Basic dataStandard ID: FZ/T 14009-2024 (FZ/T14009-2024)Description (Translated English): (Vinylon dyed waterproof canvas for canopy) Sector / Industry: Spinning & Textile Industry Standard (Recommended) Classification of Chinese Standard: W71 Classification of International Standard: 59.080.30 Word Count Estimation: 9,966 Date of Issue: 2024-07-05 Date of Implementation: 2026-07-01 Older Standard (superseded by this standard): FZ/T 14009-2014 Issuing agency(ies): Ministry of Industry and Information Technology of the People's Republic of China Summary: This standard specifies the terms and definitions, classification, requirements, test and inspection methods, inspection rules, marking and packaging of vinylon dyed waterproof canvas for awnings. FZ/T 14009-2014: Water-proof dyed vinylon canvas for awning---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.Water-proof dyed vinylon canvas for awning ICS 59.080.30 W71 People's Republic of China textile industry standards Replacing FZ/T 14009-2005 It is covered with tarpaulins dyeing vinylon Issued on. 2014-05-06 2014-10-01 implementation Ministry of Industry and Information Technology of the People's Republic of China released ForewordThis standard was drafted in accordance with GB/T 1.1-2009 given rules. Instead of the standard FZ/T 14009-2005 "are covered with tarpaulins dyeing vinylon." This standard FZ/T 14009-2005 compared to the main changes are as follows. --- Increase canopy cover defined by Villeneuve dyed waterproof canvas; --- Increased tear strength, color fastness (light fastness, abrasion) assessment; --- Weft density to the density of the zonal deviation rate, breaking strength to the lowest value assessment; --- Locality adjust the appearance of quality defect scoring method allows Rating by the minute/m to min/sq m, width cancel classification; In addition to edge defects, the rest of the starting point O; --- Disseminated defects increased width deviation, skew the assessment; --- Remove Appendix A processing system breaking strength values. The standard proposed by China Textile Industry Association. This standard by the National Technical Committee of Standardization Technical Committee printing and dyeing cotton textiles (SAC/TC209/SC2) centralized. This standard was drafted. Fenghua days Shield waterproof material Limited, New Dragon Group Co., Ltd., Shanghai textile industry technical supervision The, China Dyeing and Printing Association. The main drafters of this standard. Hu Changming, Wangyun Xia, Xu Huajun, Lin Lin, any reference. This standard replaces the standards previously issued as follows. --- ZBW75001-1985; --- FZ/T 14009-1999, FZ/T 14009-2005. It is covered with tarpaulins dyeing vinylon1 ScopeThis standard specifies with PVA short fiber as raw material with a canopy cover vinylon stained tarpaulin classification and labeling requirements, testing and inspection side Method, inspection rules and signs and packaging. This standard applies to the use of PVA identified short fibers, woven canopy cover production quality vinylon stained with waterproof canvas. This standard is not used to identify quality PVA coating canvas.2 Normative referencesThe following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 250 textile color fastness test assessing change in color like the gray card GB/T 251 Textiles Tests for color fastness - Grey scale for assessing staining card GB/T 411 cotton printing and dyeing cloth GB/T 3917.2 Textiles Tear properties of fabrics - Part 2. Determination of trouser - shaped specimens (single slit) Tear GB/T 3920 Textiles Tests for color fastness rubbing fastness GB/T 4744-1997 Textile fabrics - Determination of resistance to water penetration Hydrostatic pressure test Testing and evaluation of GB/T 4745-2012 Textiles waterproof performance of wet method GB 5296.4 consumer use - Part 4. Textiles and Clothing GB/T 8170 repair value expressed about the rules and limit values and judgment GB/T 8427-2008 Textiles Tests for color fastness Colour fastness to artificial light. Xenon arc GB/T 14801 woven and knitted skew and bowing Test Method GB 18401 National Safety Technical Code for Textile Products FZ/T 10003 Test Method for canvas fabrics FZ/T 10005 pure cotton and chemical fiber textile, printing and dyeing cloth blended inspection rules FZ/T 10010 pure cotton and chemical fiber textile, printing and dyeing cloth blended marking and packaging3 Terms and DefinitionsGB/T 411 and defined by the following terms and definitions apply to this document. 3.1 Article spend streakiness Extending along the warp or intermittent scattered, with a shallow depth color, no obvious defects on both sides of the boundary. 3.2 Warp and weft are made of polyvinyl alcohol or yarn strands weaving, dyeing and finishing warp, with waterproof properties of coarse thick fabric. Mainly used for automobile transport Covered and open-air warehouse and field tent. Category 4 Are covered with tarpaulins Villeneuve dyed fabric in accordance with the main purpose of the tarpaulin with a divided and drape fabric into two categories. Villeneuve stained with canopy cover Tarpaulin processing coefficient accordance with Appendix A.5 Requirements5.1 Content Requirements Villeneuve canopy cover with stained tarpaulin inherent quality and appearance requirements are divided into two aspects of quality, intrinsic quality including weft density deviation Rate, breaking strength, tear strength, hydrostatic pressure, cleaning the bathroom, color fastness and safety performance of seven, including the appearance of quality defects and localized defects disseminated Categories. 