GB/T 31838.6-2021: Solid insulating materials - Dielectric and resistive properties - Part 6: Dielectric properties(AC method) - Relative permittivity and dielectric dissipation factor(frequencies 0.1Hz~10 MHz)
Status: Valid
Standard IDUSDBUY PDFLead-DaysStandard Title (Description)Status
GB/T 31838.6-2021344 Add to Cart 4 days Solid insulating materials - Dielectric and resistive properties - Part 6: Dielectric properties(AC method) - Relative permittivity and dielectric dissipation factor(frequencies 0.1Hz~10 MHz) Valid

Basic data

Standard ID GB/T 31838.6-2021 (GB/T31838.6-2021)
Description (Translated English)
Sector / Industry National Standard (Recommended)

Similar standards

GB/T 42733   GB/T 31838.7   GB/T 36289.1   GB/T 31838.8   GB/T 31838.5   GB/T 31838.3

GB/T 31838.6-2021: Solid insulating materials - Dielectric and resistive properties - Part 6: Dielectric properties(AC method) - Relative permittivity and dielectric dissipation factor(frequencies 0.1Hz~10 MHz)



---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Solid insulating materials-Dielectric and resistive properties-Part 6.Dielectric properties(AC method)-Relative permittivity and dielectric dissipation factor(frequencies 0.1Hz~10 MHz) ICS 17.220.99;29.035.01 CCSK15 National Standards of People's Republic of China Dielectric and resistance properties of solid insulating materials Part 6.Dielectric properties (AC method) Relative permittivity and dielectric loss factor (Frequency 0.1Hz~10MHz) (IEC 62631-2-1.2018,Dielectricandresistivepropertiesofsolidinsulating Released on 2021-05-21 and implemented on 2021-12-01 State Administration of Market Supervision and Administration Issued by the National Standardization Management Committee

Table of contents

Foreword Ⅰ Introduction Ⅱ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 Test method 2 5 Test procedure 9 6 Report 10 7 Repeatability and reproducibility 10 Appendix A (informative) Basic measurement 11 Reference 14

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules of Standardization Documents" Drafting. This document is Part 6 of GB/T 31838 "Dielectric and Resistance Characteristics of Solid Insulating Materials". GB/T 31838 has been released The following parts. ---Part 1.General Provisions; ---Part 2.Resistance characteristics (DC method) volume resistance and volume resistivity; ---Part 3.Resistance characteristics (DC method) surface resistance and surface resistivity; ---Part 4.Resistance characteristics (DC method) insulation resistance; ---Part 5.Resistance characteristics (DC method) Volume resistance and volume resistivity of dipping and coating materials; ---Part 6.Dielectric characteristics (AC method), relative permittivity and dielectric loss factor (frequency 0.1Hz~10MHz); ---Part 7.Resistance characteristics (DC method) Measuring volume resistance and volume resistivity at high temperatures. This document uses the translation method to be equivalent to IEC 62631-2-1.2018 ``Dielectric and Resistance Characteristics of Solid Insulating Materials Part 2-1. Relative permittivity and loss factor technical frequency (0.1Hz~10MHz) AC method". The Chinese documents that have a consistent correspondence with the normative reference documents in this document are as follows. ---GB/T 6672-2001 Plastic film and sheet thickness determination mechanical measurement method (ISO 4593.1993, IDT); ---GB/T 10580-2015 Standard conditions for solid insulating materials before and during the test (IEC 60212.2010, IDT). This document has made the following editorial changes. ---In order to be consistent with the existing standard series, the file name is changed to "Solid Insulating Material Dielectric and Resistance Characteristics Part 6.Dielectric Characteristics (AC method) Relative permittivity and dielectric loss factor (frequency 0.1Hz~10MHz)》; ---In order to facilitate the understanding and implementation of the application, the "Nul method" in 4.3.2.1 and 4.3.2.2 in IEC 62631-2-1.2018 is revised to "electrical Bridge Method"; ---Due to an editorial error in the original text of IEC 62631-2-1.2018, the εr in formula (13) is modified to ε0. Please note that some of the contents of this document may involve patents. The issuing agency of this document is not responsible for identifying patents. This document was proposed by the China Electrical Equipment Industry Association. This document is under the jurisdiction of the National Standardization Technical Committee for Evaluation of Electrical Insulation Materials and Insulation Systems (SAC/TC301). Drafting organizations of this document. Zhejiang Rongtai Electrical Equipment Co., Ltd., Suzhou Jufeng Electrical Insulation System Co., Ltd., Taizhou Yumingxin Materials Co., Ltd., Suzhou Taihu Electrical New Materials Co., Ltd., Xiamen Hongcheng Composite Materials Co., Ltd., Beijing Electrical Engineering Technology Technical Economic Research Institute, Zhejiang Bofei Electric Co., Ltd., Dongfang Electric Group Dongfang Electric Co., Ltd., Jiangsu CRRC Electric Co., Ltd., CRRC Yongji Electric Co., Ltd., Guangdong Mingyang Electric Co., Ltd., Anhui Weineng Electric Co., Ltd., Beijing Furunda insulation materials Limited Liability Company, Xinchengrui Technology Co., Ltd., Tongling Jingda Special Magnet Wire Co., Ltd., Wuxi Jiangnan Cable Co., Ltd., Jinbei Electric Industrial Magnet Wire Co., Ltd., Guilin Saimeng Testing Technology Co., Ltd., China Three Gorges Group Co., Ltd. The main drafters of this document. Liu Yali, Chen Hao, Zheng Minmin, Xia Yu, Guo Zhenyan, Zhu Yongming, Di Ningyu, Jing Fengxi, Zhang Yue, Wang Jianliang, Geng Tao, Guo Xianqing, Sheng Hairong, Zhang Jinxin, Zou Zubing, Wang Qin, Peng Chunbin, Zhu Zhicun, Kuang Meizhou, Dai Jiwen, Zhao Jie.

