GB/T 10107.2-2012 English PDF

US$209.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 10107.2-2012: Cycloidal drives -- Part 2: Representation of drawings
Status: Valid

GB/T 10107.2: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 10107.2-2012	209	Add to Cart	3 days	Cycloidal drives -- Part 2: Representation of drawings	Valid
GB/T 10107.2-1988	359	Add to Cart	3 days	Representation of drawings for cycloidal drives	Obsolete

Similar standards

GB/T 5015   GB/T 5014   GB/T 4323   GB/T 43757   GB/T 39545.4   GB/T 10107.1

Basic data

Standard ID: GB/T 10107.2-2012 (GB/T10107.2-2012)
Description (Translated English): Cycloidal drives -- Part 2: Representation of drawings
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J19
Classification of International Standard: 21.120
Word Count Estimation: 9,918
Older Standard (superseded by this standard): GB/T 10107.2-1988
Quoted Standard: GB/T 4457.2-2003; GB/T 4457.4-2002; GB/T 4458.1-2002; GB/T 4458.2-2003; GB/T 4458.4-2003; GB/T 4458.5-2003; GB/T 4458.6-2002; GB/T 4460-1984
Regulation (derived from): National Standards Bulletin No. 24 of 2012
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the mechanical drawings in painting cycloid, cycloid pin wheel meshing with the painting and cycloid planetary transmission mechanism sketch icon symbols. This section applies to cycloid planetary transmission.

GB/T 10107.2-2012: Cycloidal drives -- Part 2: Representation of drawings

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS21.120 J19 National Standards of People's Republic of China Replacing GB/T 10107.2-1988 Cycloid drive - Part 2. Method icon Cycloidaldrives-Part 2. Representationofdrawings Issued on. 2013-03-01 2012-09-03 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

GB/T 10107 "cycloid planetary transmission" includes the following three parts. --- Part 1. Basic terminology; --- Part 2. graphical method; --- Part 3. Symbols of geometrical data. This is Part 2 GB/T 10107 in. Rules in this section in accordance with GB/T 1.1-2009 given draft. This Part replaces GB/T 10107.2-1988 "Cycloid drive mapping methods." This part of GB/T 10107.2- Compared to 1988, in addition to editorial amendments, the main changes are the following. --- Adjusted Chapter 3 of title and content; Appendix --- Added "Format pattern sample needle teeth shell (Figure A.2)"; --- Adjustment Appendix name (see Appendix A). This section is proposed and managed by the China Machinery Industry Federation. This part of the main drafting unit. Hebei University, Tianjin Petrochemical General Machinery Research Institute. Participated in the drafting of this section. Tianjin reducer Plant Co., Ltd., Shanghai slowdown Machinery Co., Ltd., Jiangsu Stallone reducer shares Parts Limited, Thai-reducer Co., Ltd., Shandong Obo reducer Ltd., Zhangjiagang Second Textile Machinery Co., Ltd. The main drafters of this section. Dai Tianwei, Xuan Ping, Liu Zhixin, Ma Xiaojuan, Yan Aiguo, Zhang Mingrong. This part of the standard replaces the previous editions are. --- GB/T 10107.2-1988. Cycloid drive - Part 2. Method icon

1 Scope

This section GB/T 10107 requirements in mechanical drawing painting cycloid, cycloid pin gear wheel and engaging painting and cycloid Graphic symbols planetary transmission mechanism by. This section applies to Cycloid Drive.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated edition applies to this article Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 4457.2-2003 the basic provisions of technical drawings - guidelines and guide lines of GB/T 4457.4-2002 Mechanical drawings Fatou line GB/T 4458.1-2002 Mechanical drawings - General view GB/T 4458.2-2003 Mechanical drawings assembly drawings of parts and components references and its arrangement GB/T 4458.4-2003 Mechanical drawings - Dimensioning GB/T 4458.5-2003 Mechanical drawings with dimensional tolerances and injection method Sectional GB/T 4458.6-2002 Mechanical drawings - view and a sectional view GB/T 4460-1984 mechanical drawing kinematic diagram symbols

3 cycloid pin wheel engages with its painting

3.1 General Cycloid painting and cycloidal needle wheel engaging painting should be consistent with GB/T 4457.2, GB/T 4457.4, GB/T 4458.1, GB/T 4458.2, GB/T 4458.4, GB/T 4458.5, the provisions of GB/T 4458.6, GB/T 4460's. 3.2 cycloid painting 3.2.1 addendum circle and the addendum line drawn by a thick solid line. 3.2.2 root circle and the tooth root lines with a thin solid line drawing, painting may be omitted; in cross-section, the tooth root lines drawn by a thick solid line. 3.2.3 expressed cycloid ships with two views (see Figure 1). 3.2.4 To demonstrate tooth, it can be used to draw a thick solid line or two teeth; or with an appropriate ratio shows a partial enlarged view (see FIG. 1, FIG. 2). 3.2.5 In the cross-sectional view, when the cutting plane through the wheel axis cycloid, the tooth is not generally based on cross-sectional process (Figure 1, Figure 2); slew of odd teeth Wire wheels, cut their teeth can also be treated. ......
