GB 28476-2012 English PDF

US$449.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB 28476-2012: [GB/T 28476-2012] Carpets-direction for use and labels
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB 28476-2012	449	Add to Cart	4 days	[GB/T 28476-2012] Carpets-direction for use and labels	Valid

Similar standards

GB/T 33734   GB/T 32610   SN/T 3587   GB/T 44675   GB/T 44674   GB/T 28483

Basic data

Standard ID: GB 28476-2012 (GB28476-2012)
Description (Translated English): [GB/T 28476-2012] Carpets-direction for use and labels
Sector / Industry: National Standard
Classification of Chinese Standard: W56
Classification of International Standard: 59.080.60
Word Count Estimation: 17,151
Quoted Standard: GB/T 15964; GB/T 15965; QB/T 1089; QB/T 1188; QB/T 1555; QB/T 2998; FZ/T 01053; ISO 9405; ISO 10361
Regulation (derived from): National Standards Bulletin No. 13 of 2012
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This Chinese standard specifies the use and labels carpet the basic principles and requirements. This standard applies to sales in the PRC and the production of carpet products. This standard does not apply to carpet pads.

GB 28476-2012: [GB/T 28476-2012] Carpets-direction for use and labels

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Carpets-direction for use and labels ICS 59.080.60 W56 National Standards of People's Republic of China Carpets for use and labels Published 2012-06-29 2013-07-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China issued

Foreword

Chapter 5 of this standard are mandatory, others are recommended. This standard was drafted in accordance with rules GB/T 1.1-2009 given. This reference standard ISO /IEC Guide 37 "consumer use" provisions and ISO 6347.2004 "consumer textile floor coverings Information ", the standard" pile carpets use classification and assessment "reference to the European standard EN1307.2005" textile floor coverings pile carpets points Level "and EN14215.2003" textile floor coverings machine-made pile rugs and carpet grade corridor ", and refer to CENTC134" textile floor coverings Using application examples and classification of objects related to the mark, "This standard is for use and labels carpet products for the first time to develop. Please note that some of the content of this document may involve patents, the issuing authority of this document does not assume responsibility for identifying these patents. The standard proposed by China Light Industry Federation. This standard by the National Standardization Technical Committee carpet (SAC/TC150). This standard drafting units. China Arts and Crafts Association of Professional Committee of the carpet. Participated in the drafting of this standard. Sapphire Tianjin Oriental rugs Research Center. The main drafters. Zhang Yufen, Li Xiaowen, Chen Guisheng, Liu Chang, Zhao Yao. Carpets for use and labels

1 Scope

This standard specifies the basic principles and requirements for use and labels of the carpet. This standard applies to domestic production and sales of carpet products in the People's Republic of China. This standard does not apply to carpet cushion products.

2 Normative references

The following documents for the application of this document is essential. For dated references, only applies to the version dated paper Pieces. For undated references, the latest edition (including any amendments) applies to this document. Area or number of tufts GB/T 15964 carpet pile loops per unit length and unit Determination Determination GB/T 15965 manual carpet pile length Test Method QB/T 1089 Carpets thickness QB/T 1188 Test Method carpet quality QB/T 1555 Test Method carpet on the carpet pile substrate thickness QB/T 2998 foot carpet four wheel mass loss test methods Leeson Fiber content identification FZ/T 01053 Textiles ISO 9405 Textile floor coverings Assessment of appearance change Generating the appearance change ISO 10361 Textile floor coverings using Wittman drum or roller hexapod test

3 Terms and Definitions

The following terms and definitions apply to this document. 3.1 Instructions instructionforuse How to convey to consumers the proper and safe use of the product information tools. It is usually expressed in manual, labels, signs and the like. 3.2 Carpet type carpettype The first type of pile of different thickness and mass per unit area of pile carpet pile divided, may be used for each type of the commentary Price method. 3.3 Use grade useclassification Carpet can withstand the use of different strength (abrasion resistance, appearance retention) divided adaptability level. Divided household, commercial three each grade. 3.4 Luxury grade luxuryrating Measured according to the method of the carpet pile mass, density, or Appendix C is determined by the luxury factor (CF) level.

4 Basic Principles

Use are an integral part of the delivery of the product. 4.2 All instructions should be consistent with the provisions of relevant state laws and regulations. 4.3 Instructions for use should be accurate presentation of the product, there should not be exaggerated false content.

