GB/T 10001.3-2021: Public information graphical symbols - Part 3: Symbols for passenger and cargo transport
Status: Valid

GB/T 10001.3: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 10001.3-2021	629	Add to Cart	5 days	Public information graphical symbols - Part 3: Symbols for passenger and cargo transport	Valid
GB/T 10001.3-2011	RFQ	ASK	6 days	Public information graphical symbols for use on sign -- Part 3: Symbols for passenger and cargo transport	Obsolete
GB/T 10001.3-2004	999	Add to Cart	6 days	Logo Public information graphical symbols -- Part 3: Passenger and freight	Obsolete

Similar standards

GB/T 10001.1   GB/T 16903   GB/T 15566.1   GB/T 10001.8   GB/T 10001.4   GB/T 10001.5

Basic data

Standard ID: GB/T 10001.3-2021 (GB/T10001.3-2021)
Description (Translated English): Public information graphical symbols - Part 3: Symbols for passenger and cargo transport
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: A22
Word Count Estimation: 34,335
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 10001.3-2021: Public information graphical symbols - Part 3: Symbols for passenger and cargo transport

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Public information graphical symbols - Part 3.Symbols for passenger and cargo transport ICS 01.080.10 A22 National Standards of People's Republic of China Replace GB/T 10001.3-2011 Public info graphic symbol Part 3.Passenger and Cargo Symbols Released on 2021-03-09 2021-10-01 implementation State Administration of Market Supervision and Administration Issued by the National Standardization Management Committee

Foreword

GB/T 10001 "Public Information Graphical Symbols" is divided into general symbols and symbols in specific fields according to the field of application. It is proposed to be divided into the following section. ---Part 1.General symbols; ---Part 2.Tourism and leisure symbols; ---Part 3.Passenger and cargo symbols; ---Part 4.Sports and fitness symbols; ---Part 5.Shopping symbols; ---Part 6.Medical care symbols; ---Part 7.Office teaching symbols; ---Part 8.Behavior indicators; ---Part 9.Symbols for barrier-free facilities; ---Part 10.Common symbol elements. This part is Part 3 of GB/T 10001. This section is drafted in accordance with the rules given in GB/T 1.1-2009 "Guidelines for Standardization Part 1.Standard Structure and Compilation". This part replaces GB/T 10001.3-2011 "Public Information Graphic Symbols for Signs Part 3.Passenger and Cargo Symbols", and Compared with GB/T 10001.3-2011, the main technical changes are as follows. a) 16 graphic symbols have been added, including 12 new graphic symbols. urban rail transit, rapid transit, airport bus, shuttle bus, network Car-hailing, bus parking, mini-bus parking, train transfer, tax refund, baggage packing, certificate making, express passenger lane; from GB/T 10001.1-2012 4 graphical symbols moved to this part. parking lot, indoor parking lot, bicycle parking place, plus Petrol station; b) Modify 45 graphic symbols. helicopters, ships, passenger ferry, car ferry, car passenger ferry/ro-ro ship, high-speed ship, high-speed train, long-distance bus, Bicycle rental, airplane ticket sales, ship ticket sales, train ticket sales, car ticket sales, flight transit connections, transit visas, luggage trolleys, Baggage inspection, baggage check, baggage claim, baggage inquiry, maternal and infant room waiting room, first class/soft seat waiting room, senior seat, and small Seats for children and passengers, seats for the injured and sick, seats for pregnant women, soft seats, door opening devices, service personnel, freight, cargo inspection, cargo delivery, Cargo extraction, cargo inquiry, air freight, waterway freight, railway freight, road freight, cargo area, awning, warehouse, vehicle, container Containers, container cargo areas, bulk cargo areas; c) Delete or move to other parts of 10 graphical symbols, of which 4 graphical symbols are deleted. light rail trains, intercity trains, small-capacity empty Middle cable car, get off button; plan to move to GB/T 10001.1 4 graphic symbols. swipe card, automatic walkway, self-service luggage storage, security Check; plan to move to GB/T 10001.8 graphical symbols 2.Do not throw things out of the window, do not open the window. This part is proposed and managed by the National Graphic Symbol Standardization Technical Committee (SAC/TC59). Drafting organizations of this section. China National Institute of Standardization, National Railway Administration, Ministry of Transport, Renmin University of China, Beijing Municipal Commission of Communications, China Aerospace Standardization Institute, China Household Electrical Appliances Research Institute. The main drafters of this section. Zhang Liang, Bai Dianyi, An Yaoshun, Chen Ziding, Feng Liguang, An Xiaofen, Zhu Yiwei, Yang Zunian, Zou Chuanyu, Chen Eternal power. When this part was first published in.2004, the content of GB 7058-1986 "Graphic Signs of Railway Passenger Transport Service" was incorporated. One revision, this is the second revision. Public info graphic symbol Part 3.Passenger and Cargo Symbols

1 Scope

This part of GB/T 10001 defines public information graphic symbols for passenger and freight services (hereinafter referred to as graphic symbols). The meaning and description of graphic symbols are presented, and the application requirements of graphic symbols are specified. This part is applicable to passenger and freight transportation places and related facilities such as airports, railway stations, bus stations, ports, urban rail transit stations, etc. Used for location signs, guide signs, information index signs, plan diagrams, block guide maps, and portable prints used in public information guidance systems And the design of guiding elements in other information carriers.

2 Normative references

The following documents are indispensable for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For undated reference documents, the latest version (including all amendments) is applicable to this document. GB/T 10001 (all parts) Graphical symbols for public information GB/T 15565 Graphical Symbol Terms GB/T 16900.2 Graphical Symbols Representation Rules Part 2.Comprehension Test Method GB/T 16903 Graphical Symbol Representation Rules for Signs Design Principles and Requirements for Public Information Graphical Symbols GB/T 16903.3 The rules of graphical symbol representation for signs-Part 3.Perceptual test method GB/T 20501 (all parts) Design principles and requirements for guiding elements of public information guiding systems

3 Terms and definitions

The terms and definitions defined in GB/T 15565 apply to this document.

4 Graphic symbols

Passenger and freight symbols and their meanings and descriptions are shown in Table 1.

5 Application

5.1 This part should be used in conjunction with GB/T 10001.1 and GB/T 10001.9.In application, if other graphic symbols are needed, they should be Selected from the rest of GB/T 10001. 5.2 If you need to design a new graphic symbol, it should be designed in accordance with the requirements of GB/T 16903, and should be designed in accordance with GB/T 16900.2 and GB/T 16903.31) requirements for testing. 1) This standard is proposed to be revised and renumbered as GB/T 16900.3. 5.3 The subscripts in the graphic symbol column of Table 1 do not constitute an integral part of the graphic symbols, but are only the basis for defining the symbol area. To be in design-oriented When the graphic symbols (including the subscripts) in Table 1 are enlarged or reduced in proportion, the position of the graphic symbols shall be determined on the basis of the subscripts. ......
