GB/T 39334.4-2020: Digital simulation of mechanical products manufacturing process - Part 4: Requirements of NC machining process simulation
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 39334.4-2020	149	Add to Cart	3 days	Digital simulation of mechanical products manufacturing process - Part 4: Requirements of NC machining process simulation	Valid

Similar standards

GB/T 38898   GB/T 38896   GB/T 39432   GB/T 39334.3   GB/T 39334.5   GB/T 39334.2

Basic data

Standard ID: GB/T 39334.4-2020 (GB/T39334.4-2020)
Description (Translated English): Digital simulation of mechanical products manufacturing process - Part 4: Requirements of NC machining process simulation
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J04
Classification of International Standard: 01.100.01
Word Count Estimation: 8,816
Date of Issue: 2020-11-19
Date of Implementation: 2021-03-01
Regulation (derived from): National Standard Announcement No. 26 of 2020
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 39334.4-2020: Digital simulation of mechanical products manufacturing process - Part 4: Requirements of NC machining process simulation

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Digital simulation of mechanical products manufacturing process-Part 4.Requirements of NC machining process simulation ICS 01.100.01 J04 National Standards of People's Republic of China Digital simulation of mechanical product manufacturing process Part 4.Simulation requirements of CNC machining process 2020-11-19 released 2021-03-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Table of contents

Preface Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 Category 1 4.1 Classification by simulation target 1 4.2 Classification by processing type 1 5 General requirements 1 6 Basic process 2 7 Detailed requirements 2 7.1 Formulation of simulation plan 2 7.2 Simulation model construction 3 7.3 Simulation operation analysis 4 7.4 Evaluation and optimization of results 5

Foreword

GB/T 39334 "Digital Simulation of Mechanical Product Manufacturing Process" is divided into 5 parts. ---Part 1.General requirements; ---Part 2.Production line planning and layout simulation requirements; ---Part 3.Logistics simulation requirements of assembly workshop; ---Part 4.Requirements for simulation of CNC machining process; ---Part 5.Typical process simulation requirements. This part is Part 4 of GB/T 39334. This section was drafted in accordance with the rules given in GB/T 1.1-2009. Please note that certain contents of this document may involve patents. The issuing agency of this document is not responsible for identifying these patents. This part is proposed and managed by the National Technical Product Documentation Standardization Technical Committee (SAC/TC146). Drafting organizations of this section. Xugong Group Construction Machinery Co., Ltd., China Machinery Productivity Promotion Center, China Electronics Technology Group Corporation 38 Research Institute, CRRC Zhuzhou Electric Locomotive Co., Ltd., Henan Diesel Engine Heavy Industry Co., Ltd., SAIC-GM-Wuling Automobile Co., Ltd. Co., Ltd., Shaanxi Fast Gear Co., Ltd., Xidian University, Xi’an Shaangu Power Co., Ltd., China Electronics The 30th Research Institute of Technology Group Corporation, Shenzhen Greensun Technology Co., Ltd. The main drafters of this section. Zhao Zhenglong, Wu Rui, Xin Mingzhe, Chen Jie, Wei Yixiong, Shen Longjiang, Gu Xiangyang, Wei Wei, Yan Jianbo, Yu Gongyan, Liu Huanling, Zhang Shengli, Han Zengfu, Yang Ping, Chen Zhengjiang, Wang Hongmin. Digital simulation of mechanical product manufacturing process Part 4.Simulation requirements of CNC machining process

1 Scope

This part of GB/T 39334 specifies the classification, general requirements, and basic flow of NC machining process simulation in the manufacturing process of mechanical products. Process, and detailed requirements for simulation plan formulation, simulation model construction, simulation operation analysis, result evaluation and optimization. This part is applicable to the application, development, service and research related to the simulation of NC machining process in the manufacturing process of mechanical products. This section does not apply to the simulation of processing physical parameters.

2 Normative references

The following documents are indispensable for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For undated references, the latest version (including all amendments) applies to this document. GB/T 4863 Basic terminology of mechanical manufacturing technology GB/T 39334.1 Digital Simulation of Mechanical Product Manufacturing Process Part 1.General Requirements

3 Terms and definitions

The terms and definitions defined in GB/T 4863 and GB/T 39334.1 apply to this document.

4 categories

4.1 Classification by simulation target According to the target classification of CNC machining process simulation, it can usually be divided into tool path simulation, machining interference check, and machining process parameters (cutting Volume, feed volume, speed, etc.) simulation. 4.2 Classification by processing type According to the classification of CNC machining, it can usually be divided into turning machining simulation, milling machining simulation and so on.

5 General requirements

5.1 The simulation of CNC machining process should meet the following requirements. a) Meet the basic requirements of GB/T 39334.1; b) Adopt a three-dimensional model; c) Simulation input data includes machine tool model, tool model, fixture model, process model and CNC program, etc.; d) The simulation results can be visually displayed in the form of three-dimensional animation; e) Analyze, evaluate and optimize the simulation results, and use trial processing to verify if necessary. 5.2 The simulation software should be integrated with the 3D design modeling system, CNC programming system, process design system, etc., and share machine tool models and tool models. ......