5 Content instructions for use

5.1 manufacturer's name and address Carpet manufacturers should indicate the product name and the registered address of the registered according to law. Imported carpets, Chinese mark of origin (country or region) and dealers or importers or distributors in China legally registered Name and address. 5.2 Name Product name should indicate the true nature of the product, and meet the following requirements. a) national standards, industry standards for product names are specified, should adopt national standards, industry standards prescribed name. b) the national standards, product name still does not provide industry standard, common name should be used without causing consumers confusion and misunderstanding Name or common name. 5.3 Dimensions Carpet bulk should indicate the length, width dimensions, carpet width dimension should be marked. 5.4 pile carpet face fiber names and content INGREDIENT NAME pile carpet shall be indicated and labeled fiber content, fiber content shall comply FZ/T 01053's. Carpet 5.5 Total thickness (mm) and the carpet pile substrate thickness (mm) or height (mm) The total thickness of the carpet should QB/T 1089 determines, based on the carpet pile thickness should QB/T 1555 is determined. Hand press carpet pile length GB/T 15965 determined. 5.6 total mass per unit area (g/m2) Carpets total mass per unit area should QB/T 1188 OK. Pile weight per unit area of the carpet base 5.7 (g/m2) Carpets group on carpet pile weight per unit area should QB/T 1188 is determined. Hand tufted carpets may indicate the number of channels or stitches. 5.8 Product standard number National standards should indicate the product performed, industry standard or enterprise standard. 5.9 Product Quality rating Product standards clearly defined quality level of products, product standards should be required to indicate the level of product quality. 5.10 product quality inspection certificate Domestic production of qualified products, every single product (sales unit) should have the factory inspection certificate, and indicate the date of expiration.

6 carpet for use and labels

6.1 Products for carpeting locations grading and labels Machine-made pile carpets should be provided using a hierarchical or labels indicating that the product is most suitable for use with a paved area (place). Use classification And calculation methods see Appendix A and Appendix B. Wear Index is calculated and luxury class, see Appendix C, using a hierarchical, luxury rating See Appendix D. Additional 6.2 (optionally) instructions and flag information If the product is treated with a special processing, other physical properties when provided, may be marked or selection flag corresponding to, and labeled test Methods and achieved technical level. Examples of corresponding labels in Appendix E. Form and instructions for use of claim 7 7.1 takes the form Carpet manufacturer or seller can take any of the following forms provided for use. a) the use of the carpet or labels to be sewn, stuck on or attached on a carpet product; b) printed directly on the packaging; c) provide information accompanying the product. 7.2 Basic requirements 7.2.1 the text on the use or labels should be clear and eye-catching. Text color and background color or background color for the graphical symbols to be contrasting colors. 7.2.2 use or labels used in the text should be standard Chinese characters set by the state. You can also use Hanyu Pinyin, foreign or minority culture Word, but the font size should not be greater than the corresponding Chinese characters. 7.2.3 use or labels shall be of suitable materials and methods to keep them legible in product sales during the period. 7.2.4 assess the use classification and luxury rating pile carpet products should meet the standards of their products other technical requirements. 7.2.5 use classification and luxury rating shall be used together.