5.2 grading regulations Products 5.2.1 Product divided into superior products, first-class product and the second product, lower than the second product is substandard products. 5.2.2 canopy covered with waterproof canvas dyeing vinylon rating, intrinsic quality metrics by criticism, visual quality in accordance with paragraph (hp) ratings, less in terms of quality Quality and appearance of products, such as the lowest of the match (segment) cloth goods. 5.2.3 At the same one (segment) within the fabric, localized defects per square meter to allow the use of way limited score rating; disseminated defect Press a severe rating. 5.3 intrinsic quality 5.3.1 Product safety performance should be consistent with the provisions of GB 18401. 5.3.2 Internal quality rating specified in Table 1. Table 1 rating intrinsic quality regulations Assessment project Superior grade First grade second product Weft density deviation rate /% ≥ -3.0 -4.0 -5.0 Breaking strength/N ≥ With tarpaulin Fabric Warp 800 Zonal 600 Cover with a cloth Fabric Warp 1200 Zonal 850 Tear strength/N ≥ With tarpaulin Fabric Warp 40 Weft 35 Cover with a cloth Fabric Warp 70 Weft 40 Hydrostatic/(cmH2O) ≥ Tarpaulin fabric 35 Drape fabric 60 Wet/level ≥ 4 4 3 Table 1 (continued) Assessment project Superior grade First grade second product Color fastness/grade ≥ Light discoloration 4-543 Rubbing a Dry rub 43-43 Wet Mount 32-32-3 a moisture friction color fastness, second product can lower half dark stage. Deep, medium and light level according to GB/T 250 standard, level 5 is dark, grade 2 and below shallow Color, color is in between the two colors. 5.4 appearance quality 5.4.1 localized defect provisions allow Rating 5.4.1.1 each piece (para) Locality defect fabric allows Rating provisions are shown in Table 2. Table 2 Locality defect allows Rating provisions in minutes per square meter Superior grade First grade second product ≤0.2 ≤0.3 ≤0.6 Locality defects 5.4.1.2 each piece of cloth to allow the total score according to equation (1) calculations. A = a × L × W (1) Where. A --- each piece (segment) cloth Locality defect allows total score, in minutes; a --- per square meter allow Rating, in minutes per square meter (min/m2); L --- horses (segment) length in meters (m); W --- standard width in meters (m). 5.4.1.3 The results according to GB/T 8170 rounded to single digits. 5.4.2 localized defect rates specified 5.4.2.1 localized defect rates specified in Table 3. Table 3 Locality predetermined defect rates Defect length Rating 8.0cm and below 1 minute 8.0cm to 16.0cm above and below 2 minutes 16.0cm to 24.0cm above and below 3 points 24.0cm above 4 points 5.4.2.2 1m rates must not exceed 4 points. 5.4.2.3 All the holes from the edge than 2.0cm (broken yarn 3 and above, or latitude and longitude and all off a distinct, 0.3cm above the jump Flower) regardless of size, are assessment 4 points; 2.0cm from the edge and less breakage of defects, to assess 2 points. 5.4.3 Description of localized defect rates 5.4.3.1 defect length according to the amount of the maximum length of the warp or weft count. 5.4.3.2 In addition to damage outside, and from the other side 1.0cm defect within not score. 5.4.3.3 When assessing defects cloth, cloth are subject to positive and negative with through horses shall drop a level when the spread of serious defects. 5.4.3.4 Oil defects should be based on the degree of impact on the overall effectiveness of the assessment. 5.4.4 disseminated defects allow a predetermined level Disseminated defect extent permitted by the provisions in Table 4. Table 4 disseminated defects allow a predetermined level Defect name and category Superior grade First grade second product Width deviation/cm Width 140cm and below ~ 2.0 -1.0 -1.5 -2.5 -2.0 3.0 Width 140cm above -1.5 -2.5 -2.0 3.0 -2.5 -3.5 Color/level ≥ AS Similar swatches below 3 3-43 Lower than the reference sample 32-3 2-3 Left, right, 43-42-3 Before and after 3-43-42 Front and back 32-3 less than 2-3 Skew /% ≤ skew 2.0 3.0 4.0 Uneven dyeing does not affect the exterior appearance does not affect the appearance of influence Article does not affect the appearance of the flower does not affect the appearance affect the appearance 5.4.5 Description superior product defects Superior product does not allow any of the following defects. --- A separate commentary 4 stars locality defects; --- Breakage of defects. 5.4.6 Description First grade defect and breakage resistance First grade are not allowed to breakage defects. 5.5 cut open and fight fake parts provision 5.5.1 does not allow fake cut open in the superior product. 5.5.2 Where a consumer allow fake fight or cut open parts, cut open and can be implemented to fight fake parts, the length is not less than the minimum spell 10m; false defects should be cut open Is rated as a 4-point defect or serious defect as 3 points, after a false start and cut each segment of cloth should be first-class products. 