JJF 1605-2016: Program of Pattern Evaluation of Illuminance Meters---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.Program of Pattern Evaluation of Illuminance Meters National Metrological Technical Code of the People's Republic of China Illumination Scale Evaluation Outline 2016-11-30 release 2017-02-28 Implementation State Administration of Quality Supervision, Inspection and Quarantine issued Illumination Scale Evaluation Outline Coordinate unit. National Committee for Optical Metrology The main drafting unit. Guangdong Institute of Metrology China Testing Technology Research Institute Participated in the drafting unit. China Institute of Metrology Beijing Normal University This specification entrusts the National Committee for Optical Metrology to explain The main drafters of this specification. Weight xiaojing (Guangdong Institute of Metrology) Mo Fan (Guangdong Institute of Metrology) Mu Yayong (China Test Technology Research Institute) Participate in the drafters. Jiang Xiaomei (China Institute of Metrology) Zhang Baozhou (Beijing Normal University) Ke Jin (Guangdong Institute of Metrology) table of ContentsIntroduction (Ⅲ) 1 Scope (1) 2 References (1) 3 Terminology (1) 3.1 V (λ) Matching error (1) 3.2 cosine characteristic error (1) 3.3 Fatigue property error (1) 4 Overview (1) 5 legal management requirements (2) 5.1 Unit requirements (2) 5.2 Metrological requirements for marking and measuring instruments (2) 6 Measurement requirements (2) 6.1 Relative zero error (2) 6.2 Relative indication error (2) 6.3 V (λ) Matching error (3) 6.4 cosine characteristics (directional response) error (3) 6.5 shift error (3) 6.6 Fatigue error (3) 6.7 Infrared response error (3) 6.8 UV response error (4) 6.9 Nonlinearity error (4) 7 General technical requirements (4) 7.1 Appearance and structure (4) 7.2 Electrical safety (4) 7.3 Environmental Adaptability (5) 8 type evaluation item table (6) 9 the number of samples provided and the use of the prototype (7) 9.1 Test prototype (7) 9.2 How to use the prototype (7) 10 Test conditions and methods of test items and data processing and eligibility criteria (7) 10.1 Measurement requirements (7) 10.2 General technical requirements (15) 11 Measuring instruments and equipment for use in test items (21) 12 should pay attention to the type of evaluation (22) Decision of type 13 evaluation result (22) 14 type evaluation original record format (22) Appendix A Illuminance Type Evaluation Original Record Format (23)IntroductionThis specification is based on JJF 1015 "General specification for evaluation of measuring instruments", JJF 1016 " Outline the preparation of the outline of the outline. The technical indicators of this specification refer to JJG245-2005 "light meter" and other technical regulations. This specification is the first release. Illumination Scale Evaluation Outline1 ScopeThis specification applies to the type of light meter (hereinafter referred to as light meter) type evaluation.2 reference fileJJG245-2005 light meter Terminology and definitions of optical radiation metrology nouns JJF 1032-2005 Specification for relative spectral responsivity calibration of photodetectors JJF 1150-2006 GB/T 11606 Environmental testing methods for analytical instruments GB/T 12085.2-2010 Environmental and optical instruments - Environmental test methods - Part 2. Low temperature, Hot and humid For dated references, only the dated edition applies to this specification; references that are not dated , The latest version (including all modifications) applies to this specification.3 terminology3.1 V (λ) Matching error V (λ) matchingerror In theory, the relative spectral response of the illuminance meter is fully consistent with the visual function V (λ), whereas the actual optical radiation detector Spectral response degrees are far from the difference, must be corrected by correcting filter group to be matched. Matching the illuminance The deviation of the relative spectral response of the detector from the visual function is the V (λ) matching error. 3.2 Cosine characteristic error cosinecharacteristicerror The cosine law shows that when the beam is illuminated at an angle to the illuminance surface of the illuminometer detector, the illuminance reading should The product of the reading when the beam is incident at the same time as the cosine of the incident angle. The actual illuminance meter can not exactly conform to the cosine method Then its deviation from the cosine law is the cosine characteristic error. 3.3 Fatigue characteristic error Fatigue characteristics of the photometric light detector photosensitive surface to receive a strong light radiation, the detector response will gradually decline phenomenon. The resulting error is called the fatigue characteristic error.4 OverviewThe illuminometer is a measuring instrument that measures the illuminance, which is corrected by the optical head [including cosine corrector, V (λ) Device, photoelectric receiver] and the display (digital or pointer type) composed of two parts. When the photoelectric receiver is received through Cosine modifier and V (λ) filter, the resulting photoelectric signal is signaled on the display Showing the corresponding illuminance value. ...... |