Appendix A

(Informative) Use pile carpets and grades A.1 General Assessment on use classification is to protect the interests of consumers for the application of this standard is intended to provide guidance to consumers so they can buy laid Appropriate in a specific area of use rating pile carpet products. A.2 pile carpet using a hierarchical assessment Pile carpets can be divided according to their type of use. a) full pile carpets (including carpet tiles); b) pile rugs, carpet corridor. A.2.1 fitted pile carpets use classification and luxury rating Fitted pile carpets using adaptive use as the basis for classification is divided into residential, commercial three levels each. Based carpet The abrasion resistance of the product (mass loss) of the carpet surface appearance retention test (change in appearance), and used to determine the suitability of the carpet strength (light resistance Of pedaling frequency, the frequency of resistance to moderate depression, severe depression frequency generally resistant, resistant to severe pedaling frequency, resistance heavily pedaling frequency). The overall level of use in a single test level two, i.e., wear and appearance retention of a lower rating determined. Luxury grade (walking comfort) is based on test results to calculate the level of the luxury class. A.2.1.1 fitted pile carpets classification (see Table A.1) Full pile carpets basis weight per unit area of the pile of the pile thickness, blanket group may be divided into two categories, according to different classification for making With grading test and evaluation. Table A.1 fitted pile carpets classification Groups on the carpet pile thickness mm Area on the carpet pile weight based unit (SPW) g/m2 spw < 600 600≤spw < 900 spw≥900 < 6 of a Class Type II ≥6 a class of second-class A.2.1.2 fitted pile carpet using a hierarchical technical requirements (see Table A.2) The use of two specifications --- strength and wear resistance of the carpet surface appearance retention determining adaptability level pile carpets. a) wear resistance rating Carpet Wear --- a classification test by QB/T 2998 method, wheel tread wear coefficient Leeson test results (the ITR) by Calculation of formula (B.1). --- two types of carpet grade abrasion wear index is calculated (W1) in accordance with Appendix C. b) Classification carpet surface appearance retention Carpet surface appearance retention according to ISO 10361, the use of roller hexapod test based on ISO 9405 and evaluated. Table A.2 fitted pile carpet using a hierarchical Technical Requirements Intensity of use use grade Wear grade appearance retention rating A Carpet ITR Two types of carpet Wear index (W1) Carpet and a < 80% wool carpets Type II ≧ 80% wool carpets and rugs Hexapod tumbler test 12000r (level) hexapod tumbler test 12000r (level) Mild walk frequency 1 ≥0.9 ≥0.8 1.5 1.5 Moderate walking frequency 2 ≥1.7 ≥1.7 2 2 Severe walk frequency 3 ≥2.3 ≥2.5 2.5 2.5 Usually severe walking frequency ≥2.3 Ⅰ ≥2.5 2.5 2.5 Severe walk frequency Ⅱ ≥3.0 ≥2.5 3 2.5 Heavily walk frequency Ⅲ ≥3.0 ≥3.3 3.5 3 A.2.1.3 fitted pile carpets luxury level technical requirements (see Table A.3) Luxury rating is calculated luxury rating factor CF according to Appendix C, Table A.3 Option 1 rating, or choose Table A.3 listed velvet Head Quality Option 2 rating. Table A.3 fitted pile carpets luxury level technical requirements Luxury Level Option 1 Option 2 Luxury factor CF Area on the carpet pile weight based unit (SPW) g/m2 LC1 CF < 12.0 < 400 LC2 12.0≤CF < 24.0 ≥400 LC3 24.0≤CF < 36.0 ≥600 LC4 36.0≤CF < 72.0 ≥800 LC5 CF≥72.0 ≥1000 A.2.2 pile rugs and carpets using the corridor level and luxury rating Pile rugs and carpet strip according to applications, and how often to use the degree of luxury grading. A.2.2.1 pile rugs and carpets using the corridor level technical requirements (see Table A.4) Pile rugs and carpets should corridor retentive surface appearance of the carpet according to Table A.4 corresponding to the frequency of use of graded. Carpet surface appearance Hexapod Tumbler retention using the test method according to ISO 10361, ISO 9405 based on the evaluation. Table A.4 pile rugs and carpet corridor using a hierarchical Technical Requirements Using the intensity level using the drum test Hexapod appearance change 12000r/Level 1.5 Mild walk frequency 1 Moderate walking frequency 22 Usually severe walking frequency 33 4 Severe walk frequency 3.5 Heavily walk frequency 54 A.2.2.2 pile rugs and carpets luxury corridor level technical requirements (see Table A.5) Evaluation luxury rating factor CF is calculated according to the luxury level appendix C, Table 1 A.5 rating option or choice listed in Table A.5 Option 2 pile weight rating. Table A.5 pile rugs and carpets luxury corridor level technical requirements Luxury Level Option 1 Option 2 Luxury factor CF Area on the carpet pile weight based unit (SPW) g/m2 LC1 CF < 20.0 < 600 LC2 20.0≤CF < 36.0 ≥600 LC3 36.0≤CF < 72.0 ≥800 LC4 72.0≤CF < 100.0 ≥1000 LC5 CF≥100.0 ≥1500

Appendix B

(Informative) The ITR (Leeson depression test wheel) calculated Wear coefficient test results B.1 Leeson wheel tread (the ITR) calculated according to formula (B.1) ITR = 0.19 spw × 100-mrv (B.1) Where. --- the ITR wear coefficient test results Leeson wheel tread; --- the SPW press blanket yl QB/T 1188 measured pile weight per unit area in grams per square meter (g/m2); relative mass loss by MRV --- QB/T 2998 measured,%. B.2 calculated relative mass loss (MRV) of mrv = mv spw × 100 (B.2) Where. Loss of mass by Music Videos --- QB/T 2998 unit area measured in grams per square meter (g/m2); --- SPW by the carpet pile head mass yl QB/T 1188 unit area measured in grams per square meter (g/m2). B.3 calculated mass loss per unit area (Music Videos) of mv = m1-m2 (B.3) Where. Mass before test wheel tread M1 --- Leeson carpet sample in grams (G); --- M2 rear wheel tread Leeson test carpet sample mass in grams (G); A --- Leeson test area of the test wheel tread. To run the wheel track width × pedal depression detecting wheel Leeson length, in meters (M2).

