GB/T 32514.2-2016: Resistance welding -- Welding current measurement for resistance welding -- Part 2: Welding current meter with current sensing coil
Status: Valid
Standard IDUSDBUY PDFLead-DaysStandard Title (Description)Status
GB/T 32514.2-2016294 Add to Cart 3 days Resistance welding -- Welding current measurement for resistance welding -- Part 2: Welding current meter with current sensing coil Valid

Similar standards

GB/T 41861   GB/T 40337   GB/T 35091   GB/T 32514.4   GB/T 32514.5   GB/T 32514.3

Basic data

Standard ID: GB/T 32514.2-2016 (GB/T32514.2-2016)
Description (Translated English): Resistance welding -- Welding current measurement for resistance welding -- Part 2: Welding current meter with current sensing coil
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J64
Classification of International Standard: 25.16.30
Word Count Estimation: 15,159
Date of Issue: 2016-02-24
Date of Implementation: 2016-09-01
Quoted Standard: GB/T 32514.1-2016; GB/T 32514.3-2016; GB/T 32514.4-2016; ISO 669
Adopted Standard: ISO 17657-2-2005, IDT
Regulation (derived from): National Standard Announcement No
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the requirements for measuring welding time and current values ??of welding current for single-phase alternating current (50 Hz or 60 Hz) and DC resistance welding, and welding current measuring instruments with current sensing coils. This standard applies to a welding current measurement system (with connection to a welding controller) with a display or a calibrated output port.

GB/T 32514.2-2016: Resistance welding -- Welding current measurement for resistance welding -- Part 2: Welding current meter with current sensing coil


---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Resistance welding - welding current measurement for resistance welding - Part 2. welding current meter with current sensing coil ICS 25.16.30 J64 National Standards of People's Republic of China Resistance welding welding current measurement - Part 2. Welding Current Measuring Instrument with Current Induction Coil welding-Part 2. Weldingcurrentmeterwithcurrentsensingcoil (ISO 17657-2..2005, IDT) 2016-02-24 released 2016-09-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Management Committee released Directory Preface I 1 Scope 1 2 normative reference document 1 3 Terms and definitions 1 4 Environmental conditions 2 5 Classification and marking of welding current measuring instrument (with current induction coil) 2 5.1 Classification of welding current measuring instrument with current induction coil 2 5.2 Product identification 2 6 Requirements for welding current measuring instrument with current induction coil 2 6.1 Welding current measuring instrument 2 6.2 Current sensing coil 3 6.3 Welding current measuring instrument with current induction coil 3 6.4 Integrator 3 6.5 data processing unit 3 6.6 Display unit and output port 3 6.7 Soldering current shortest and longest duration 4 6.8 Maximum measuring current 4 6.9 Minimum measuring current 4 6.10 phase control current 4 6.11 Minimum time for current measurement 4 6.12 Input voltage fluctuation 4 6.13 Mechanical strength of current sensing coil 4 6.14 positioning error of current sensing coil 4 6.15 Influence of Ambient Temperature 4 6.16 Test 5 7 Test procedure 5 7.1 Maximum measuring current 5 7.2 Minimum measuring current 5 7.3 Phase shift control current 6 7.4 Minimum current measurement time 6 7.5 Power supply voltage fluctuation 6 7.6 Thermal performance test 6 8 mark 6 Appendix A (normative) shows the definition of the measurement time and the display current value Appendix B (informative) The setting of the current sensing coil and the structure of the welding current measuring instrument 10

Foreword

GB/T 32514 "resistance welding welding current measurement" is divided into five parts. - Part 1. Measurement guidelines; Part 2. welding current measuring instrument with current sensing coil; Part 3. Current sensing coils; - Part 4. Calibration system; Part 5. Confirmation of welding current measurement systems. This part is part 2 of GB/T 32514. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This part uses the translation method equivalent to ISO 17657-2..2005 "Resistance welding welding current measurement Part 2. with current sensing Coil welding current measuring instrument ". And the normative reference in this standard international documents are consistent with the relationship between China's documents are as follows. Mechanical and electrical requirements for solder resist welding machines (ISO 669..2000, MOD) GB/T This part is made by China Electrical Equipment Industry Association. This part of the National Welding Technology Standardization Technical Committee (SAC/TC70) centralized. This part of the drafting unit. Chengdu Sanfang Electric Co., Ltd., Tianjin seven high-tech Co., Ltd., Zhejiang Ken was Electrical Co., Ltd., Tian Tian Miaji Trade (Shanghai) Co., Ltd., Shenzhen Peng Yu Wei Technology Co., Ltd., Guangzhou Songxing Electric Co., Ltd. The main drafters of this part. Yang Qingxuan, Zhang Yimin, Zhu Xuanhui, Ni Yufeng, Liu Xingwei, Liu Guoying. Resistance welding welding current measurement - Part 2. Welding Current Measuring Instrument with Current Induction Coil

1 Scope

This part of GB/T 32514 specifies the welding time and welding for measuring single phase AC (50Hz or 60Hz) and DC resistance welding. The current value of the current, with the current induction coil welding current measuring instrument requirements. This section applies to a welding current measurement system with a display or a calibrated output port (which can be connected to a welding controller).

2 normative reference documents

The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. GB/T 32514.1-2016 Resistance welding welding current measurement - Part 1. Measurement guide (ISO 17657-1..2005, IDT) GB/T 32514.3-2016 Resistance welding welding current measurement - Part 3. Current sensing coils (ISO 17657-3..2005, IDT) GB/T 32514.4-2016 Resistance welding welding current measurement - Part 4. Calibration system (ISO 17657-4..2005, IDT) ISO 669 resistance welding resistance machine mechanical and electrical requirements (Resistancewelding-Resistanceweldingequip- ment-mechanicalandelectricalrequirements

3 terms and definitions

ISO 669 and the following terms and definitions apply to this document. 3.1 Minimum measurement time The minimum settable value of the measurement time. See Figure A.1. 3.2 Maximum measurement time The maximum settable value of the measurement time depends on the type of component of the welding current meter. See Figure A.1. 3.3 The measured measurement time is indicated by measuring time The duration of the welding current from start to finish. Note. Normally, the start and end times used to measure the current are set automatically. If the start time is set to zero or a value greater than zero, the end The time is set at a value less than the welding time (see Figure A.1), the welding current is calculated by the measurement between the start time and the end time. 3.4 Automatic zero correction. Automaticzerolevelcorrection When measuring DC welding current, the effect of correcting the output zero drift on the device is allowed.
......