Introduction

Dielectric loss tangent or dielectric loss factor is also called tanδ, which is a basic parameter to measure the quality of insulating materials. Measuring capacitance The method of loss angle and loss angle has been used in industry for more than 100 years. The dielectric loss factor (tanδ) depends on several parameters, such as electrode design, material properties, environment, humidity, temperature, applied voltage, and mainly It depends on the test frequency, the accuracy of the test equipment and other parameters applied to the sample. The frequency range is limited, which depends on the test unit and electrode design, the size of the sample and the connecting wire. Therefore, in this document, all The frequency parameter is limited to the very low frequency (VLF) range of 0.1Hz~10MHz. However, the measuring instrument can provide a wider frequency Range, so the available and suitable frequency range is limited by the entire test system. GB/T 31838 proposes a test method for the dielectric and resistance characteristics of solid insulating materials to test the dielectric properties of solid insulating materials for users. And resistance characteristics provide a unified sample preparation method and test procedures. Currently, GB/T 31838 is composed of seven parts. ---Part 1.General Provisions. Put forward the factors that affect the dielectric and resistance characteristics of solid insulating materials, and guide the other parts of the document. prepared by. ---Part 2.Resistance characteristics (DC method) Volume resistance and volume resistivity. It is proposed to measure solid insulating materials (excluding immersion Stains and coating materials, casting materials) volume resistance and volume resistivity test methods. ---Part 3.Resistance characteristics (DC method) Surface resistance and surface resistivity. Proposed to measure the surface resistance of solid insulating materials And the test method of surface resistivity. ---Part 4.Resistance characteristics (DC method) Insulation resistance. A test method for measuring the insulation resistance of solid insulating materials is proposed. ---Part 5.Resistance characteristics (DC method) Volume resistance and volume resistivity of dipping and coating materials. For dipping and coating For layered insulating materials, test methods for measuring volume resistance and volume resistivity are proposed. --- Part 6.Dielectric characteristics (AC method) relative permittivity and dielectric loss factor (frequency 0.1Hz ~ 10MHz). mention A test method for measuring the dielectric properties of solid insulating materials at a frequency of 0.1 Hz to 10 MHz. ---Part 7.Resistance specific (DC method) Measuring volume resistance and volume resistivity at high temperatures. The proposed temperature is not higher than 800℃ The following test methods for determining the volume resistance and volume resistivity of solid insulating materials. Dielectric and resistance properties of solid insulating materials Part 6.Dielectric properties (AC method) Relative permittivity and dielectric loss factor (Frequency 0.1Hz~10MHz)

1 Scope

This document describes the measurement of the dielectric constant and dielectric loss factor characteristics of solid insulating materials in the frequency range of 0.1 Hz to 100 MHz. Test method (AC method). Note. This document mainly considers a measuring device system with a protective electrode.

2 Normative references

The contents of the following documents constitute the indispensable clauses of this document through normative references in the text. Among them, dated quotations Only the version corresponding to that date is applicable to this document; for undated reference documents, the latest version (including all amendments) is applicable to This document. IEC 60212 Standard conditions for solid insulating materials before and during the test (Standard conditions for use priority toandduringthetestingofsolidelectricalinsulatingmaterials) ISO 4593 Plastic Film and Sheeting Mechanical Scanning Determination of Thickness (Plastics-Filmandsheeting-Determinationof thicknessbymechanicalscanning)

3 Terms and definitions

The following terms and definitions apply to this document. The terms and definitions used in this document in ISO and IEC can be found on the following website. 3.1 Electrical insulating material A solid material with negligible low conductivity used to isolate conductor parts with different electric potentials. Note. The term ......
