspection Institute, Shijiazhuang Kaipu Special Power Transmission Machinery Co:, Ltd:, Jilin University: The main drafters of this document: Lei Yongzhi, Xie Longde, Ding Shuqing, Qin Shuan, Cao Xiaolin, Zhu Shusheng, Yang Wei, Zhu Liusheng, Tao Dazhong, Zhang Liujie, Jin Chongli, Yu Caiping, Li Xin, Hao Yongliang, Liu Limin, Ni Minmin, Feng Zengming, Zhou Peng: The previous versions of this document and the documents it replaces are as follows: ---First published as GB 11356-1989 in 1989, and published in parts during the first revision in:1997: This document corresponds to GB/T 11356:2-1997; ---This is the second revision:

Introduction

V-belt transmission is one of the important transmission methods in belt transmission: Ordinary and narrow V-belt transmission are the most basic forms of V-belt transmission: Ordinary and narrow V-belt transmission can be divided into two series: standard width system and effective width system: It is widely used in machine tools, mining machinery, petroleum machinery, coal mining machinery, woodworking machinery, etc: Industrial machinery, garden machinery, agricultural machinery and other fields: As early as 1989, my country issued GB 11356-1989 "General and narrow V-belt transmission "Pulley Groove Inspection" was revised in:1997 and was revised into two parts of the standard based on the procurement standards---GB/T 11356:1-1997 "Belt Transmission Pulleys for ordinary and narrow V-belt drives (standard width system) Groove inspection" and GB/T 11356:2-1997 "Belt drives for ordinary and narrow V-belts" Belt drive pulley (effective width system) groove inspection", in:2008 completed GB/T 11356:1-2008 "Belt drive V pulley (base width) System) Groove Inspection" revision work: GB/T 11356 is designed to guide the groove shape inspection of ordinary and narrow V-pulleys, and detect their consistency with the standard pulley groove shape through mechanical methods: properties, but no rapid or continuous inspection methods for controlling the geometries of pulley products are specified: GB/T 11356 is intended to consist of two parts: ---Part 1: Base width system: The purpose is to establish groove inspection specifications applicable to standard width V-pulleys: ---Part 2: Effective width system: The purpose is to establish groove inspection specifications suitable for effective width V-pulleys: Belt drive ordinary and narrow V pulley groove inspection Part 2: Effective width system

1 Scope

This document specifies the routine inspection method for the groove shape of V-pulleys with narrow effective width: This document is applicable to the inspection of basic dimensional parameters of narrow V-belt pulleys (effective width system): The corresponding V-belts can be single or combined belts:

2 Normative reference documents

The contents of the following documents constitute essential provisions of this document through normative references in the text: Among them, the dated quotations For undated referenced documents, only the version corresponding to that date applies to this document; for undated referenced documents, the latest version (including all amendments) applies to this document: GB/T 6931:1 Belt drive terminology Part 1: Basic terminology GB/T 6931:2 Belt drive terminology Part 2: V-belt and poly-V belt drive (GB/T 6931:2-2020, ISO 1081: 2013,MOD) GB/T 10413 Narrow V-belt pulley (effective width system) (GB/T 10413-2002, ISO 5290:2001, MOD)

3 Terms and definitions

The terms and definitions defined in GB/T 6931:1 and GB/T 6931:2 apply to this document:

4 basic procedures

The inspection of pulleys should be carried out according to the following four continuous inspection procedures: a) Groove cross-section inspection; b) Groove spacing inspection; c) Effective diameter inspection; d) Circular runout inspection: 5 Groove cross-section inspection 5:1 Groove cross-section dimensions The groove cross-section size should comply with the regulations of GB/T 10413: The actual outer diameter of the pulley should not be greater than de 2δh1, and the outermost end of the straight edge of the pulley groove should be straight: The minimum diameter is de-2δh2: The test parameters are shown in Figure 1 and Table 1: ......