Appendix C

(Informative) Attrition Index (W1) and the luxury rating factor (CF) is calculated C.1 Attrition Index (W1) is calculated according to the formula (C.1) W1 = spw × spdff × 18 (C.1) Where. Pile weight SPW Press --- QB/T 1188 measured on a blanket substrate per unit area in grams per square meter (g/m2); SPD --- the carpet surface pile density Press QB/T 1188 measured in grams per cubic centimeter (g/cm3); --- fiber factor FF, Table C.1. Table C.1 fiber factor Fiber Fiber factor 1.0 polyamide filament Polyamide staple fibers 1.2 Polypropylene filament 1.2 Polypropylene staple fiber 1.4 Polyester staple fibers 1.6 Polyacrylonitrile staple fiber 1.8 Wool 1.9 Cotton 2.0 Modified viscose staple fiber 2.2 Modified acrylic staple fibers 2.4 Blending proportion C.2 luxury rating factor (CF) is calculated, see formula (C.2) and formula (C.3) a) a carpet or contains more than 2/3 of the cutting head is domesticated hen loops were cut pile carpets. CF = spt5 × spw 100 × NZ 200 (C.2) b) loop carpet CF = spt6 × spw 100 × NZ 200 (C.3) Where. CF --- luxury factor; Press SPT --- QB/T 1555 based on the measured pile carpet thickness in millimeters (mm); Pile weight SPW Press --- QB/T 1188 measured on a blanket substrate per unit area in grams per square meter (g/m2); NZ --- by the number of tufts GB/T 15964 measured per square decimeter within.

Appendix D

(Informative) Use classification, luxury rating example Example D.1 using a hierarchical flag, see Table D.1 Table D.1 example using a hierarchical flag Flag of legend levels extent of use Applications Lightdomestic Mild depression Frequency (domestic) Lower utilization study, bedroom, etc. Moderatedomestic Moderate pedaling frequency (home) Personnel access more living room, hall Heavydomestic Severe depression Frequency (domestic) Porches, walkways and other places higher utilization Lightcommercial Mild pedaling frequency (commercial) Hotel rooms, meeting rooms, offices, etc. Generalcommercial Moderate pedaling frequency (commercial) Personnel access more shops, offices, Conference room Heavycommercial Severe pedaling frequency (commercial) Frequent utilization, more staff or place Porch, hallway, lounge, etc. D.2 luxury rating example, see Table D.2 Table D.2 luxury rating example Luxuryclass (LC1) Luxury Level Level 1 Luxuryclass (LC4) Luxury Level 4 Luxuryclass (LC2) Luxury Level 2 Luxuryclass (LC5) Luxury Level 5 Luxuryclass (LC3) Luxury level 3

Appendix E

(Informative) Additional (optional) information flag Example E.1 flame flame resistance's signs GB 20286 carpet fire performance should be executed, the test achieved levels represented in Table E.1 flag. Table E.1 exemplary flame resistance marker Flame resistance to flame GB 20286 ISO 9239-1 ISO 11925-2 E.2 carpet antistatic property's signs Carpet antistatic property test according to ISO 6356 walking method executed, measured according to ISO 10965 performs, see Table E.2 resistance method. Table E.2 flag exemplary antistatic properties electricalbehaviorbodyvoltage The human body static voltage habits (walking method) ≤2kW or ≤3.5kW antistaticpropertyof carpets (electrical resistance) Antistatic carpet (resistance method) E.3 test methods and other optional information flag exemplary Table E.3. Table Example E.3 other optional information flag QB/T 2998 Resistancetofraying durable Mass loss ≤25% QB/T 1088 Dimensionalstability Dimensional stability 0.4% to -0.8% twenty one Table E.3 (cont.) ISO 4918 Castorchairoccasionaluse Occasional foot wheelchair spaces ISO 4918 Castorchaircontinuoususe Often using foot wheelchair spaces ISO 13746 Stairsoccasionaluse Suitable for occasional use on stairs ISO 13746 Stairscontinuoususe It applies to the stairs often used ASTMF609-05 BSEN14041 Slipresistance (2classes) Skid resistance (Level 2) references [1] GB 20286-2006 public places flame combustion products and components, performance requirements and identification. [2] QB/T 2998-2008 Leeson four foot carpet wheel mass loss test methods. [3] QB T 1088-1991 Carpets dimensional change/hot under flooding and drying action. [4] ISO 6356.2000 carpet electrostatic habit Evaluation walking test. [5] ISO 10965.1998 Determination of resistance carpet. [6] ISO 4918.1990 Textile floor measurement castor chair test feature wear. [7] ISO 13746.2000 Textile floor coverings and stair carpet laying Guide. [8] EN1307.2005 Textile floor coverings - Classification of pile carpet. [9] EN14215.2003 Textile floor coverings machine-made pile rugs and carpet corridor classification. [10] CEN/TC134N1209. Textile floor using the application examples related to signs of surface features and classification of 2006. [11] EN14041.2004 elastic, textile floor coverings and Laminate flooring must-have feature. [12] ASTM609.2005 Standard Test Method for horizontal sliding tester traction. ......