5.5.3 from the cloth ends within 5m and 30m in length are not permitted leave open cut. Length of more than 30m can be used for a false start and cut each additional 30m increase a fake open scissors, and so on. Spacing between the false start and cut not less than 10m. Each cut should leave open Placing 0.25m As compensation for the length of the false start and cut defects (if defects longer than the actual length of 0.25m plus release). As a false defect rates are not cut open Credit in the match (segment) cloth localized defect of the total score. 5.5.4 cut open and fight false piece rate must not exceed 20% of the total, of which spell piece rates shall not exceed 10%. Otherwise required by the implementation of the agreement. 5.5.5 fake open scissors cloth should be clearly marked, with a false start and cut section length sheets.6 Test and inspection methods6.1 Test Method 6.1.1 weft density Press FZ/T 10003 Executive, weft density variation rate according to equation (2) calculated according to GB/T 8170 rounded down to the decimal point A. e = D1-Dw Dw × 100% (2) Where. e --- zonal density deviation rate,%; Dw --- are covered by standard PVA dyed weft density waterproof canvas, the unit is the root of every ten centimeter (root/10cm); D1 --- are covered with tarpaulins Villeneuve dyed weft density measured in units of ten centimeters per root (root/10cm). 6.1.2 Breaking Strength press FZ/T 10003 execution. 6.1.3 tear strength according to GB/T 3917.2 execution. 6.1.4 hydrostatic test performed in GB/T 4744-1997. Which test the water temperature is 20 ℃ ± 2 ℃, water pressure is applied from the front of the sample, Pressure rise rate 10cmH2O/min ± 0.5cmH2O/min. 6.1.5 Spray test according to GB/T 4745-2012 execution. Which test the water temperature is 20 ℃ ± 2 ℃. 6.1.6 color fastness test according to GB/T 8427-2008 3 execution method. 6.1.7 rubbing fastness test according to GB/T 3920 execution. 6.1.8 Width Press FZ/T 10003 execution. 6.1.9 color, color according to GB/T 250, staining according to GB/T 251 assessment. 6.1.10 skew according to GB/T 14801 execution. 6.2 Appearance quality conditions and methods 6.2.1 using the test light to 40W fluorescent tube plus cover glaucoma 3 ~ 4, illumination of not less than 750lx, light fabric with distance 1.0m ~ 1.2m. Rating cloth section 6.2.2 inspection, defect marked by the inspection machine made score rating. Reinspection section 6.2.3 of cloth, fabric inspection and acceptance should be flat on the table, according to the zonal inspection by frame to expand the line of sight of inspectors should face cloth, eyes Distance from the cloth is 55.0cm ~ 60.0cm. 6.2.4 predetermined positive test fabric (printing side of the cover shoot for the opposite).7 Inspection rulesInspection rules by FZ/T 10005 execution.8 signs and packagingSigns and packaging press FZ/T 10010 Executive, the packaging of the flag according to GB 5296.4 execution.9 OtherSpecial varieties and users of the products have special requirements, another express agreement by both parties.Appendix A(Normative) It is covered with tarpaulins dyeing vinylon processing coefficients A.1 width, density processing coefficients A.1.1 According canopy covered with tarpaulins dyeing vinylon classification, combined with dyeing process design, according to the processing coefficient shall be calculated. Processing coefficient Table A.1. A.1 processing coefficients Class width processing coefficient (b) Processing density coefficient (c) Warp weft With tarpaulin Thick fabric 0.955 1.047 1.000 Muslins 0.940 1.064 0.970 Drape with 0.965 1.036 1.010 A.1.2 canopy covered with tarpaulins Villeneuve dyed warp and weft average density according to equation (A.1) calculated according to GB/T 8170 rounded to single digits. T = Tj Tw (A.1) Where. T --- Villeneuve stained canopy cover with waterproof canvas weft average linear density in tex (tex); Tj --- are covered with tarpaulins Villeneuve dyed warp yarn density in tex (tex); Tw --- are covered with tarpaulins Villeneuve dyed weft yarn density in tex (tex). A.1.3 canopy covered with tarpaulins vinylon stained thick and thin fabric classified in accordance with the weft average density classification. Weft average density It is 118tex above, thick fabric. Weft density 118tex average and below, a thin fabric. A.2 Calculation Method A.2.1 standard width according to equation (A.2) calculations. W = W1 × b (A.2) Where. W --- are covered with tarpaulins dyeing vinylon standard width in meters (m); W1 --- qualities vinylon canvas canopy cover with a standard width in meters (m); b --- canopy cover width dyeing vinylon processing coefficients waterproof canvas. A.2.2 Standard (weft) density according to equation (A.3) calculations. Dt, w = dt, w × c (A.3) Where. Dt, w --- are covered with tarpaulins vinylon stained standard (weft) density in the root of every ten centimeter (root/10cm); dt, w --- are covered with canvas vinylon character standard (weft) density in the root of every ten centimeter (root/10cm); c --- canopy cover waterproof canvas stained with PVA (weft) density processing coefficients. ...... |
